INT-88HDX
Installation Guide

Rear Panel

A
IR OUT
IR OUT
IR OUT
1
2
3
4
5
6
INPUT
INPUT
INPUT
E
A.
IR output ports for each source device
B.
IR input ports for each HDBaseT output
C.
RS232 control input
D.
AC power input
E.
HDMI inputs
F.
Output Zone
i.
HDBaseT outputs with PoH support
ii.
HDMI outputs (1, 2, 3 and 4 only)
iii.
RS232 input for each HDBaseT output
iv.
Unbalanced analog audio output ports
G.
TCP/IP (Ethernet) control input; also allows control via web browser; IR input for matrix when front
is covered or matrix is located in a concealed location (IR EYE); IR input to send IR commands to all
remote HDBaseT devices simultaneously (IR ALL IN)
H.
Ground screw
8
B
IR IN
IR IN
IR OUT
7
8
1
2
3
RS232
AUDIO
RS232
AUDIO
RS232
INPUT
OUTPUT 1
OUTPUT 2
F
IR IN
IR IN
IR IN
4
5
6
AUDIO
RS232
AUDIO
RS232
AUDIO
RS232
OUTPUT 3
OUTPUT 4
OUTPUT 5
IR IN
IR IN
IR IN
7
8
AUDIO
RS232
AUDIO
RS232
AUDIO
OUTPUT 6
OUTPUT 7
OUTPUT 8
C
D
G
H
