Edit Route Map; Edit Waypoints - satmap ACTIVE 10 Full User Manual

8.02d ROUTES MENU: ROUTE EDIT
8.02d Edit Route Map
(GPS MAP → MAIN MENU → ROUTES
MENU → (folder/route) → Edit → Edit Route
Map)
Highlight Edit Route Map, then press
to access EDIT ROUTE screen. Using the
joystick, move the location icon to the edit
point on the route. Either press the
Waypoint button (section 8.01) or center
press the joystick to add a waypoint with a
green-headed 'pin'. Drag the new waypoint to
the desired location.
Done
Either press or center press the joystick
to fix the new waypoint. Move the location
icon away from the route. Press
return to ROUTE EDIT screen.
8.02e Edit Waypoints
(GPS MAP → MAIN MENU → ROUTES
MENU → (folder/route) → Edit → Edit
Waypoints)
Highlight Edit Waypoints, press
access the WAYPOINTS screen. A list
is shown, SP is for start point, WP is for
waypoint. Highlight the waypoint to be edited
and either press Edit or center press the
joystick to access the EDIT WAYPOINT
screen. Here you have the option to edit
individual waypoints:
• Edit Name
• Edit Comments
• Edit Location by Grid
• Edit Location by Map
• Delete
© Satmap Systems Ltd
Edit Name
Highlight Edit Name
press the joystick to access the keypad and
rename the waypoint (section 9.00).
Edit Edit Comments
Highlight Edit Comments
center press the joystick to access the keypad
Add
and add a description to the waypoint (section
9.00). This will show up next to the waypoint
name in the
Edit Location by Grid
Highlight Edit Location by Grid
Edit
or center press the joystick to edit the
waypoint by changing the grid reference
values. This will take you to the
Done to
screen where you can use the joystick to
move left/right to toggle between boxes.
Move the joystick up/down to change the box
entries. Pressing
rows (except with OSGB). Select
complete to go back to the
menu.
Edit to
Edit Location by Map
Highlight Edit Location by Map
Edit
or center press the joystick to edit the
waypoint on the map. Click the waypoint to
set a green-headed 'pin' and drag it to a new
location. Press
joystick to confirm the placement.
Delete
Highlight Delete
press the joystick to instantly delete the
waypoint. Press
ROUTE EDIT
and press Edit or center
and press Edit or
WAYPOINTS menu.
and press
SETTING
Next will move between
Done when
EDIT WAYPOINT
and press
Done or center press the
and press Delete or center
Back to go back to the
menu.
45
green-
headed
pin
Figure 8.02d
Figure 8.02e
