  • Page 1 D1812 PORTABLE 8" LCD MONITOR AND DVD PLAYER...

  • Page 2: Table Of Contents

    Content A. Introduction ... 1 B. Cautions and Warnings ... 1 C. Contents ... 3 D. Powering and installation ... 3 E. Controls, Indicators, and Connectors ... 4 F. Loading and Playing a Disc ... 5 G. Setup... 6 H. Basic Operation ... 15 I.
  • Page 3 Notice: This Product incorporates copyright protection technology that is pro- tected by method claims of certain U.S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights own- ers. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited view- ing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 4: Introduction

    A. Introduction Thank you for choosing the 8” portable DVD player. The main fea- tures include a 8" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in hotels, offices or your home.
  • Page 5 the unit. To ensure proper ventilation and proper operation, never cover or block the slots and openings with a cloth or other material. Keep the unit away from an open flame such as fire, candle etc. It is hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type, in order to protect the enviromnent, please dispose the battery properly.

  • Page 6: Contents

    C. Contents 1. 1 x 8’ ’ LCD Monitor & DVD Player Combo 2. 1 x AC to DC Adapter 3. 1 x Remote Control with battery (CR2025) 4. 1 x Instruction Manual 5. 1 x Audio/Video Cable 6. 1 x Cigarette Lighter Adapter 7.

  • Page 7: Controls, Indicators, And Connectors

    E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 3) 1) LCD Panel Shut Off Switch 2) Wide Button 3) Stop Button 4) Previous Button 5) Next Button 6) Play Button 7) MENU Button 8) Up Button 9) Right Button 10) OK Button 11) Down Button 12) Left Button...

  • Page 8: Loading And Playing A Disc

    2. Remote Control View (Refer to Figure 4) 1) Display Button 2) Angle Button 3) Subtitle Button 4) Audio Button 5) Zoom Button 6) UP/DOWN/LEFT/RIGHT/ ENTER Buttons 7) Return Button 8) A-B Button 9) Forward Button 10) Reverse Button 11) Slow Button 12) Stop Button 13) Numeric Keypad 14) Setup Button...

  • Page 9: Setup

    G. Setup Press ‘ SETUP’ to display the Main screen of the Setup Menu on the screen. Press ‘ SETUP’ again to exit the Setup Menu and the unit will resume it’ s last playback mode. Main Setup Menu Screen 1) Press “...
  • Page 10 b).Select ‘ TV Type’ using the UP/DOWN button, and then press the RIGHT button to enter the submenu. Choose TV Type using the UP/ DOWN button and then press ENTER to confirm the setting. Press the LEFT button to return. TV Type Screen Display c).Select ‘...
  • Page 11 d). Select ‘ Screen Saver’ using the UP/DOWN button, and then press the RIGHT button to enter the submenu. Choose Screen Saver on or off using the UP/DOWN button and then press ENTER to confirm the setting. Press the LEFT button to return. Screen Saver Screen Display *On: Enables screen saver *Off: Disables screen saver (off)
  • Page 12 *On: The unit will return to the last position on the disc. *Off: The unit will not return to the last position on the disc. Note: The Last position memory function only effect for OPEN operation. 2) Select “ Video Quality Setup” by using the LEFT/RIGHT button, press ENTER to enter the video quality setup page.
  • Page 13 b).Select ‘ Contrast’ by using the UP/DOWN button, then press ENTER you can adjust the Contrast by pressing the LEFT/RIGHT button. Contrast Screen Display To exit ‘ Contrast’ Setting, press ENTER again to return the main Menu. c).Select ‘ Hue’ by using the UP/DOWN button, then press ENTER you can adjust the Hue by pressing the LEFT/RIGHT button.
  • Page 14 3).Select “ Password” using the LEFT/RIGHT button, then press the RIGHT button to enter the submenu. Password Setup Page Screen Display Press ENTER to enter the Password Change Page. Input the Old Password or the Default Password, the New Password, and the Con- firmed New Password.
  • Page 15 4).With no disc inside the player select ‘ Preference Page’ using the LEFT / RIGHT buttons, then press ‘ ENTER’ to enter the preference page. a. Select ‘ Audio’ using the UP/DOWN button, then press RIGHT to enter the submenu. Select the audio language you desire using the UP/DOWN button, then press ENTER to confirm the setting.
  • Page 16 c. Select ‘ Disc Menu’ using the UP/DOWN button, then press RIGHT to enter the submenu. Select the Disc Menu Language you desire using the UP/DOWN button, then press ENTER to confirm the setting. Press LEFT to return. Preference Disc Menu Language Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages.
  • Page 17 e. Select ‘ Default’ using the UP/DOWN button, then press RIGHT to en- ter the submenu. Press ENTER to make the setting return to the fac- tory-set mode. NOTE: The parental setting is not affected by the default reset function. Loading Factory Setting NOTE: The Default Password is 3308.

  • Page 18: Basic Operation

    H. Basic Operation POWER OPEN PLAY SLOW PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS RETURN MENU REPEAT DISPLAY ANGLE SUBTITLE AUDIO ZOOM SETUP Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Play at 1/2, 1/4, 1/8 or 1/16 times speed Still Picture (1 time) Stop at the present playing point / (2 times) Stop playing...

  • Page 19: Menu

    I. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 20 c. Press ‘ DISPLAY’ a 3rd time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. Chapter Elapsed Time Screen Display d. Press ‘ DISPLAY’ a 4th time to display the Remaining Time for the chapter.
  • Page 21 Angle Screen Display 3. SUBTITLE During disc playback press ‘ SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘ SUBTITLE’ again to select another subtitle lan- guage.
  • Page 22 4. AUDIO During playback press ‘ AUDIO’ to select the audio language you desire*, with the current Audio Channel Number (1) and the total num- ber of Audio Channels (2) displayed. Press AUDIO again to select another audio language. The audio display will disappear automati- cally if the ‘...
  • Page 23 6. A-B REPEAT a. During playback press first time ‘ A-B’ to set the Starting Point A. A-B Repeat Starting Point Screen Display b. Press ‘ A-B’ second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point B. A-B Repeat Ending Point Screen Display c.
  • Page 24 7. REPEAT a. During playback press ‘ REPEAT’ once to repeatedly play the cur- rent chapter. Chapter Repeat Screen Display b. During playback press ‘ REPEAT’ again to repeatedly play the current title. Title Repeat Screen Display c. During playback press ‘ REPEAT’ a 3rd time to repeat all Chapters and Titles.

  • Page 25: Playing Audio Cds

    d. Press “ REPEAT” a 4th time, to resume normal playback. Repeat Off Screen Display K. Playing Audio CDS When playing an audio CD press the DISPLAY button on the remote to view time information. The options below show you what information is available using this function.

  • Page 26: Using The Repeat Feature

    c. Press ‘ DISPLAY’ a 2nd time and Total Elapsed appears along with the current track playing and the total time that the CD has been playing. Total Elapsed Screen Display d. Press ‘ DISPLAY’ a 3rd time and Total Remain appears along with the current track playing and the amount of time remaining on the CD.

  • Page 27: Playing Mp3 Discs

    L. Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song is compressed into the MP3 format with very little loss of audio quality while taking up much less disc space. CD-R /RW discs that have been encoded in MP3 format are compatible with this system.
  • Page 28 Use the ( NEXT ) button to move to the next song. Press the (PREVIOUS) button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: •...

  • Page 29: Playing Jpg File

    M. Playing JPG file 1) Load the JPG Disc into tray. 2) Select JPG file by pressing “ UP/DOWN” button. 3) You can preview the JPG file by pressing “ Play” or “ ENTER” . 4) Pressing the “ Left Key“ will rotate the picture 90 degrees counterclockwise.
  • Page 30 i. Press “ display” 9th time, “ EXTEND FROM CENTER H” will dis- play on the screen, the picture will refresh from horizontal center to both sides. j. Press “ display” 10th time, “ EXTEND FROM CENTER V” will display on the screen, the picture will refresh from vertical cen- ter to both sides.

  • Page 31: Connecting To A Tv Or Another Monitor

    N. Connecting to a TV or another monitor ( Refer to Figure 42) You can also connect the DVD player to a TV to enjoy high quality stereo sound and picture on another monitor. 1. Slide the AV IN/OUT switch to OUT side, Connect one end of the audio/video cable’...

  • Page 32: Specifications

    O. Specifications Compatible DISC: DVD/CD/MP3 Signal system: NTSC/PAL Panel size: 8 inch Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75 Ohm, unbalanced Audio output: 1.4V /10kOhm Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm Power source: DC 9V Power consumption: 12 W...
  • Page 33 airtight container with desiccant or other dehumidifying agent. Each full recharge takes approximately five-hours and one full charge can provide power to the player for approximately 2 hours. During recharge, the red indicator will stay on. Once fully recharged, the red light will turn off. At this point you may remove the wall plug and stop charging.
  • Page 34 Installing the Battery Pack: 1. First, make sure the player is in “ Stop” mode and that the AC power supply has been disconnected. 2. Close the player cover. 3. Push the battery towards the rear flank of the player until it locks into position.

  • Page 35: Troubleshooting

    Q. Troubleshooting PROBLEM • Make sure your DVD is connected properly. No sound or Make sure all cables are securely inserted distorted sound into the appropriate jacks. • You can’ t advance through the opening credits and warning information that appears Can’...

  • Page 36: Troubleshooting (Cont)

    Troubleshooting (Cont) PROBLEM •Verify that the batteries in the remote are IR sensor fresh. inoperative •Verify that the remote sensor eye is not obstructed. •Verify that the infrared transmitter is affixed over the sensor eye of the com- ponent to be controlled. •...

  • Page 37: Day Limited Warranty

    AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
