Getting to Know Your AutoHybrid IP2

1 2
Controls & Indicators
Hidden Reset Switch
1.
Use a paper clip to reset the AutoHybrid IP2 instead of power cycling.
Auto Answer
2.
When enabled, AutoHybrid IP2 automatically answers an incoming call and
then disconnects after the caller hangs up.
OH LED
3.
Lit when the corresponding line is off-hook. For incoming calls, the OH
LEDs provide a visual ring indication.
Call Buttons
4.
Press this button to answer the corresponding line.
Drop Buttons
5.
Press this button to drop a call or place the corresponding line on-hook.
Signal LEDs
6.
Send LEDs represent the signal level going into the transmitter. Receive
LEDs represent the signal level at the output XLR.
Conference Button
7.
Conference lines 1 & 2 together when both lines are off-hook. The LED will
only light up when there are two calls in an active conference.
Power LED
8.
Lit when unit receives power from AC or PoE.
2
AutoHybrid IP2™ VoIP/AoIP Codec
Line 1
3 4 5 6 Line 2
6 4 5 3 2
7 8
