  • Page 1 D1812PK PORTABLE 8" LCD MONITOR AND DVD PLAYER IN A BAG PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
  • Page 2 An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park”...

  • Page 3: Table Of Contents

    Content A. Introduction ... 4 B. Cautions and Warnings ... 4 C. Contents ... 6 D. Powering and Installation ... 7 E. Vehicle Installation...7 F. Controls, Indicators, and Connectors ... 9 G. Loading and Playing a Disc ... 10 H. Setup... 11 I.

  • Page 4: Introduction

    A. Introduction Thank you for choosing the D1812PK. The main features include a 8" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor, a DVD player and a game controller with 30 built-in games. The unit applies the latest state of the art electronics and is de- signed for use in hotels, offices, vehicles or your home.
  • Page 5 Keep the unit away from an open flame such as,.fire, candle etc,. It is hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type. In order to protect the enviromnent please dispose of the battery properly. Do not use the unit in temperatures higher than 104 degrees Fahrenheit or 40 de- grees Celsius.

  • Page 6: D. Powering And Installation

    C. Contents 1. 1 x 8’’ LCD Monitor & DVD Player 2. 1 x AC to DC Adapter 3. 1 x Remote Control with battery (CR2025) 4. 1 x Instruction Manual 5. 1 x Audio/Video Adapter Cable 6. 1 x DC Power Adapter 7.

  • Page 7: Powering And Installation

    E. Vehicle Installation Make sure that the unit is placed into the bag with the clear plastic covering on the right side of the unit. Load the disc into the DVD compartment and then adjust the retaining cord across the top portion of the unit.
  • Page 8 2. Installing the system between the driver/passenger seat (Refer to Figure 3) 1). Take one strap and connect the latch to the upper metal ring on the left side of the bag. Attach the “S” hook to the same ring after looping the strap around the headrest of the driver’s seat.

  • Page 9: Controls, Indicators, And Connectors

    F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 4) 1) LCD Panel Shut Off Switch 2) Wide Button 3) Stop Button 4) Previous Button 5) Next Button 6) Play Button 7) Menu 8) Up Button 9) Right Button 10) OK/Enter Button 11) Down Button 12) Left Button...

  • Page 10: Loading And Playing A Disc

    2. Remote Control View (Refer to Figure 5) 1) Display Button 2) Angle Button 3) Subtitle Button 4) Audio Button 5) Zoom Button 6) UP/DOWN/LEFT/RIGHT/ ENTER Buttons 7) Return Button 8) A-B Button 9) Forward Button 10) Reverse Button 11) Slow Button 12) Stop Button 13) Numeric Keypad 14) Setup Button...

  • Page 11: Setup

    H. Setup Press ‘SETUP’ to display the Main screen of the Setup Menu on the screen. Press ‘SETUP’ again to exit the Setup Menu and the unit will resume it’s last playback mode. 1) Press “SETUP”, the ‘General Setup Page’ will display on screen. a).Select ‘TV Display’...
  • Page 12 b).Select ‘TV Type’ using the UP/DOWN button, and then press the RIGHT button to enter the submenu. Choose TV Type using the UP/ DOWN button and then press ENTER to confirm the setting. Press the LEFT button to return. c).Select ‘Angle Mark’ using the UP/DOWN buttton, and then press the RIGHT button to enter the submenu.
  • Page 13 d). Select ‘Screen Saver’ using the UP/DOWN button, and then press the RIGHT button to enter the submenu. Choose Screen Saver on or off using the UP/DOWN button and then press ENTER to confirm the setting. Press the LEFT button to return. *On: Enables screen saver *Off: Disables screen saver (off) *NOTE: The DVD player will enter the Screen Saver mode after ap-...
  • Page 14 2) Select “Video Quality Setup”by using the LEFT/RIGHT button, press ENTER to enter the video quality setup page. a).Select ‘Brightness’ by using the UP/DOWN button, then press EN- TER you can change the Brightness by pressing the LEFT/RIGHT button. To exit ‘Brightness’ setting, press ENTER again to return the main Menu.
  • Page 15 To exit ‘Contrast’ Setting, press ENTER again to return the main Menu. c).Select ‘Hue’ by using the UP/DOWN button, then press ENTER you can adjust the Hue by pressing the LEFT/RIGHT button. To exit ‘Hue’ Setting, press ENTER again to return the main Menu. d).Select ‘Saturation’...
  • Page 16 3).Select “Password” using the LEFT/RIGHT button, then press the RIGHT button to enter the submenu. Password Setup Page Screen Display Press ENTER to enter the Password Change Page. Input the Old Password or the Default Password, the New Password, and the Con- firmed New Password.
  • Page 17 4).With no disc inside the player select ‘Preference Page’ using the LEFT / RIGHT buttons, then press ENTER to enter the preference page. a. Select ‘Audio’ using the UP/DOWN button, then press RIGHT to enter the submenu. Select the audio language you desire using the UP/DOWN button, then press ENTER to confirm the setting.
  • Page 18 Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages. If the selected, language is not available, the player will play and display on the screen the original recorded language contained in the disc. c.
  • Page 19 e. Select ‘Default’ using the UP/DOWN button, then press RIGHT to en- ter the submenu. Press ENTER to make the setting return to the fac- tory-set mode. NOTE: The parental setting is not affected by the default reset function. Loading Factory Setting NOTE: The Default Password is 3308.

  • Page 20: Basic Operation

    I. Basic Operation POWER OPEN PLAY SLOW PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS RETURN MENU REPEAT DISPLAY ANGLE SUBTITLE AUDIO ZOOM SETUP PDF created with FinePrint pdfFactory Pro trial version Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Play at 1/2, 1/4, 1/8 or 1/16 times speed Still Picture...

  • Page 21: Menu

    J. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 22 c. Press ‘DISPLAY’ a 3rd time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. d. Press ‘DISPLAY’ a 4th time to display the Remaining Time for the chapter. The heading will disappear automatically in 3 seconds. e.
  • Page 23 Angle Screen Display 3. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘SUBTITLE’ again to select another subtitle lan- guage.
  • Page 24 4. AUDIO During playback press ‘AUDIO’ to select the audio language you desire*, with the current Audio Channel Number (1) and the total num- ber of Audio Channels (2) displayed. Press AUDIO again to select another audio language. The audio display will disappear automati- cally if the ‘AUDIO’...
  • Page 25 6. A-B REPEAT a. During playback press ‘A-B’ once to set the Starting Point A. A-B Repeat Starting Point Screen Display b. Press ‘A-B’ a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point B. A-B Repeat Ending Point Screen Display c.
  • Page 26 7. REPEAT a. During playback press ‘REPEAT’ once to repeatedly play the cur- rent chapter. b. During playback press ‘REPEAT’ twice to repeatedly play the current title. c. During playback press ‘REPEAT’ three times to repeat All Chapters and Titles. PDF created with FinePrint pdfFactory Pro trial version Chapter Repeat Screen Display Title Repeat Screen Display...

  • Page 27: Playing Audio Cds

    d. Press ‘REPEAT’ a 4th time, to resume normal playback. L. Playing Audio CDS When playing an audio CD press the DISPLAY button on the remote to view time information. The options below show you what information is available using this function. a.

  • Page 28: Using The Repeat Feature

    c. Press ‘DISPLAY’ a 2nd time and Total Elapsed appears along with the current track playing and the total time that the CD has been playing. d. Press ‘DISPLAY’ a 3rd time and Total Remain appears along with the current track playing and the amount of time remaining on the CD. e.

  • Page 29: Playing Mp3 Discs

    M. Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song is compressed into the MP3 format with very little loss of audio quality while taking up much less disc space. CD-R /RW discs that have been encoded in MP3 format are compatible with this system.
  • Page 30 Use the (PREVIOUS) button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: • Single • Repeat One • Repeat Folder •...

  • Page 31: Playing Jpeg Files

    N. Playing JPG file 1) Load the JPG Disc into tray. 2) Select JPG file by pressing “UP/DOWN” button. 3) You can preview the JPG file by pressing “Play” or “ENTER”. 4) Pressing the “Left Key“ will rotate the picture 90 degrees counterclockwise.
  • Page 32 i. Press “display” 9th time, “EXTEND FROM CENTER H” will dis- play on the screen, the picture will refresh from horizontal center to both sides. j. Press “display” 10th time, “EXTEND FROM CENTER V” will display on the screen, the picture will refresh from vertical cen- ter to both sides.

  • Page 33: Connecting To A Tv Or Another Monitor

    O. Connecting to a TV or another monitor ( Refer to Figure 6) You can also connect the DVD player to a TV to enjoy high quality stereo audio and video on another monitor. To connect the DVD player to a monitor requires the purchase of an audio/video cable. The cable is readily available at most electronic retailers.

  • Page 34: Specifications

    P. Specifications Compatible DISC: DVD/CD/MP3 Signal system: NTSC/PAL Panel size: 8 inch Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75 Ohm, unbalanced Audio output: 1.4V /10kOhm Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm Power source: DC 9V Power consumption: 12 W...

  • Page 35: Rechargeable Battery Installation And Use

    Q. Rechargeable Battery Installation and Use The player utilizes a set of long-life Ni-Mh batteries for a portable power supply. Ni-MH batteries feature high storage capacity and low level of degradation. This means the Ni-MH batteries do not have “Memory Effect” and thus can be recharged safely regardless of whether the battery is fully or only partially discharged.
  • Page 36 2.Recharge efficiency will degrade when environmental temperatures drop below 50 3. Please remove the battery from the player and store it properly if the player is not to be used for long time. During this period , please recharge the battery at least once every two months to maintain the battery in optimum codition.

  • Page 37: Troubleshooting

    R. Troubleshooting PROBLEM No sound or distorted sound Can’t advance through a movie The icon ( appears on screen Picture is distorted No forward or reverse scan PDF created with FinePrint pdfFactory Pro trial version SOLUTION • Make sure the DVD player is connected properly.

  • Page 38: Troubleshooting (Cont)

    Troubleshooting (Cont) PROBLEM IR sensor inoperative Disc won’t play Play starts, but then stops immediately PDF created with FinePrint pdfFactory Pro trial version SOLUTION • Verify that the batteries in the remote are fresh. • Verify that the remote sensor eye is not obstructed.

  • Page 39: Day Limited Warranty

    AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
