6.03 Primary Screens: TRIP LOG

6.03 TRIP LOG Screen

(GPS MAP → MAIN MENU → COMPASS →
TRIP LOG)
The upper half of the TRIP LOG
split into 12 data fields:
• Total distance travelled (Total Dist)
• Total time (Total Time)
• Time of last reset (Trip Reset)
• Straight line distance: from start position to
end position (Strt Line Dist)
• Time moving (Time Moving)
• Average moving speed (Av Moving)
• Speed now (Speed Now)
• Average speed (Av Speed)
• Maximum speed (Max Speed)
• Sunrise time (Sunrise)
• Sunset time (Sunset)
• Altitude above sea level (Elevation)
All units can be given in metric or imperial.
(section 7.11).
TRIP LOG
The lower half of the
shows a graph of the elevation profile of
your journey. Above the graph, a red pointer
indicates the maximum height and a blue
pointer indicates the minimum height. Figures
for these heights are given below the graph.
Also shown is the abbreviation
ascended height.
Buttons:
Start/Stop
Press to start/stop data logging.
(Note: remember that if Stop is showing,
it means Start was the button pressed
previously and the GPS is logging data).
© Satmap Systems Ltd
The unit's data logging functions are intended
to register a single trip. The log should be reset
before starting the next trip. Using the
Stop
button allows you to pause data logging
screen is
during a journey, e.g. pausing for a lunch break.
When Stop
all data logging. If you switch to the
screen and continue moving, no snail trail is
left.
GPS Map
Return to
Primary Screens
Go to GPS STATUS
scroll through primary screens (section 4.00)
Menu
Access the following range of options:
• Reset All
• Reset All & Convert
• Reset Log (keeps the snail trail and elevation
screen
profile)
• Reset Trail (also resets elevation data)
• Reset Trail & Convert
• Convert Trail to Track (section 6.04)
• Set Trip Data (section 7.14)
There are on-screen descriptors for each
'Asc:' for
option. If you would like to save your data
before resetting, choose one of the 'Convert'
options in the menu.
As the trip log data uses up memory on your
unit, make sure you reset the trip log regularly
to maintain optimum performance.
Start/
has been pressed, the unit stops
GPS MAP
GPS MAP (section 5.00)
screen (section 6.07) and
19
Note: If you transit between trips and press
Start without resetting the log, the transit
is shown as a straight line snail trail to your
present location and will be incorporated into
subsequent data logging.
Elevation data:
• Elevation data is obtained from maps or the
GPS Settings
GPS. See
(section 7.09).
Trip Log Status:
(Stop/Record Icon)
Elevation
profile
Stop
Trip Log
has started
Figure 6.03
GPS Map
Note: Trip log data is not stored in hibernate
mode.
for more details
Trip Log Active
Trip Log Inactive
Elevation
data
Access
Menu
options
Primary
Screens
