ETHERNET/WIFI – (
With ETHERNET/WIFI displayed, press the PRINT/ENTER key. The display will change to
ETHERNET MOdE. Proceed to the Ethernet Port Output Mode parameter.
Otherwise, press the ID/HEIGHT key to advance to the TIME SETTINGS menu.
ETHERNET MOdE (Ethernet Port Output Mode)
The display will show ETHERNET MOdE and the current setting. If the value displayed is
acceptable, press the PRINT/ENTER key to save it. Otherwise, using the numeric keys,
enter a new value and then press the PRINT/ENTER key to save it.
Allowable values are 0, 1, 2 or 3.
0 = Ethernet Port Output Mode is Disabled
1 = Ethernet Port Output Mode is set for Weight On Demand
2 = Ethernet Port Output Mode is set for Continuous Data
3 = Ethernet Port Output Mode is set for a Printer (not for connection to a printer
but can output print data to PC if connected)
PRINTER TYPE (Set Type Of Printer Output –
The display will show PRINTER TYPE and the current setting. If the value displayed is
acceptable, press the PRINT/ENTER key to save it. Otherwise, using the numeric keys,
enter a new value and then press the PRINT/ENTER key to save it.
Allowable values are 0, 1, 2 or 3.
0 = Print default ticket
1 = Print journal line
2 = Print label
3 = Print nControl ticket (must have loaded a ticket format, otherwise will use
default ticket)
ENd OF PRINT (End Of Print Linefeeds –
At the end of data sent to a printer, the MV1 can send a number of carriage return/line feeds
to space the paper in the printer to a desired position for withdrawal or for the next print.
The display will show End OF PRINT and the current setting. If the value displayed is
acceptable, press the PRINT/ENTER key to save it. Otherwise, using the numeric keys,
enter a new value and then press the PRINT/ENTER key to save it.
Allowable values are 0 through 9.
RESET ETHERNET (Reset Ethernet Settings to Factory Default Settings)
The display will show RESET ETHERNET and the current setting. If the value displayed is
acceptable, press the PRINT/ENTER key to save it. Otherwise, using the numeric keys,
enter a new value and then press the PRINT/ENTER key to save it.
Allowable values are YES or no.
YES = Ethernet settings are reset to
factory default settings
8555-M512-O1 Rev D 01/15
If Option Card Installed
Only if ETHERNET MOdE = 3
no = Ethernet settings are not reset to
factory default settings
)
Only if ETHERNET MOdE = 3
)
)
39
