- Page 1 CPRO-12ES 1 by 2 HDMI Scaler Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........1 6. Hardware Description ......2 6.1 Front Panel ........2 6.2 Rear Panel .........3 6.3 OSD MENU .........4 7. -
Page 6: Introduction
1. INTRODUCTION The 1 by 2 HDMI Scaler is designed to scale both 4K2K and non-4K2K HDMI signal into 1080p and also, bypass 4K2K signal out on to 4K2K display. Allowing all types of HDMI source signal to be display on HDTV/ Monitor. -
Page 7: Hardware Description
6. HARDWARE DESCRIPTION The following sections describe the hardware components of the unit. 6.1 Front Panel HDMI OUT HDMI IN DC 5V SERVICE 2 SCALER BYPASS HDMI OUT/SCALER: This slot is to connect with HDMI TV/display for output AV displaying with resolution up to 1080p. BYPASS: This slot is to connect with HDMI TV/display with or without 4K2K specification for output AV displaying according to input source signal setting. -
Page 8: Rear Panel
6.2 Rear Panel RS-232 SERVICE 1 BYPASS POWER 4K2K MENU ENTER 720p RS-232: This slot is reserve for factory use only. SERVICE 1: This slot is reserve for factory use only. POWER LED: This LED will illuminate when the device is connected with power supply. -
Page 9: Osd Menu
6.3 OSD MENU Layer Layer Layer Layer Contrast 0~100 Brightness 0~100 0~100 Saturation 0~100 Sharpness 0~100 Off/ FineTune Picture High/ Setting Middle/ Exit 0~100 Green 0~100 Color Blue 0~100 Exit Output Full/Over Scan/Under Scan/Letter Size Setting Box/Pan Scan/Best Fit 640x480/60,800x600/60,1024x768/... - Page 10 TimerOut 5~100 Background 0~100 Display Info/On/Off Exit Factory Reset No/Yes Setting Exit Information Input …x… Output …x… Version x.xx Exit ...
-
Page 11: Connection Diagram
7. CONNECTION DIAGRAM DVD or Blu-ray Player HDMI OUT HDMI IN DC 5V SERVICE 2 SCALER BYPASS HD TV HD TV... -
Page 12: Specifications
8. SPECIFICATIONS Video Frequency 300MHz/9Gbps Input Ports 1 x HDMI, 2 x USB (Service only), 1 x RS-232 (Service only) Output Ports 2 x HDMI HDMI Cable Distance In 15M, Out 15M@1080p/8bit, In 10M, Out 10M@1080p/12bit, In 5M, Out 10M@4K2K Power Supply 5V / 2.6A DC (US/EU standards, CE/FCC/ UL certified) - Page 13 HDMI Supported Resolutions Input Output 640x480@60 640x480@72 640x480@75 720x480@60 720x480i@60 720x576i@50 720x576p@50 800x600@56 800x600@60 800x600@72 800x600@75 1024x768@60 1024x768@70 1024x768@75 1280x720@60 1280x720p@60 1280x800@60 1280x1024@60 1440x1050@60 1600x1200@60 1920x1080@60 1920x1080i@50 1920x1080i@60 1920x1080p@23.97 1920x1080p@24 1920x1080p@25 1920x1080p@29.97 1920x1080p@30 1920x1080p@50...
- Page 14 1920x1080p@60 1920x1200@60(RB)
- Page 16 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-CPRO12ES...
