Audiovox D1788PK Owner's Manual

7” lcd monitor, dvd player with built-in battery
Hide thumbs

Advertisement

Quick Links

Download this manual
D1788PK
7" LCD MONITOR, DVD PLAYER
WITH BUILT-IN BATTERY

Advertisement

loading
Need help?

Need help?

Do you have a question about the D1788PK and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox D1788PK

Summary of Contents for Audiovox D1788PK

  • Page 1 D1788PK 7” LCD MONITOR, DVD PLAYER WITH BUILT-IN BATTERY...
  • Page 2 Notice: This Product incorporates copyright protection technology that is protected by method claims of certain U.S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
  • Page 3 2. Installation Ensure that the D1788PK is used and installed in accordance with the instructions and illustrations provided in this manual. 3. Objects and Liquids Do not push objects of any kind into the unit through openings;...
  • Page 4 4. Disassembly Do not attempt to disassemble the cabinet. There is a risk of electric shock and/or exposure to Laser Radiation. Contact qualified service personnel if your system is in need of repair. 5. Cleaning Unit When cleaning, make sure the system is unplugged from the power source.
  • Page 5 C. Contents 1. 1 x 7” LCD Monitor and DVD Player 2. 1 x AC to DC Adapter 3. 1 x Remote Control w/Battery (CR2025) 4. 1 x Instruction Manual 5. 1 x Audio/Video Cable 6. 1 x DC Power Adapter 7.
  • Page 6 E. Vehicle Installation Installing the DVD Player onto the seat back in a car (Refer to Figure 2) Carry Bag Closed Elastic Straps Vehicle Headrest Vehicle Seat Back 1). Unfold the carry bag, and place the DVD player on the bag beneath the elastic straps.
  • Page 7 F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure3) 1) Menu Button 2) Up/Down/Left/Right/OK Buttons 3) Open Button 4) Previous/Next/Pause/ Stop/Play Buttons 5) Screen Mode Button 6) Remote Sensor 7) Power Indicator Figure 3 8) Power On/Off Switch 9) Volume Up/Down Control 10) Headphone Jack 1 11) Headphone Jack 2...
  • Page 8 2. Remote Control View (Refer to Figure 4) 1) Setup Button 2) Up Button 3) Previous Button 4) Enter Button 5) Reverse Scan /Left Button 6) Down Button 7) Numeric Keypad 8) Display Button 9) Zoom Button 10) Subtitle Button 11) Next Button 12) A-B Repeat Button 13) Forward Scan /Right Button...
  • Page 9 . SETUP Press ‘SETUP’ to display the Main screen of the SETUP Menu on the screen. Press ‘SETUP’ again to exit the SETUP Menu and the unit will resume it’s last playback mode. 1) Press SETUP, the ‘GENERAL SETUP PAGE’ will display on screen.
  • Page 10 b).Select ‘ANGLE MARK’ using the DOWN button, and then press the ‘ENTER’ button to enter the submenu. Choose Angle Mark on or off using the UP/DOWN buttons and then press ‘ENTER’ to confirm the setting. Press the LEFT button to return. Gen eral Video Ang le Mark Set Angle Mark...
  • Page 11 c). Select ‘SCREEN SAVER’ using the DOWN button. Gen eral Video Ang le Mark Screen Saver Screen Display *ON: enables screen saver *OFF: disables screen saver (off) *NOTE: The DVD player will enter the Screen Saver mode after approximately five minutes if the same image remains on the screen.

  • Page 12: Video Setup Page

    2) Select ‘VIDEO’ by using the LEFT/RIGHT buttons, press ‘ENTER’ to enter the VIDEO SETUP PAGE. Video Quality Setup Screen Display a).Select ‘BRIGHTNESS’ by using the UP or DOWN buttons ,then press ‘ENTER’. Adjust the Brightness by pressing the LEFT or RIGHT buttons.
  • Page 13 3). Select ‘Password’ using the LEFT or RIGHT buttons, then press the ‘ENTER’ button to enter the PASSWORD SETUP PAGE.submenu. Password Setup Page Screen Display Press ‘ENTER’ twice to enter the PASSWORD CHANGE PAGE. Input the Old Password or the Default Password, the New Pass- word, and the Confirmed New Password.
  • Page 14 4).With no disc inside the player select ‘PREFEREN’ using the LEFT or RIGHT buttons, then press ‘ENTER’ to enter the PREFERENCE PAGE . a). Select ‘AUDIO’ using the DOWN button, then press ‘ENTER’ to enter the submenu. Select the audio language you desire using the UP or DOWN buttons, then press ‘ENTER’...
  • Page 15 b). Select ‘SUBTITLE’ using the DOWN button, then press ‘ENTER’ to enter the submenu. Select the desired subtitle lan- guage or SUBTITLE OFF using the UP or DOWN buttons, then press ‘ENTER’ to confirm the setting. Press the LEFT button to return.
  • Page 16 d). Select ‘PARENTAL’ using the DOWN button, then press ‘ENTER’ to enter the submenu. Parental Preference Screen Display Select the parental level you desire using the UP or DOWN but- tons for discs with lock-out function or multiple rating levels. These are listed from the lowest level (1 KID SAFE) to the highest level (ADULT).
  • Page 17 I. Basic Operation POWER OPEN PLAY PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS MENU REPEAT DISPLAY ANGLE SUBTITLE AUDIO ZOOM SETUP Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Still Picture (1 time) Stop at the present playing point / (2 times) Stop playing Go to the next chapter, track or scene dur- ing play back...
  • Page 18 J. MENU A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press ‘MENU’...
  • Page 19 Angle Screen Display 3. SUBTITLE During disc playback press ‘SUB’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are multiple languages press ‘SUB’ again to select another subtitle lan- guage.
  • Page 20 3. SUBTITLE During disc playback press ‘SUB’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are multiple languages press ‘SUB’ again to select another subtitle lan- guage.
  • Page 21 4. AUDIO During playback press ‘AUDIO’ to select the audio language you desire*, with the current Audio Channel Number (1) and the total number of Audio Channels (2) displayed. Press AUDIO again to se- lect another audio language. The audio display will disappear auto- matically if the ‘AUDIO’...
  • Page 22 6. A-B REPEAT a. During playback press ‘A-B’ to set the Starting Point A. A-B Repeat Starting Point Screen Display b. Press ‘A-B’ a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point A-B Repeat Ending Point Screen Display c.
  • Page 23 7. REPEAT a. During playback press ‘1/ALL’ once to repeatedly play the current chapter. Chapter Repeat ON Screen Display b.During playback press ‘1/ALL’ again to repeatedly play the current title. Title Repeat ON Screen Display c. During playback press ‘1/ALL’ a third time to repeat all Chapters and Titles.

  • Page 24: Forward/Reverse Scan

    d. Press ‘1/ALL’ a fourth time, to resume normal play. 8. FORWARD/REVERSE SCAN a. During playback press 32x and normal speed. b. During playback press 32x and normal speed. L. PLAYING AUDIO CDS When an CD disc is inserted into the unit, the Menu Screen appears. You can use Up and DOWN button to choose the song you desire.

  • Page 25: Using The Repeat Feature

    1. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing ‘1/ALL’ consecutively changes the repeat options: • Repeat one- repeats the track that is playing. • Repeat All- repeats the disc that is playing. • Repeat Off As you toggle through the options, the repeat option changes.
  • Page 26 When an MP3 disc is inserted into the unit, the Menu Screen appears automatically. You can use the Menu Screen to change folders and songs. The system plays the songs in the order they were burned onto the disc. 1. Press the 2.
  • Page 27 N. Playing JPEG files 1) Load the JPEG disc into tray. You player will display a folder and the contents of the folder. 2) Pressing the “MENU” button will return to the Photo Menu. You can choose the picture you desire by using the “UP” and “DOWN” buttons and pressing “ENTER”.
  • Page 28 2. Connecting Optional Headphones Simply plug the optional headphones into either Headphone 1 jack or Headphone 2 jack on the right side of the DVD Player. (Refer to Figure 6) Plugging into Headphone jack 1 will disable the internal speakers. P .
  • Page 29 Q. Built-In Rechargeable Battery The DVD player utilizes a long-life Li-Polymer battery for portability. Li-Polymer batteries feature high storage capacity and low level of degradation. This means the Li-Polymer batteries do not have “Memory Effect” and thus can be recharged regardless of whether the battery is fully or only partially discharged.

  • Page 30: 90-Day Limited Warranty

    90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within ninety (90) days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
  • Page 31 © 2008 Audiovox Electronics Corporation 128-8374...
