Mvbluefox3-M1 - Matrix Vision mvBlueFOX3 Technical Manual

32
2004: 0.4 Mpix, 728 x 544,
1012b: 1.2 Mpix, 1280 x 960,
1012d: 1.2 Mpix, 1280 x 960,
1013: 1.3 Mpix, 1280 x 1024,
1020: 2.0 Mpix, 1600 x 1200,
1020a: 2.0 Mpix, 1600 x 1200,
2016: 1.6 Mpix, 1456 x 1088,
2024: 2.4 Mpix, 1936 x 1214,
2024a: 2.4 Mpix, 1936 x 1214,
1031: 3.1 Mpix, 2052 x 1536,
2032: 3.2 Mpix, 2048 x 1536,
2032a: 3.2 Mpix, 2064 x 1544,
2051: 5.1 Mpix, 2464 x 2056,
2051a: 5.1 Mpix, 2464 x 2056,
2089: 8.9 Mpix, 4112 x 2176,
2089a: 8.9 Mpix, 4112 x 2176,
1100: 10 Mpix, 3856 x 2764,
2124: 12.4 Mpix, 4112 x 3008,
2124a: 12.4 Mpix, 4112 x 3008,
- B: Sensor color
G: Gray scale
C: Color
- C: Infrared enhanced (for -1013G)
E: Infrared enhanced
- (1): Lensholder
only mvBlueFOX3-1
1: CS-mount (standard) without back focus adjustment
2: C-mount without back focus adjustment
only mvBlueFOX3-2
1: C-mount (standard) without back focus adjustment
2: C-mount with back focus adjustment
- (2): Filter
1: IR-CUT (standard)
2: Glass
3: Daylight cut
9: None
- (3): Case
1: Color blue (standard)
2: Color black, no logo
- (4): I/O
1: None (standard)
2: With I/O

7.2.2 mvBlueFOX3-M1

The mvBlueFOX3-M1 nomenclature scheme is as follows:
mvBlueFOX3-M1(A)(B)(C) - (1)(2)(3)(4)
- (A): Sensor model
012b: 1.2 Mpix, 1280 x 960,
012d: 1.2 Mpix, 1280 x 960, 1/3"
013: 1.3 Mpix, 1280 x 1024,
020: 2.0 Mpix, 1600 x 1200, 1/1.8"
020a: 2.0 Mpix, 1600 x 1200,
031: 3.1 Mpix, 2052 x 1536, 1/3"
100: 10 Mpix, 3856 x 2764,
- (B): Sensor color
G: Gray scale
C: Color
- (C): Infrared enhanced (for -013G)
E: Infrared enhanced
- (1): Lensholder
1: no lensholder
2: BF3-LH-SMNT 13
- (2): Filter
1: standard
- (3): Case
1/2.9", CMOS
1/3", CMOS
1/3", CMOS
1/1.8", CMOS
1/1.8", CMOS
1/1.8", CMOS
1/2.9", CMOS
1/1.2", CMOS
1/1.2", CMOS
1/3", CMOS
1/1.8", CMOS
1/1.8", CMOS
2/3", CMOS
2/3", CMOS
1", CMOS
1", CMOS
1/2.35", CMOS
1.1", CMOS
1.1", CMOS
1/3"
1/1.8"
1/1.8"
1/2.35"
