8.00 MAIN MENU: ROUTES MENU
8.00a Active and Inactive Routes
There are three ways to 'activate' a route:
• Highlight the route in the ROUTES MENU
and press Activate. An active route is
indicated by a tick next to the route name.
To deactivate, highlight the ticked route
name and press No route active.
• Alternatively you can go to the
MENU, press View and then Start, which
activates the route automatically.
• If you can see the route on the
PLANNING screen, center press the joystick
anywhere on the route. This will bring up the
Choose Information Type window (section
11.00). Select the route, and then move the
joystick left/right to highlight the green tick.
An activate route has relevant data choices
available for display on the GPS MAP screen
in either 2 or 4 data box overlays (sections
7.04 – 7.08). Refer to MAIN MENU →
Settings → Set Trip Data to control whether
changing an activated route during a trip will
reset the log data.
When active, the route is shown as a yellow
or blue highlighted line with red arrowheads
indicating the direction of travel. Inactive
routes are shown as gray highlighted lines
when displayed.
Inactive routes may be hidden or have just
their start points displayed (section 7.14).
Note: Showing your inactive routes will take
up operating memory.
© Satmap Systems Ltd
8.00b Following a Route
A route is made up of individual waypoints,
shown as small green circles which turn blue
as you approach the next waypoint. The route
color can be either blue or yellow, with varying
transparency, depending on the active route
color chosen (section 8.02f). The default route
color is blue.
ROUTES
To follow a route, you need to first 'activate' it
(section 8.00a).
GPS MAP
or
As you begin to follow the yellow/blue route,
the next waypoint along turns blue. The
current leg between waypoints is shown to
have blue edging and blue arrowheads. As
you approach this point, the waypoint name
is displayed (section 8.02e) and the unit will
beep. As you pass this waypoint it will turn
from blue to green, and the next waypoint
marker will turn blue, and so on.
Figure 8.00b
41
Figure 8.00a
Active route
Inactive route
