Audiovox D1805 Instruction Manual
  1. Manuals
  2. Brands
  3. Audiovox Manuals
  4. Portable DVD Player
  5. D1805
  6. Instruction manual
Audiovox D1805 Instruction Manual

Audiovox D1805 Instruction Manual

Portable 8" lcd monitor and dvd player
Hide thumbs

Advertisement

Quick Links

Download this manual
D1805
PORTABLE 8" LCD MONITOR AND DVD PLAYER
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the D1805 and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox D1805

Summary of Contents for Audiovox D1805

  • Page 1 D1805 PORTABLE 8" LCD MONITOR AND DVD PLAYER...
  • Page 2 A. Introduction Thank you for selecting the D1805 portable DVD player. The main features include a 8" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in hotels, offices, vehicles or your home.
  • Page 3 4.Disassemble Do not attempt to disassemble the cabinet. There is a risk of elec- tric shock and/or exposure to Laser Radiation. Contact qualified service personnel if your system is in need of repair. Cleaning Unit When cleaning, make sure the system is unplugged from the power source.
  • Page 4 D. Powering and installation 1. Powering the system indoors (Refer to Figure 1) Plug one end of the AC to DC adapter into the DC 9V jack on the left side of the main unit, then plug the other end into the 120V AC power socket.
  • Page 5 E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 2) 1) DC 9V Input Jack 2) Audio Jack (L+R) 3) Video Jack 4) AV Input /Output Switch 5) Brightness Control 6) MENU 7) Up button 8) Left Button 9) OK Button 10) Down Button 11) Right Button...
  • Page 6 2. Remote Control View (Refer to Figure 3) 1) Display Button 2) Angle Button 3) Subtitle Button 4) Audio Button 5) Zoom Button 6) UP/DOWN/LEFT/RIGHT/ ENTER Buttons 7) Return Button 8) A-B Button 9) Forward Button 10) Reverse Button 11) Slow Button 12) Stop Button 13) Number Buttons 14) Setup Button...
  • Page 7 G. SETUP Press ‘SETUP’ to display the Main screen of the SETUP Menu on the screen. Press ‘SETUP’ again to exit the SETUP Menu and the unit will resume it’s last playback mode. Figure 7. Main SETUP Menu Screen 1) Press “Setup”, the ‘GENERAL SETUP PAGE’ will display on screen. Figure 8.
  • Page 8 * NORMAL/PS: When the player is connected to a normal TV, and a wide picture is shown on the full screen. * NORMAL/LB: When the player is connected to a normal TV, and a wide picture is shown on the screen with a black strip at both the top and bottom of the screen.
  • Page 9 d). Select ‘SCREEN SAVER’ using the DOWN button. Figure 11. SCREEN SAVER Display *ON: enables screen saver *OFF: disables screen saver (off) *NOTE: The DVD player will enter the Screen Saver mode after approximately five minutes if the same image remains on the screen.
  • Page 10 a).Select “Brightness by using the UP or DOWN buttons ,then press “Enter”you can change the Brightness by pressing the LEFT or RIGHT buttons. To exit “Brightness Setting”, press “Enter”again to return to the main Menu. Figure 14. BRIGHTNESS Screen Display b).Select “Contrast”...
  • Page 11 d).Select “Saturation “ by using the UP or DOWN buttons, then press “Enter” you can adjust the Saturation by pressing the LEFT or RIGHT buttons. Figure 17. SATURATION(Color) Screen Display To exit “Saturation”Setting,press “Enter”again to return to the main Menu 3).With no disc inside the player ,select “password”...
  • Page 12 NOTE: The Default Password is 3308. This password is always effective even after you have selected your own password and changed it. To avoid the possibility of others using the default password to set the parental level and change the password, you can record this default password in another area and delete it from this manual.
  • Page 13 b. Select ‘SUBTITLE’ the using the UP or DOWN buttons, then press RIGHT to enter the submenu. Select the desired subtitle lan- guage or SUBTITLE OFF using the UP or DOWN buttons , then press ‘ENTER’ to confirm the setting. Press ‘LEFT’ to return. Figure 19.
  • Page 14 d. Select ‘PARENTAL’ using the UP or DOWN buttons , then press RIGHT to enter the submenu. Figure 21. PARENTAL Preference Screen Display Select the parental level you desire using the UP or DOWN but- tons for discs with lock-out function or multiple rating levels. These are listed from the lowest level (1 Kid Safe) to the highest level (Adult).
  • Page 15 1. Basic Operation Turn the unit on/off POWER OPEN Remove/load the disc PLAY Start Play/Execute item or setting Play at 1/2, 1/4, 1/8 or 1/16 times speed SLOW PAUSE Still Picture STOP (1 time) Stop at the present playing point / (2 times) Stop playing NEXT Go to the next chapter, track or scene dur-...
  • Page 16 2. MENU A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 17 c. Press ‘DISPLAY’ a 3rd time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. Figure 25. Chapter Elapsed Time Screen Display d. Press ‘DISPLAY’ a 4th time to display the Remaining Time for the chapter.
  • Page 18 Figure 27. Angle Screen Display 3. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle lan- guage you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are multiple languages press ‘SUBTITLE’ again to select another subtitle language.
  • Page 19 4. AUDIO During playback press ‘AUDIO’ to select the audio language you desire*, with the current Audio Channel Number (1) and the total number of Audio Channels (2) displayed. Press AUDIO again to select another audio language. The audio display will disappear automatically if the ‘AUDIO’...
  • Page 20 6. A-B REPEA T a. During playback press ‘A-B’ to set the Starting Point A. Figure 31. A-B Repeat Starting Point Screen Display b.Press ‘A-B’ a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point Figure 32.
  • Page 21 7. REPEAT a. During playback press ‘REPEAT’ once to repeatedly play the cur- rent chapter. Figure 34. Chapter Repeat ON Screen Display b.During playback press ‘REPEAT’ again to repeatedly play the current title. Figure 35. Title Repeat ON Screen Display c.

  • Page 22: Playing Audio Cds

    d. Press “REPEAT” a 4th time, to resume normal play. Figure 37. Repeat Off ON Screen Display 4. PLAYING AUDIO CDS When playing an audio CD press the DISPLAY button on the remote to view time information. The options below show you what information is available using this function.

  • Page 23: Using The Repeat Fea Ture

    c. Press ‘DISPLAY’ two times and TOTAL ELAPSED appears along with the current track playing and the total time that the CD has been playing. Figure 40. TOTAL ELAPSED Screen Display d. Press ‘DISPLAY’ three times and TOTAL REMAIN appears along with the current track playing and the amount of time remaining on the CD.

  • Page 24: Playing Mp3 Discs

    5. PLAYING MP3 DISCS MP3 is a format for storing digital audio. An audio CD-quality song is compressed into the MP3 format with very little loss of audio quality while taking up much less disc space. CD-R /RW discs that have been encoded in MP3 format are compatible with this system.
  • Page 25 Use the ( NEXT ) button to move to the next song. Press the (PREVIOUS) button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: •...
  • Page 26 6. Playing JPEG file 1) Load the JPEG Disc into tray. 2) Select JPEG file by pressing “UP/DOWN” button. 3) You can preview the JPEG file by pressing “Play” or “ENTER”. 4) Pressing the left or right button will rotate the JPEG in that direction.
  • Page 27 k. Press “display” 11th time, “COMPRESS TO CENTER H” will display on the screen, the picture will refresh from top and bot- tom to center. l. Press “display” 12th time, “COMPRESS TO CENTER V” will display on the screen, the picture will refresh from right and left to center.
  • Page 28 7. Playing a Video Game (Refer to Figure 44) 1. Slid the AV in/out button to the “In” position. 2. Plug the video output from your game system into the Audio and video input jack on the left side of the unit. Adjust the volume control and the brightness control on the monitor for individual preference.
  • Page 29 Disc format: DVD/CD/MP3 Color system: NTSC/PAL Screen size: 8’’ Frequency response: DVD (PCM 96 kHz/24 bits ): 20 Hz to 44 kHz DVD (PCM 48 kHz): 20 Hz to 22 kHz CD: 20 Hz to 20 kHz Video output: 1.0 Vp-p/75 Ohm, unbalanced Video S/N: Better than 35 dB Audio S/N: Better than 35 dB Power source: DC 9V 1.5A...
  • Page 30 2. To charge the battery, please connect the power jack directly into the D1805 and leave the POWER switch in the off position. Using and Maintaining your Rechargeable Batteries 1. Please make sure you always use only the AC transformer in- cluded with the player to recharge your batteries.

  • Page 31: Installing The Battery Pack

    Installing the Battery Pack: 1. First, make sure the player is in “Stop” mode and that the AC power supply has been disconnected. 2. Close the player cover. 3. Align the battery pack with the player module’s front edge. 4. Push the battery towards the rear of the player until it locks into position.

  • Page 32: 90-Day Limited Warranty

    90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
  • Page 33 © 2003 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-6920...

This manual is also suitable for:

D1805pk
