19.00 GoTo and Marker
19.00 GoTo and Marker Screen
(GPS MAP → MAIN MENU → GoTo and
Marker)
GoTo point: A set point that acts as a target.
Once you have activated a GoTo point, a
straight line from your current location and
GoTo point (or route) will appear. This is
useful in situations when you do not know
where you are going, i.e. you have no
determined route. Access various statistics
from the data box options using this feature,
e.g. GoTo Distance, GoTo ETA, GoTo Bearing
etc. (section 7.08).
Marker: A red flag (reference point) on the
map from which the distance and bearing to
any other point on the map can be measured.
You are not able to follow a Marker and it
is only available in Planning mode. Use the
joystick to move the planning circle in the
desired direction to calculate the straight line
distance or bearing.
The menu options are as follows:
• GoTo – Set By Coords
• GoTo – Route*
• Marker – Set By Coords
*Available once a GoTo point has been set.
Note: GoTo and Marker function for setting by
postcode are available for some units sold in
the UK.
Clear Marker and GoTo – Clear
active once a point/marker has been set.
(Also accessible from the POSITION INFO
screen section 10.00).
© Satmap Systems Ltd
19.01 GoTo – Set By Coords
Marker – Set By Coords
Selecting one of these options brings up
a screen on which grid references may be
entered. Move the joystick up/down to change
the coordinate values, and left/right to select
the next entry box, or use the
move to the next row.
Buttons:
Next
Move between rows (does not work with
OSGB)
Convert
Updates coordinate conversions. (Active once
original coordinates have been changed).
Map
Return to last map screen
Done
Press to set coordinates of GoTo point/Marker
Cancel
Return to GoTo and Marker
Back
Return to PLANNING
Coordinates can be entered in different
position display formats and the preferred
format can be selected from
Settings → GPS
Alternative option for setting a GoTo point/
Marker:
buttons are
(PLANNING → POSITION INFO via center
press → Set Marker/Set GoTo)
Next button to
screen
screen
Main Menu →
Settings.
79
19.02 GoTo – Route
Only available once a GoTo point has been
set. Selecting this option shows the straight
line distance from your current location to a
route and puts the center of the planning
circle at the GoTo point.
Figure 19.00
Figure 19.01
