13 GenICam and Advanced Features

13 GenICam and Advanced Features

13.1 Introduction

For new applications or to set the device via wxPropView (p. 74) we recommend to use the GenICam (p. 155)
interface layout as it allows the most flexible access to the device features.
After you've set the interface layout to GenICam (p. 155) (either programmed or using wxPropView (p. 74)), all
GenICam (p. 155) controls of the device are available.
Note
It depends on the device, which controls are supported.
In wxPropView (p. 74), you can see them in "Setting -
As you can see, there are some controls with and without the prefix "mv".
• "mv" prefix features are unique non-standard features developed by MATRIX VISION.
• Without "mv" are standard features as known from the Standard Feature Naming Convention of GenICam
properties (p. 159) (SFNC).
All those features are "camera based / device based" features which can also be accessed using the camera with
other GenICam (p. 155) / USB3 Vision (p. 161) compliant third-party software.
MATRIX VISION GmbH
Base -
Figure 1: wxPropView - GenICam controls
Camera - GenICam":
107
