MANUEL D'INSTALLATION
KCPROXWLC
Dual Technology Digicode

8] PROGRAMMING CHART

2 beeps are emitted
Red
Programming
illumination
keypad
A0
1 beep
Green LED ON
Enter the illumination
time in seconds or
"00" for a permanent
illumination.
1 beep = OK
Green LED ON
4 beeps = Error
cdvi.com
6
cdvigroup.com
/Proximity reader - Wiegand
®
For the programming
connect the purple cable
with the black cable.
Switch the power supply
off then switch it on.
LED ON
Programming
the output
format
A1
1 beep
Green LED ON
Enter:
- 1 = Wiegand format
- 2 = Standard format
- 3 = ISO Track 2
format
1 beep = OK
Green LED ON
4 beeps = Error
Programming
the code lenght
A2
1 beep
Green LED ON
Enter:
4, 5 or 6 to specify the
number of digits.
1 beep = OK
Green LED ON
4 beeps = Error
EN
Programming the
Bit format
A3
1 beep
Green LED ON
Enter: 26, 30 or 44
to define the Bit number of
the Wiegand format
1 beep = OK
Green LED ON
4 beeps = Error
