Installation Steps - Envirovent HeatSava Installation Manual

08

Installation Steps

Step Instruction
1 Read Instructions
2 Boiler flue exclusion zone
3 Use the template to position and orientate the unit
4 Check unit size & wall depth
5 Clearance from walls and ceilings
6 Heat cell cowl orientation
7 Use marking template
8 Drill fixing holes
9 Drill core hole
10 Wall sleeve
11 Rubber wall seal
12 Fit pull cord to suit orientation
13 Fix unit to wall
14 Make electrical connection
15 Check unit is working
16 Fit halo to outside if required
17 Wireless control (optional)
18 Inform building owner/user on how to operate the system
19 Give instructions to end user
AFTER INSTALLING THIS UNIT PLEASE PASS ONTO END USER
DO NOT THROW AWAY
These checks are required to ensure the proper function of this unit.
For EnviroVent Technical help call 0345 27 27 810
