The QuickPanel + Operator Interface is an all-in-one microcomputer designed for
maximum flexibility. The design is based on an advanced ARM core microprocessor to
combine a high-resolution touchscreen operator interface with a variety of
communications options. Users can connect to most industrial equipment through the
QuickPanel + communications ports.
The QuickPanel + is equipped with several memory types to satisfy the most demanding
applications. A section of DRAM is split between the operating system, an object store,
and application memory. A section of non-volatile flash memory functioning as a virtual
hard drive is divided between the operating system and persistent storage for application
programs. Retentive memory is a battery-backed SRAM to store and protect valuable data
during a power failure.

1.1.1 General Specifications

IC755CxW07CDx IC755CxS10CDx
Freescale i.MX535 (1 GHz ARM Cortex A8)
DDR2 SDRAM
512 MB
SLC NAND 256 MB
Microsoft Windows Embedded Compact 7
7" Widescreen TFT
10.4" Standard TFT LCD
LCD
800(W) x 480(H)
pixels WVGA
310 cd/m 2
1x 10/100BaseT
(RJ-45)
1x RS-232 UART port
(5-pin connector)
IC755CxS12CDx
DDR3 SDRAM 1 GB
SLC NAND 512 MB
512 KB (with battery backup)
12.1" Standard TFT
LCD
800(W) x 600(H) pixels SVGA
65,536
400 cd/m 2 450 cd/m
LED
Projected capacitive
Two-point
2x 10/100BaseT (RJ-45)
1x 10/100BaseT (RJ-45) for IC755CxS12CDA
1x RS-232 UART port,
1x RS-232/485 port
(2x 5-pin connector)
(1x 10-pin connector for IC755CxS12CDA)
2x USB 2.0 (Type-A)
Max power (5 V at 0.5 A)
1x USB 2.0 (Mini Type-B)
1x SD/SDHC card slot
IC755CxS15CDx
15" Standard TFT
LCD
1024(W) x 768(H)
pixels XGA
2 310 cd/m 2
GFK-2847F User Manual 7
