- Page 1 VIPA System 100V CM | Manual HB100E_CM | Rev. 13/05 January 2013...
- Page 2 Copyright © VIPA GmbH. All Rights Reserved. This document contains proprietary information of VIPA and is not to be disclosed or used except in accordance with applicable agreements. This material is protected by the copyright laws. It may not be reproduced, distributed, or altered in any fashion by any entity (either internal or external to VIPA), except in accordance with applicable agreements, contracts or licensing, without the express written consent of VIPA and the business management owner of the material.
-
Page 3: Table Of Contents
Safety information ..................2 Chapter 1 Basics ................1-1 Safety information for Users..............1-2 Overview System 100V ................ 1-3 General Description of the System 100V..........1-4 Assembly dimensions................1-5 Installation guidelines ................1-7 Chapter 2 Hardware description and deployment ......2-1 Overview .................... - Page 4 Contents Manual VIPA System 100V HB100E - CM - Rev. 13/05...
-
Page 5: About This Manual
Manual VIPA System 100V About this manual About this Manual This manual describes the terminal modules CM 101 of the System 100V from VIPA. Outline Chapter 1: Basics These basics include recommendations on the handling of the modules of the VIPA System 100V as central resp. decentral automation system. - Page 6 About this manual Manual VIPA System 100V Objective and This manual describes the installation and usage of the terminal modules CM 101 of the System 100V. contents This manual is relevant for: Product Order number as of state: CM 101...
-
Page 7: Safety Information
Manual VIPA System 100V Safety information Safety information The System 100V is constructed and manufactured for Applications conforming with • communication and process control specifications • general control and automation applications • industrial applications • operation within the environmental conditions specified in the technical data •... - Page 8 Safety information Manual VIPA System 100V HB100E - CM - Rev. 13/05...
-
Page 9: Chapter 1 Basics
These basics include recommendations on the handling of the modules of Overview the VIPA System 100V as central resp. decentral automation system. Besides a system overview you will find general information of the System 100V like assembly dimensions, installation and environmental conditions. -
Page 10: Safety Information For Users
Chapter 1 Basics Manual VIPA System 100V Safety information for Users VIPA modules make use of highly integrated components in MOS- Handling of technology. These components are extremely sensitive to over-voltages electrostatic that can occur during electrostatic discharges. sensitive modules... -
Page 11: Overview System 100V
Manual VIPA System 100V Chapter 1 Basics Overview System 100V The System 100V from VIPA is a compact central and decentral usable General automation system from VIPA. The system is recommended for lower and middle performance needs. At a System 100V module, CPU res. bus coupler are integrated together with in-/output functions in one case. -
Page 12: General Description Of The System 100V
• Dimensions basic module: 4tier width: (WxHxD) in mm: 101.6x76x48 / in inches: 4x3x1.9 6tier width: (WxHxD) in mm: 152.4x76x48 / in Inches: 6x3x1.9 The installation of a System 100V module works via snapping on a norm Installation profile head rail. -
Page 13: Assembly Dimensions
Manual VIPA System 100V Chapter 1 Basics Assembly dimensions Installation dimensions Installed and 45 mm 44 mm wired dimensions 34 mm 48 mm ca. 70 mm HB100E - CM - Rev. 13/05... - Page 14 Chapter 1 Basics Manual VIPA System 100V CPU 11x with 51 mm 50 mm EasyConn from 45 mm VIPA 11 mm 5 mm 85 mm 8 cm HB100E - CM - Rev. 13/05...
-
Page 15: Installation Guidelines
The installation guidelines contain information about the interference free General deployment of System 100V. There is the description of the ways, interference may occur in your control, how you can make sure the electromagnetic digestibility (EMC), and how you manage the isolation. - Page 16 - Please take care for the targeted employment of the grounding actions. The grounding of the PLC is a protection and functionality activity. - Connect installation parts and cabinets with the System 100V in star topology with the isolation/protected earth conductor system. So you avoid ground loops.
- Page 17 Manual VIPA System 100V Chapter 1 Basics Isolation of Electrical, magnetically and electromagnetic interference fields are weakened by means of an isolation, one talks of absorption. conductors Via the isolation rail, that is connected conductive with the rack, interference currents are shunt via cable isolation to the ground. Hereby...
- Page 18 Chapter 1 Basics Manual VIPA System 100V 1-10 HB100E - CM - Rev. 13/05...
-
Page 19: Chapter 2 Hardware Description And Deployment
Hardware description and deployment This chapter contains every information for the deployment of the terminal Overview modules of the System 100V. The terminal modules are not connected to the backplane bus and they are deployed as passive stand-alone components. For example actively supplied sensors may be connected by means of these modules. -
Page 20: Overview
Chapter 2 Hardware description and deployment Manual VIPA System 100V Overview Terminal modules are passive modules where the contacts inside are Description vertically electrical connected. Using terminal modules, you may easily realize a distributor for your power supply and have the option to connect active supplied sensors like e.g. -
Page 21: 101-4Fh50 - 8X11Com
Manual VIPA System 100V Chapter 2 Hardware description and deployment 101-4FH50 - 8x11COM Structure Position X1 Position X2 Position X3 Position X4 2x11 COM 2x11 COM 2x11 COM 2x11 COM CM 101 VIPA 101-4FH50 Circuit diagram HB100E - CM - Rev. 13/05... - Page 22 Chapter 2 Hardware description and deployment Manual VIPA System 100V Technical data Order no. 101-4FH50 Type CM 101 Clamp parameter Terminal voltage max. DC 60 V Terminal current max. 10 A Total current per module, max. Isolated group Number of clamps...
