21.3 mvBlueFOX3-2024 (2.4 Mpix [1936 x 1216])
Note
The exposure time step width is limited to the sensor's row time of 4.86 us and therefore
- auto exposure with very low exposure times will perform with relatively large increments and
- exposure mode = TriggerWidth (if available) will perform with a jitter corresponding to the row time
The following trigger modes are available:
Setting (GenICam)
"TriggerSelector =
FrameStart"
"TriggerMode = Off"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
Software"
"ExposureMode = Timed"
To trigger one frame execute
the TriggerSoftware@i command
then.
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
desired Line "
"TriggerActivation =
LevelLow"
"ExposureMode = Timed"
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
desired Line "
"TriggerActivation =
LevelHigh"
"ExposureMode = Timed"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
desired Line "
"TriggerActivation =
FallingEdge"
"ExposureMode = Timed"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
desired Line "
"TriggerActivation =
RisingEdge"
"ExposureMode = Timed"
MATRIX VISION GmbH
Mode / Setting (obsolete "Device
Specific")
Continuous
OnDemand
OnLowLevel
OnHighLevel
OnFallingEdge
OnRisingEdge
Description
Free running, no external trigger
signal needed.
Image acquisition triggered by
command (software trigger).
Start an exposure of a frame as
long as the trigger input is below
the trigger threshold. (No Frame
Trigger!)
Start an exposure of a frame as
long as the trigger input is above
the trigger threshold. (No Frame
Trigger!)
Each falling edge of trigger signal
acquires one image.
Each rising edge of trigger signal
acquires one image.
