Call Management - JK Audio AutoHybrid IP2 User Manual

Device Friendly Name
1.
Edit the Friendly Name under the System tab.
Line Status, Caller ID, Active Codec, Caller Name
2.
Indicates when a line is On Hook, Off Hook or ringing. Caller ID and the
active Codec will appear adjacent to the Line Status. If it is available, the
Caller Name will appear below the Line Status.
Phone Number Input
3.
A. Enter a phone number or a valid SIP address.
For outbound calls in the US, dial 1, then the area code.
B. Click on a Username/Number from the Call Log to dial a recent caller.
Call Button
4.
Press <Call> to answer an incoming call
Drop Button
5.
Press <Drop> to hang up a call.
Mute Button
6.
Mute Buttons for Send and Receive Audio.
Volume Controls
7.
Adjust the volume for Send and Receive Audio.
VU Meter
8.
Individual peak indicators for Send and Receive Audio.
Auto Answer & Ring Count
9.
Disable/Enable Auto Answer. Select the number of rings before
Auto-Answer takes the line off-hook.
Ducking
10.
Lowers the caller's audio level by 9 dB when local audio is present.
AGC
11.
Automatically adjust the gain of caller audio so all callers are received at an
average level.
Test Tones
12.
Send a full scale 0 dB, maximum output level 1kHz tone down the line.
Conference
13.
Conference lines 1 & 2 together when both lines are off-hook and indicates
a conference is active. Edit Conference mode options In the Audio menu
(Audio> Conference Modes).
Auto CNF
14.
Automatically conference lines 1 & 2 together, when both lines are off-hook.

Call Management

(Username@Domain)
(18005551234)
Graphic User Interface
7
