Table Of Contents; Introduction - Envirovent HeatSava Installation Manual

Contents
01 Introduction
02 Technical Specification
03 Wiring Diagrams
04 Safety
05 Controls
06 Box Contents
01

Introduction

Designed for through the wall installation, the heatSava is ideal for both refurbishment and new build properties.
The outside diameter of the heat exchange casing is smaller than a standard wall sleeve and can therefore utilize an existing one
already in place. The heatSava also takes into account the complexities of different wall depths to offer 4 different main lengths that the
heat exchange casing is manufactured to (see page 4). The unit is installed from the inside out to allow for ease of installation in high-
rise applications. The heatSava is exceptionally versatile and can be installed horizontally or vertically in 4 different positions through
360°. The unit has been designed to operate continuously.
Thank you for choosing EnviroVent
The fastest growing ventilation company in the UK
Ensure that this product is treated with care, installed and maintained correctly i.e. for
the life of the building. Remember, if you have any problems please call our dedicated
2
07 Tools Checklist
2
08 Installation Steps
3-4
09 Installation
5-6
10 RF Controller (Optional)
7-8
11 Cleaning & Maintenance
8
12 Guarantee
9
Technical Team.
SHOULD YOU ENCOUNTER ANY PROBLEMS INSTALLING THIS UNIT CALL
10
11
12-22
23
24-26
27
