BEFORE SETTING SURFACE CONTROLS
Pan Sensing
The cooking zone sensors located below the cooktop
surface require that certain cookware conditions are met
before the induction cooking zones can operate.
The cooking zone display windows may display a pan
sensing error message. If a cooking zone is activated and
no cookware is detected, the affected induction cooking
zone display window will flash with the last power level
request setting (Figure 5). If the cookware does not meet
the correct conditions, the cooking zones may not heat.
Figure 5: Power boost power level setting
A flashing error message as illustrated in
generated by those conditions. Use
help to correct the problem or problems before attempting
to reactivate any of the cooking zones.
If the problem or problems are not corrected, the affected
cooking zone will automatically deactivate after 3 minutes.
NOTE
It is recommended that you lower the requested power
level setting before correcting the pan sensing message.
10
Figure 5 can be
Figure 6 as a guide to
Correct
• Cookware base material has
good magnetic characteristics.
• Cookware centered correctly
on cooking zone.
• Flat pan bottom and straight
sides.
• Pan size meets or exceeds
the recommended minimum
size for cooking zone.
• Pan rests completely and is
level on the cooktop
surface.
• Pan is properly balanced.
Figure 6: Potential cooking zone Issues
Incorrect
• Cookware base material is
non-magnetic.
• Cookware not centered on
cooking zone.
• Curved or warped pan bottoms
or sides.
• Pan does not meet the minimum
size required (too small) for
cooking zone.
• Pan bottom rests on cooktop
edge.
• Heavy handle tilts pan.
