  • Page 1 D1810 PORTABLE 8" LCD MONITOR AND DVD PLAYER 128-6925...
  • Page 2 Notice: This Product Incorporates copyright protection technology that is protected by method claims of certain patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless authorized by Macrovision Corporation.
  • Page 3 A. Introduction Thank you for selecting the D1810 portable DVD player. The main features include a 8" Wide Screen (16:9 Aspect Ratio) Liquid Crystal Dis play (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in cars, hotels, office, home or anywhere.
  • Page 4 . Cleaning Unit When cleaning, make sure the system is unplugged from the power source. Do not use liquid cleaners or aerosol cleaners. Use a cloth lightly dampened with water for cleaning the exterior of the system only. 6. Disc Do not use irregularly shaped discs such as heart or star-shaped discs as they may cause the unit to malfunction.
  • Page 5 E. Controls, Indicators, and Connectors 1. Unit View (Refer to Figures 1and 2) 10 Source 11 Menu 12 Return 13 Display 14 Function 15 Up 16 Enter 17 Right 18 Power Figure 1 19 DC IN 9V 20 S Video/Video 21 Audio 22 Headphone 23 Volume...
  • Page 6 1) SOURCE BUTTON 2) MENU (OR SETUP WHEN IN STOP MODE) 3) RETURN BUTTON 4) DISPLAY BUTTON 5) FUNCTION BUTTON (FOR SCREEN ASPECT RATIO, COLOR AND BRIGHTNESS ADJUSTMENT) 6) UP BUTTON 7) ENT. BUTTON (ENTER) 8) RIGHT BUTTON 9) POWER ON/OFF BUTTON 10) DOWN BUTTON 11) LEFT BUTTON 12) FORWARD SCAN BUTTON...
  • Page 7 2. Remote Control View (Refer to Figure 3) Prog. Figure 3...
  • Page 8 Remote Control Function Description Screen: Change the screen aspect ratio. Angle: Switch to a different angle if the DVD contains angle options. Mute: Mute speakers Setup: System setting Display: On screen display of the current disc status Vol. +/-: Volume adjustment 7: Reverse Scan at 2x, 4x or 8x normal playback speed at 2x, 4x or 8x normal playback speed Forward Scan...
  • Page 9 F. Loading and Playing a Disc 1. After connecting power to the unit, power on “DVD player” by holding down the power button* for 2 seconds. 2. Open the disc door by pressing “PUSH OPEN”, place a disc into the tray with the label side of the disc facing up.
  • Page 10 White Red Yellow AUDIO / VIDEO cable Black Yellow Amplifier White S VIDEO cable (Not Supplied) Player(Right Side) Figure 4.-A Fiber Digital AUDIO cable (Not Supplied) Player(Right Side) Stereo Sound AUDIO cable Figure 4.-B...
  • Page 11 H. SETUP Press ‘SETUP’ to display the Main menu of the SETUP Menu on the screen. Press ‘RETURN’ or 'SETUP' to exit the SETUP Menu Figure 5. Main SETUP Menu Screen 1) DISC MENU Select “DISC” using the Left /Right buttons, then press ‘ENTER’ to enter the DISC MENU screen Figure 6.
  • Page 12 a). Select ‘AUDIO LANGUAGE’ using the Up or DOWN buttons, then press ENTER to enter the submenu. Select the desired *audio language using the Up or DOWN buttons. Then press ‘ENTER’ to confirm the setting. Figure 7. Audio Language Setting Screen b).
  • Page 13 Figure 9. Menu language Setting Screen *Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages. If the selected language is not available, the player will play and display on the screen the original recorded language contained in the disc.
  • Page 14 Figure 10. Rating Setting Screen...

  • Page 15: Video Setting

    NOTE: ADULT is the default setting. 2) VIDEO SETTING Select “VIDEO” using the Left/Right buttons, then press ‘ENTER’ to Enter the VIDEO MENU screen. REMARK: You can s et up your Player to work with normal and wide screen televisions. If you are using a wide screen TV, set this option to 16:9 to match the aspect ratio of your TV.

  • Page 16: Dolby Digital Setting

    Figure 12. TV ASPECT Setting Screen b).TV OUTPUT TYPE Note: Model D1810 is NTSC only. Figure 13. TV OUTPUT TYPE Setting Screen 3) DOLBY DIGITAL SETTING Select “DOLBY DIGITAL” using the Left or Right buttons, then press ENTER to enter the submenu.
  • Page 17 DOWN buttons, then press ‘ENTER’ to confirm the setting. Dolby Digital Figure 14. DOLBY DIGITAL Setting Screen...

  • Page 18: Display Setting

    4) DISPLAY SETTING Select “DISPLAY” by using the left or right buttons, then press ENTER to enter the Figure 15. Display Setting Screen Display a). Select MENU LANGUAGE Note: The system operation MENU LANGUAGE is set on ENGLISH only. b). Select ‘ON SCREEN MESSAGE’ using the UP or DOWN buttons, then press ‘ENTER”...

  • Page 19: Other Setting

    OTHER SETTING Select “OTHER” by using the left or right buttons, then press ENTER to enter the submenu. Figure 17. OTHER SETTING Screen Display a).Select ‘LAST MEMORY’ using the UP or DOWN buttons . Press ENTER to enter the submenu. Select NO or YES by using the UP or DOWN buttons , then press ENTER to confirm.

  • Page 20: Basic Operation

    1. BASIC OPERATION POWER OPEN PLAY SLOW PAUSE STOP NEXT PREVIOUS FORWARD REVIEW UP/DOWN/LEFT /RIGHT ENTER NUMBERS RETURN MENU REPEAT DISPLAY ANGLE SUBTITLE ZOOM SETUP SOURCE FUNCTION VOLUME CONTROL Turn the unit on/off Remove/load the disc Start Playback Play at 1/2, 1/4, 1/8 times normal speed Still Picture (1 time) Stop at the present playing point / (2 times) Stop playing...
  • Page 21 2. MENU A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the root menu, and press MENU or PLAY to resume playback.
  • Page 22 Battery status: When using the battery, the Battery Icon is displayed with color; when using AC, the Battery Icon is displayed in gray. Charger status: When the battery is connected and charging, the arrow will point up. When the battery is connected and the AC adapter is not, the arrow will point down.
  • Page 23 6. ZOOM During playback press ‘ZOOM’ to enlarge the picture by 2x. Press “zoom” again; the picture will return to normal. Figure 22. ZOOM Screen Display 7. A-B REPEAT a).During playback press ‘A-B’ to set the Starting Point A. Figure 23. A-B Repeat Screen Display b).Press ‘A-B’...
  • Page 24 c).Press A-B a third time to cancel A-B repeat and resume playback from point A. Figure 25. A-B Repeat Cancel Screen Display 8. REPEAT a. During playback press ‘REPEAT’ once to display the current repeat status. Figure 26. Repeat Status Screen Display b.
  • Page 25 c. Press ‘REPEAT’ a 3rd time to repeatedly play the current chapter. Figure 28. Chapter Repeat ON Screen Display d. Press ‘REPEAT’ a 4th time to repeat all Chapters and Titles. Figure 29. Disc Repeat ON Screen Display e. Press ‘REPEAT’ a 5th time to resume normal playback. 9.
  • Page 26 Wide Mode When viewing a movie recorded in standard 4:3 format for normal TVs, try this setting. A unique horizontal scaling is used to display the image on the full wide screen, where it would otherwise appear stretched horizontally. Normal Mode When viewed on the player’s wide screen display, movies made for standard televisions (4:3 aspect ratio) will appear stretched horizontally.
  • Page 27 Figure 31. Slow 1/2 Screen Display 11. Program CD Play List a).During CD playback, press Title/Prog. to enter the program list. Use the Up or Down buttons to highlight the desired song, then press Enter to confirm the song in the program list.
  • Page 28 properly. For longer periods of storage, please recharge the battery at least once every two months to maintain the battery in its best condition. Please under no circumstances short out the battery, store the battery in a metal container, or leave the battery in a humid or damp environment.
  • Page 29 Figure 33. Installing the DVD Player Battery...
  • Page 30 Removing the Battery Pack: (See Fig 34.) 1. First, make sure the player is in the “Stop” mode and that the AC power supply has been disconnected. 2. Press the release tabs on the sides of the battery. 3. Pull the battery pack to disconnect it from the unit. Figure 34.
  • Page 31 13. Specifications Disc format: DVD/CD Color system: NTSC Screen size: 8.0" Frequency response: DVD (PCM 96 kHz/24 bits ): 20Hz-44KHz DVD (PCM 48 kHz/16 bits): 20Hz-22KHz CD: 20Hz-20KHz Video output: 1.0Vp-p(at 75ohm) Video S/N: > 35dB Audio output: 2 X 0.5W Audio S/N: >...
