model no. 058-8691-0
AIR-POWERED BRAD NAILER
IMPORTANT:
For your own safety, read and follow all of the Safety Guidelines
and Operating Instructions before operating this nailer. Keep this
manual for future reference.
OPERATING
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 058-8691-0 and is the answer not in the manual?

Questions and answers

Related Manuals for MasterCraft 058-8691-0

Summary of Contents for MasterCraft 058-8691-0

  • Page 1 058-8691-0 AIR-POWERED BRAD NAILER IMPORTANT: OPERATING For your own safety, read and follow all of the Safety Guidelines MANUAL and Operating Instructions before operating this nailer. Keep this manual for future reference.
  • Page 2 TABLE OF CONTENTS TECHNICAL SPECIFICATIONS SAFETY GUIDELINES KEY PARTS DIAGRAM TECHNICAL INFORMATION TYPES OF NAILS OPERATING INSTRUCTIONS MAINTENANCE TROUBLESHOOTING EXPLODED VIEW PARTS LIST WARRANTY...

  • Page 3: Technical Specifications

    058-8691-0 | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS SAFETY GUIDELINES This manual contains information that relates to PROTECTING PERSONAL SAFETY and CAPACITY (QTY.) 100 Nails PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual carefully and understand it thoroughly before using the product. The symbols listed below are used to NAIL SIZE 18–gauge brad nails (5/8–2")

  • Page 4: Safety Guidelines

    058-8691-0 | contact us 1-800-689-9928 SAFETY GUIDELINES Risk of burns: The pump and the manifold generate high temperatures. In order to avoid burns or other injuries, do not touch the pump, the manifold, Do not use oxygen or any other combustible or bottled or the transfer tube while the compressor is running.
  • Page 5 058-8691-0 | contact us 1-800-689-9928 CAUTION! Potential hazard that may result in injury or damage to equipment. Air inlet plug Quick release handle Disconnect the tool from the air supply and turn off the compressor before performing any maintenance,...
  • Page 6 058-8691-0 | contact us 1-800-689-9928 Compatible compressors GUIDELINES FOR PROPER USE AND OPERATION Be sure to use a proper air compressor with Mastercraft air-powered tools. The ® compressor should be able to supply a minimal air delivery of 2.0 CFM@ 90 PSI to ensure the compressor can run continuously with the Mastercraft ®...

  • Page 7: Types Of Nails

    058-8691-0 | contact us 1-800-689-9928 • It is recommended that a filter-regulator-lubricator be used and be located as close to the tool ACCEPTABLE NAILS as possible. • Length: 5/8 - 2" (15 to 50 mm) If a filter-regulator-lubricator is not installed, place up to 6 drops of compressor oil into the air inlet plug before each use.

  • Page 8: Model No. 058-8691-0 | Contact Us 1-800

    058-8691-0 | contact us 1-800-689-9928 Loading nails Insert a strip of nails (1) into the fig. C magazine. After ensuring that the points 1. Disconnect the tool (1) from the air fig. A of the nails are facing down, close the supply (2) (Fig.

  • Page 9: Model No. 058-8691-0 | Contact Us 1-800

    058-8691-0 | contact us 1-800-689-9928 Cold weather operation Fasteners depth adjustment fig. F When operating any air-powered tool below freezing temperature: The Mastercraft® Air-powered Brad Nailer • Verify that the compressor tanks have been properly drained prior to use.
  • Page 10 058-8691-0 | contact us 1-800-689-9928 Maintenance Clearing a jammed nail To clear a jammed nail TOOLS OR MAXIMUM SERVICE INTERVAL MAINTENANCE DESCRIPTION Disconnect the tool from the air supply line. MATERIALS Each Use or REQUIRED Remove the non-jammed nails that are stored in the tool’s magazine.

  • Page 11: Cylinder Cover 1

    058-8691-0 | contact us 1-800-689-9928 PROBLEM POSSIBLE CAUSES SOLUTIONS The following chart lists common issues and solutions. Please read it carefully and Verify that the air supply is adequate. The air supply is inadequate. The tool does not follow all instructions carefully.
  • Page 12 058-8691-0 | contact us 1-800-689-9928 Sealing Washer Movable Driver Guide Cover Gun Body O-RING 1.9 x 1.2 Guide Stand Pin 3 x 26 Driver Guide Washer II Safety Nozzle Compressed Spring Inlay Slice Pusher Pipe Movable Magazine Adjustable Stand Bolt M4 x 12 Norm Pin 1.5 x 8...
  • Page 13 058-8691-0 | contact us 1-800-689-9928 3-Year Limited Warranty This warranty will not apply to any product or part thereof if any part from another manufacturer is installed therein or any repairs or alterations have This product is guaranteed for a period of 3 years from the date of original retail purchase been made or attempted by unauthorized persons.
