IBM Flex System V7000 Introduction And Implementation Manual page 162

Choosing the Actions pull-down button will allow you to collect inventory, update storage
system firmware, and open the IBM Flex System V7000 Storage Node management
application, as shown in Figure 3-88.
Figure 3-88 FSM - Storage Control - Storage system action menu
Managing external storage systems
To manage external storage subsystems in IBM Flex System Manager, perform the following
steps:
1. From the left slide-out tab, select Resource Explorer, as shown in Figure 3-89.
Slide-out tab
Figure 3-89 Opening Resource Explorer in FSM
144
IBM Flex System V7000 Storage Node Introduction and Implementation Guide
