Body Mass Index (BMI) Functions
This is the CLEAR (BACKSPACE) key. It is used to clear an incorrect entry
from the display without processing the data. If an incorrect entry is made,
press this key and re-enter the correct data. When entering the ID, pressing
this key will act as a "backspace" key (it will back up one space and delete the
character in that space). NOTE: The CLEAR key must be pressed before
the PRINT/ENTER key to ensure the data is not processed.
This is the PRINT/ENTER key. It serves several purposes. First, it is used to
signal completion of the data entry and causes the MV1 to process the data
entered. Second, it is used to initiate the transmission of weight and
associated data using the selected I/O port.
NOTE: The MV1 will not respond to pressing the PRINT/ENTER key unless the
weight display is stable. If displaying gross weight, only the gross weight is
printed. If displaying net weight, the gross, tare, and net weights are printed. If
the ID and BMI features are used, their data is printed along with the weight data.
nControl Feature
The MV1 includes support for nControl. nControl is
a PC based program that can design a ticket then
download the ticket information to the MV1. The
MV1 allows 1 programmable format (up to 2kb in
size) instead of the ASCII format default ticket.
For more information on nControl, refer to the
nControl Fast Start Guide.
NOTE: If the ID/HEIGHT key is disabled, the appropriate field will be left
out when printing a ticket.
10
These keys are used to enter alphanumeric data during the setup
and calibration as well as during normal operation of the MV1.
NOTE: The 0 and 1 keys have
dual functions. They are used to
enter numeric data during setup
and calibration as well as during
normal operations. In addition,
they are used to select YES or
NO to various prompts.
To enter letters, you must press the key in succession until the
desired letter is displayed. This is similar to the way a cell phone
keypad operates. (Ex: If you want to enter the letter C, you would
need to press the 2 key four times).
Time, mm/dd/yy
ID:
xxxxxxxxxxx
BMI:
xx.x
Height:
xx.x cm
Weight:
xxx.xuu G
xxx.xuu T
xxx.xuu N
SAMPLE TICKET
8555-M512-O1 Rev D 01/15
