Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Quick Setup Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Connections, Buttons, and LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Communication Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Important Product Warnings & Safety Instructions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
How to Contact Key Digital®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Always follow the instructions provided in this Operating Manual.
Please check the Key Digital Website for the most up-to-date Manual.
© 2016 Key Digital, Inc. All rights reserved.

Introduction

Key Digital
®
KD-Pro2x1/KD-Pro4x1 HDMI switchers are designed and engineered to
offer the best in quality, performance, and reliability, while providing a cost-effective
HDMI switching solution. The KD-Pro2x1/KD-Pro4x1 HDMI switchers are capable of
switching 2/4 independent Inputs/Sources to 1 Output/Zone and feature de-embedding
of HDMI audio for external distribution. KD-Pro2x1/KD-Pro4x1 support all SD, HD, VESA
and Ultra HD/4K video standards, including UHD/4K, 1080p/60, 1920x1200, 3D, and
support of HDCP 2.2 and HDR.
About the KD-Pro2x1/KD-Pro4x1
HDMI Switching: 2/4 HDMI sources to 1 HDMI output
HDCP Licensing: Fully licensed and compatible with HDCP 2.2
Resolution Support: Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA,
SXGA, UXGA)
Ultra HD/4K Support: 4096x2160 or 3840x2160 30Hz at 4:4:4 and 60Hz at 4:4:4
HDR (High Dynamic Range): More life-like images through a greater range of
luminance levels
Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
Audio De-Embedder: Audio from the selected HDMI input is de-embedded through
the Coax digital (PCM) or Analog L/R Balanced/Unbalanced
3D Ready: Capability to pass 3D stereoscopic signal formats
Full Buffer System
: Manages TMDS re-clocking / signal re-generation,
HDCP authentication to source & display, and EDID Control handshake
EDID: Internal library with 15 default EDID handshakes for inputs, in addition to native
EDID data for Output/Display
TMDS re-clocking: Support for long HDMI connectivity using Key Digital
Lossless Compressed Digital Audio: Dolby
Audio
, and Dolby Atmos
Control: Front panel buttons/LEDs, Trigger In, Serial IR, Optical IR, RS-232 Control,
and TCP/IP Control
Control System Support: Key Digital
®
by all IR, RS-232, and TCP/IP supported control systems via open API.
Accessories
Power Supply: KD-PS5V2ASC, 5V/2A, 100-240VAC, 50-60Hz, Interchangeable head,
screw-type connector
Rack Ears
Remote Control
(2) 6-Pin Terminal Blocks
HDMI cables
®
TrueHD, Dolby
Digital Plus, DTS-HD Master
®
®
App ready. Compass Control
ready. Fully controllable
®
1
