Summary of Contents for Planet Audio P370MB
-
Page 2: Table Of Contents
CONTENTS Precautions..............................1 Take Precaution............................1 Installation ..............................2-3 Installation Procedures .......................... Installation Opening ..........................Wiring Connections..........................3 Remove of the Main Unit ........................3 Control Panel Button Locations ........................4 Operation ..............................4-5 Power On/Off ............................4 ..........................4 Adjust Volume (VOL) Adjust Menu Options (SEL) ........................ -
Page 3: Precautions
PRECAUTIONS Take Precaution Some MP3/WMA files may not be playable. Be sure to lower the volume before switching off the unit or the ignition key. -
Page 4: Installation
INSTALLATION Installation Procedures First complete the electrical connections and then check for correctness. Installation Opening This unit can be installed in any dashboard Having an opening as shown below. 2.05 inch 7.20 inch Insert mounting collar into the dashboard and bend the mounting tabs out with a screwdriver. Make sure that lock lever is flush with the mounting collar( not projecting outward). -
Page 5: Wiring Connections
INSTALLATION(CONT.) - Only use speakers with 4 ohms impedance. - The maximum current of the auto antenna is 200mA. Wiring Connections WIRING DIAGRAM Radio Antenna White:Front Left PRE-AMP Output Red: Front Right PRE-AMP Output Red: Rear Right PRE-AMP Output White: Rear Left PRE-AMP Output Purple + Green + CAUTION... -
Page 6: Control Panel Button Locations
CONTROL PANEL BUTTON LOCATIONS OPERATION 1 . Turn Unit on/off (PWR) Press any button to turun on the unit. Press and hold the VOL/PWR/SEL button to turn off the unit. Adjust the volume (VOL) Rotate the VOL knob to increase or decrease the volume level. Adjust Menu Options (SEL) Press SEL button repeatedly to cycle through the following adjustable audio functions: BASS, TREBLE, BALANCE, FADER, EQ OFF, CLASS/ROCK/POP/ FLAT, LOUD ON/OFF, DX/LOC, STEREO/MONO,... -
Page 7: Change The Source (Src)
OPERATION 4. Change the Source (SRC) Press this button to select the different modes: Radio, BT(Bluetooth), USB(with USB deviceinserted), SD(with SD card inserted) and AUX-IN(auxiliary input) modes. 5. Setting Time Press the CLK button to display time. Press and hold the CLK button again, the hours digits start flashing on the display. -
Page 8: 15. Loudness On/Off
OPERATION 15. Loudness on/off Press the LOUD button to turn on the loudness to reinforce the output of bass frequencies, press again to turn it off. 16. Hands-free Microphone To receive your voice when you calling by using this bluetooth handsfree system. 17. -
Page 9: Bluetooth Operation
To begin pairing, enable BT mode on your mobile phone. 2. When the phone the car audio system, the PLANET P370MB name will be displayed. 3. Choose the PLANET P370MB from the device list to pair and connect with the car audio system. Upon the BT logo will stop 4. -
Page 10: Troubleshooting
TROUBLESHOOTING If you suspect something is wrong, immediately switch power off. Do not use the unit in abnormal condition, for example without sound, or with smoke or foul smell, can cause fire or electric shock. Immediately stop using it and call the store where you purchased it. Never try to repair the unit by yourself because it is dangerous to do so. -
Page 11: Specifications
MicroSD™ Pre-amp Output Front and Rear Frequency Response 20 Hz - 20 KHz S/N Ratio 60dB BT Profile supports A2DP , AVRCP & HFP Range of frequency 2.4GHz spectrum Choose Planet Audio products if you’re looking for a quality sound.
