Analog Control - Matrix Vision mvBlueFOX3 Technical Manual

114
Feature name (acc.
(p. 159))
CounterSelector
CounterEventSource[Counter
Selector]
CounterEventActivation[Counter
Selector]
etc.
TimerSelector
TimerDuration[TimerSelector]
TimerDelay[TimerSelector]
etc.
related to the usage of programmable counters and timers.
Because there are many ways to use this feature, the list of use cases is long and not finished yet:
• Getting a trigger with an incremental encoder (p. 227)
• Creating different exposure times for consecutive images (p. 233)
• Creating synchronized acquisitions using timers (p. 277)
• Generating a pulse width modulation (PWM) (p. 229)
• Outputting a pulse at every other external trigger (p. 232)

13.6 Analog Control

The "Analog Control" contains features like
Feature name (acc.
(p. 159))
GainSelector
Gain[GainSelector]
GainAuto[GainSelector]
GainAutoBalance
BlackLevelSelector
BalanceWhiteAuto
Gamma
etc.
to SFNC Property name (acc. to mvIMPA
CT Acquire (p. 157))
counterSelector
counterEventSource
counterEventActivation
timerSelector
timerDuration
timerDelay
to SFNC Property name (acc. to mvIMPA
CT Acquire (p. 157))
gainSelector
gain
gainAuto
gainAutoBalance
blackLevelSelector
balanceWhiteAuto
gamma
CONTENTS
Description
Selects which Counter to configure.
Selects the events that will be the
source to increment the Counter.
Selects the Activation mode Event
Source signal.
Selects which Timer to configure.
Sets the duration (in microseconds)
of the Timer pulse.
Sets the duration (in microseconds)
of the delay.
Description
Selects which Gain is controlled by
the various Gain features.
Controls the selected gain as an
absolute physical value [in dB].
Sets the automatic gain control
(AGC) mode.
Sets the mode for automatic gain
balancing between the sensor color
channels or taps.
Selects which Black Level is con-
trolled by the various Black Level
features.
Controls the mode for automatic
white balancing between the color
channels.
Controls the gamma correction of
pixel intensity.
