- Page 1 M1 and M2 POS Motherboard (with BIOS Setup) User Manual (Edition May 2017)
- Page 2 Please send us a copy of this page if you have any constructive criticism. We would like to thank you in advance for your comments. With kind regards, Your opinion: Wincor Nixdorf International GmbH Documentation R&D BLN 2 Wohlrabedamm 31 D-13629 Berlin E-Mail: retail.documentation@wincor-nixdorf.com...
- Page 3 M1 and M2 POS Motherboard User Manual Edition May 2017...
- Page 4 All brand and product names mentioned in this document are trademarks of their respective owners. Copyright © Wincor Nixdorf International GmbH, 2017 The re production, transmission or use of this document or its contents is not permitted without express authority. Offenders will be liable for damages. All rights, including rights created by patent grant or registration of a utility model or design, are reserved.
-
Page 5: Table Of Contents
Overview ..................7 Introduction ..................7 Some Highlights of the M1 and M2 Motherboard ......7 Motherboard Specification ............9 Mainboard assembly variants ............9 Block Diagram .................. 10 CPU support ..................11 Mainboard internal connectors and onboard features ....12 Memory (internal) ............... - Page 6 Product Name: ................40 System, Mainboard, Power Supply: ..........40 Main Menu .................. 41 System Information ................41 Open source software license information ........41 System Language................41 System date ..................42 System time..................42 M1 and M2 Motherboard, User Manual...
- Page 7 XHCI Hand-off [Disabled] ............. 52 Port 60/64 Emulation [Enabled] ..........52 USB transfer time-out ..............52 Device reset time-out ..............52 Device power-up delay ..............52 USB Port Security................. 52 Hardware Monitor ................53 M1 and M2 Motherboard, User Manual...
- Page 8 Lock Legacy Resources [Disabled] ..........62 S3 Video Repost [Disabled] ............62 OEM Settings ..................63 RTC Lock [Enabled] ..............63 BIOS Lock [Enabled] ..............63 Prevent External NVRAM Module [Enabled] ....... 63 Intel Ethernet Connection ..............64 M1 and M2 Motherboard, User Manual...
- Page 9 Boot Override .................. 76 Test Points Codes ................. 77 Checkpoint Ranges ................77 Standard Checkpoints ..............78 Phase SEC ..................78 PEI Phase ..................79 PEI Beep Codes ................82 DXE Phase ..................82 M1 and M2 Motherboard, User Manual...
- Page 10 OEM-Reserved Checkpoint Ranges ..........86 Abbreviations ................87 M1 and M2 Motherboard, User Manual...
-
Page 11: Overview
This manual describes the features of two variants of a Motherboard based on the Intel 100 series chipset Q170 and H110, formerly known as Skylake. These M1 and M2 Motherboards were primarily designed for the Wincor Nixdorf POS System BEETLE /M-III. - Page 12 MiniPCIe socket (full size) supporting the WN NVRAM module M.2 (PCIe x4/SATA) on M1 1x PS2 (KBD/MS) 2 USB3.0 ports up to 10 USB2.0 ports (H110: 6 ports) TFT- displays without DDC are not supported. M1 and M2 Motherboard, User Manual...
-
Page 13: Motherboard Specification
Motherboard Specification Mainboard assembly variants As mentioned above there are two motherboard variants: The M1 board with Q170 chipset supporting AMT, RAID, M.2 and mPCIe and the M2 board with H110 chipset as value edition supporting lesser features. M1 and M2 Motherboard, User Manual... -
Page 14: Block Diagram
PCI Express x1 Q170 / H110 Up to 10 USB2.0 1Gb LAN Ports I219LM/I219V PCI Express x1 / USB3.0 SATAIII 2x USB3.0 Ports mSATA/miniPCIe TPM Header Up to 6x COM BIOS 64/128Mbit NCT6106D PS/2 PS/2 M1 and M2 Motherboard, User Manual... -
Page 15: Cpu Support
CPU support Base CPU# #CPU #Threads Cache (Turbo) core size Freqency i5 (Kaby Lake) i5-7500 3.4 (3.8) i5 (Skylake) i5-6500 3.2 (3.6) i3 (Kaby Lake) i3-7101E I3 (Skylake) I3-6100 Pentium (Skylake) G4400 Celeron (Skylake) G3900 M1 and M2 Motherboard, User Manual... -
Page 16: Mainboard Internal Connectors And Onboard Features
The amount of installed memory that can be used may vary based on the BIOS settings and the used OS. Total Video memory size up to 1536MB of the installed memory. (Pre-allocated Video memory size up to 1GB) M1 and M2 Motherboard, User Manual... -
Page 17: Serial Ports (Internal)
This output is designed according to UL regulations and is protected by a self-resettable fuse. COM1 is a standard 9 pin DSUB connector in I/O shield. 2x 6 pin header, 2.54 mm pitch Signal Key Pin +5 V +12 V M1 and M2 Motherboard, User Manual... -
Page 18: Lpt (Internal)
SLCT USB 2.0 (internal) 7 USB ports at M1 board and 3 USB ports at M2 are routed to 10pin double row headers with 2.54 mm pitch. These headers are intended to connect optional front USB modules or USB hubs. -
Page 19: Mini Pci Express /Msata (Internal)
The interface (SATA or PCIe) is automatically detected using Pin 51 of the mSATA connector (GND = SATA; N.C = PCIe). PCIe functionality is only supported on M1 motherboard. Connector type: Standard MiniPCIe connector full size M1 and M2 Motherboard, User Manual... -
Page 20: Internal)
The M.2 connector supports M.2 Key M modules with SATA or PCIe up to x4 interface and a size of 2260 and 2280. The interface (SATA or PCIe) is automatically detected using the PEDET Pin 69 of the M.2 connector (GND = SATA; N.C = PCIe). M1 and M2 Motherboard, User Manual... -
Page 21: Sata (Internal)
(white) and SATA1 (blue) and SATA2 (black) supporting SATA III connectivi- ty speed. SATA3 port is connected to mSATA connector and SATA4 port is connected to M.2 connector. The RAID functionality is only supported by the M1 motherboard. TPM (internal) Trusted Platform Modules are a Trusted Computing Group (TCG) security solution to increase the system security. -
Page 22: Pci Express Slots (Internal)
(orange) is on System is off. ‘Power On’ LED is off Deep Sleep ‘Sleep’ LED (orange) is ‘Power On’ LED is blink- Failure in Power Supply 4x short then repeated after intermission 100ms on/ 900ms M1 and M2 Motherboard, User Manual... - Page 23 The BIOS is able to disable the power button during S0. Then it is not pos- sible to shut down the system by the power button, even when pressed longer than 4s. Power on from S5 is still possible. M1 and M2 Motherboard, User Manual...
-
Page 24: Chassis Intrusion Connector (Internal)
This is detected, even if no AC is connected. However, this will not be indicated until the system is operating again. Type: 3 pin shrouded header, B3B-PH-K-S (JST) or equivalent. Pin Number Function Intrusion input (switch to GND if chassis is open) n.c. M1 and M2 Motherboard, User Manual... -
Page 25: Clear Cmos Jumper (Internal)
1000 or similar. The connector follows the Intel “4-Wire Pulse Width Modulation (PWM) Controlled Fans” specification. PWM Fan Signal Signal Description 12 V Fan operation voltage Sense Tachometric signal Control PWM control signal (only 4 pin connector) M1 and M2 Motherboard, User Manual... -
Page 26: Atx / 12V Power Connector (Internal)
In this case the pins 11,12,23 and 24 are not used and left open. The 4 pin ATX power connector has to be connected to the PSU anyway, otherwise the motherboard will not work. M1 and M2 Motherboard, User Manual... -
Page 27: Voltage Regulator
180 MHz pixel clock rate at 24 bpp, or up to 240 MHz pixel clock rate at 18 bpp Display Modes: Single Display, Display Clone, Extended Desktop: 3 Independent displays on M1 only M1 and M2 Motherboard, User Manual... -
Page 28: Audio
Realtek ALC 671 Default Audio Codec Ports Remark: System Beeps are audible on Line_Out1 at Rear Connector. Supported Sleep States Normal Operation (“ON”) Suspend to RAM / “Stand By” Suspend to Disk / “Hibernation” Soft Off M1 and M2 Motherboard, User Manual... -
Page 29: System Wake Up
In this state the System can be switched on by power button or RTC WakeUp only. BIOS Flash devices SPI Flash Size Vendor Type [Mbit] Macronix MX25L6450FM2I-10G Winbond W25R64FVSIQ Micron N25Q064A13ESE4MF Macronix MX25L12850FM2I-10G Winbond W25R128FVSIQ Micron MT25QL128ABA1ESE-MSIT M1 and M2 Motherboard, User Manual... -
Page 30: Mainboard Onboard Connectors With External Access
TMDS Data 1+ TMDS Data 1+ TMDS Data shield TMDS Data shield n.c. +12V n.c. +12V +5V SB Hotplug detect Hotplug detect TMDS Data 0- TMDS Data 0- TMDS Data 0+ TMDS Data 0+ M1 and M2 Motherboard, User Manual... - Page 31 2.5A. This voltage rail is only enabled if a monitor DDC identification is passed and a PL2-capable monitor was detected, e.g. vendor ID is Wincor Nixdorf (05dh 0d8h) and device ID is in the range of 30000…34999.
-
Page 32: Vga (External)
Four USB ports (two for USB2.0 and two for USB3.0) are located in the mainboard I/O connector area. Audio (external) The mainboard supports a microphone-in (pink), a line-out (green) and a line-in (blue) connector in I/O shield. The connector type is stereo 3.5mm diameter. M1 and M2 Motherboard, User Manual... -
Page 33: Power Supply Requirements
Main power +12V +/- 5% 0,05A 8A/12A supply -12V +/- 10% 0,0A 0,3A +/- 5% 0,2A +3,3V +/- 5% 0,0A 0,5A Auxiliary +5V AUX +5% / -3% 0,0A 2,5A power M1 and M2 Motherboard, User Manual... -
Page 34: Power Load Ability
Intel Skylake PCH SMBus Slave Address A0h 1010 000xb EEPROM of the DIMM 1, channel A Module 1 A4h 1010 010xb EEPROM of the DIMM 1, channel B Module 2 C8h 1100 100xb Management Engine (iAMT) M1 and M2 Motherboard, User Manual... -
Page 35: Frequency And Bandwidth Overview
SATA 2 1500 300 MB/s SATA 3 3000 600 MB/s HD-Audio LPC-Bus USB (low-, full-, high 2500 1,5Mb/s \ 12Mb/s \ speed, SuperSpeed) 480Mb/s \ 5Gbit/s Real time clock 32,768 kHz SMBus 100 kHz M1 and M2 Motherboard, User Manual... -
Page 36: Raid (M1 Motherboard)
RAID (M1 Motherboard) The M1 motherboard provides RAID functionality for the SATA interface. Raid level 0 (striping), 1 (mirroring) and 5 (striping with distributed parity) are supported. For RAID 5 three HDD/SSD devices are needed. To enable the RAID functionality please see the corresponding chapter in the BIOS setup description. -
Page 37: Technical Data
9x USB 2.0 (M1) 5x USB 2.0 (M2) Expansion Slots 2x PCIe x1 Gen3 1x PCIe x16 Gen3 1x MiniPCIe (on M1 only)+mSATA, additional LPC signals 1x M.2 M key (PCIe x4/SATA) 1x TPM pin header Motherboard 2x Plink2.0 / DVI-D... - Page 38 Internal I/O Con- 4x USB 2.0 headers supporting 7 total USB (M1) nectors 2x USB 2.0 headers supporting 3 total USB (M2) 1x PCIe x16 2x PCIe x1 1x MiniPCIe 1x M.2 2x DDR4 SODIMM 3x SATA 1x CPU fan 4pin...
-
Page 39: Changing The Battery
Downloads/POSLotterySystems/Manuals/manuals_node.html The lithium battery must be replaced only by identical batteries or types recommended by Wincor Nixdorf International. You can return the used batteries to your Wincor Nixdorf International sales outlet. Batteries containing harmful substances are marked accordingly. The chemical denotations are as follows: CD = Cadmium; Pb = Lead, Li = Lithium. -
Page 40: Uefi Bios Setup
UEFI BIOS Setup The mainboard M1.x-Q170-uATX and M2.x-H110-uATX comes with an AMI UEFI BIOS chip that contains the ROM Setup information of your system. This chip serves as an interface between the processor and the rest of the mainboard’s components. This section explains the information contained in the Setup program and tells you how to modify the settings according to your system configuration. -
Page 41: Bios Menu Bar
Use this menu to exit the current menu or specify how to exit the Setup program. To access the menu bar items, press the right or left arrow key on the keyboard until the desired item is highlighted. M1 and M2 Motherboard, User Manual... -
Page 42: Legend Screen
When a scroll bar appears to the right of a help window, it indicates that there is more information to be displayed that will not fit in the window. Use <PgUp> and <PgDn> or the up and down keys to scroll through the en- tire help document. M1 and M2 Motherboard, User Manual... -
Page 43: Sub-Menu
Specific Help window located to the right side of each menu. This window displays the help text for the currently highlighted field. Info Screen When the Setup program is accessed, the following info screen appears: M1 and M2 Motherboard, User Manual... -
Page 44: Bios Revision
This text is fixed for your mainboard with standard UEFI BIOS. This board is called “M1.x-Q170-uATX” or “M2.x- H110-uATX” System, Mainboard, Power Supply: The default placeholders may be replaced by specific data from factory, describing configuration, serial number etc. for each device. M1 and M2 Motherboard, User Manual... -
Page 45: Main Menu
Open source software license information This submenu provides the licence information for the open source soft- ware that is used in this system board. System Language Specifies the language used in the BIOS Setup. M1 and M2 Motherboard, User Manual... -
Page 46: System Date
System date Set the date. Use Tab to switch between date elements. Default ranges: Year: 2005-2099 Days: dependent on month System time Set the time. Use Tab to switch between time elements. M1 and M2 Motherboard, User Manual... -
Page 47: Advanced Menu
The advanced functions which are available to the system are configured in this menu for the advanced system configuration. Only change the default settings if required for a special purpose. Incorrect settings can cause malfunctions. M1 and M2 Motherboard, User Manual... -
Page 48: Onboard Devices Configuration
The LAN Controller on the system board is not available. Azalia HD Audio [Enabled] Allows the onboard Azalia HD (High Definition) audio controller to be enabled. Enabled The onboard audio controller is enabled. Disabled The onboard audio controller is disabled. M1 and M2 Motherboard, User Manual... -
Page 49: Cpu Configuration
The virtualisation technology enhances the processor support for virtuali- sation purposes on the over 16 bit and 32 bit protected modes and on the Intel® Extended Memory 64 Technology (EM64T) mode. M1 and M2 Motherboard, User Manual... -
Page 50: Vt-D [Enabled]
Select the Aparture Size Note: Above 4GB MMIO BIOS assignment is auto- matically enabled when selecting 2048MB aperture. To use this feature, please disable CSM Support. CPU AES [Enabled] Enable/Disable AES (Advanced Encryption Standard). M1 and M2 Motherboard, User Manual... -
Page 51: Drive Configuration
This will configure the mode of the SATA controllers. Possible is AHCI or RAID mode. Aggressive Link Power Management [Enabled] Allows in AHCI Mode to enable Aggressive Link Power management (ALPM) to save energy. M1 and M2 Motherboard, User Manual... -
Page 52: Smart Settings
SMART Settings Smart Self Test [Disabled] Run SMART Self Test on all HDDs during POST. M1 and M2 Motherboard, User Manual... -
Page 53: Csm Configuration
Launch Storage OpROM Policy [Legacy only] Controls the execution of UEFI and Legacy Video OpROM. Other PCI device ROM priority [Legacy only] For PCI devices other than Network, Mass storage or Video defines which OpROM to launch. M1 and M2 Motherboard, User Manual... -
Page 54: Trusted Computing
TPM Device Selection [PTT] Selects TPM device: PTT or dTPM. Enables PTT in SkuMgr dTPM 1.2 Disables PTT in SkuMgr Warning! PTT/dTPM will be disabled and all data saved on it will be lost. M1 and M2 Motherboard, User Manual... -
Page 55: Usb Configuration
USB. Booting the operating system from a USB device is possible. Auto Legacy USB support will be disabled if no USB devices are connected. M1 and M2 Motherboard, User Manual... -
Page 56: Ps/2 Emulation [Enabled]
Host Controller. AUTO uses default value time: for a Root port it is 100 ms, for a Hub port, the delay is taken from Hub descriptor. USB Port Security Configures USB ports according to device classes. Any disabled USB ports are also not available under the operating system. M1 and M2 Motherboard, User Manual... -
Page 57: Hardware Monitor
Hardware Monitor M1 and M2 Motherboard, User Manual... -
Page 58: Super Io Configuration
The parallel port is not available. Enabled The parallel port is available. Device Mode Change here the printer port mode: STP Printer Mode SPP Mode EPP 1.9 and SPP Mode EPP 1.7 and SPP Mode M1 and M2 Motherboard, User Manual... -
Page 59: Serial Port Console Redirection
Serial Port Console Redirection Console Redirection [Disabled] Enable or disable the COM Console Redirection. M1 and M2 Motherboard, User Manual... -
Page 60: Amt Configuration
Opens the submenu to configure Intel® Active Management Technology. ME Version Shows the current AMT/ME version. Intel AMT [Enabled] Enables/Disables Intel (R) Active Management Technology BIOS Extension. iAMT H/W is always enabled. This option simply controls the execution of the BIOS Extension. M1 and M2 Motherboard, User Manual... -
Page 61: Usb Provisioning Of Amt [Disabled]
Enable MEBx selection screen with 2 options: Press 1 to initiate a remote connection Note: Network Access must be activated from MEBx Setup for this screen to be displayed. PET Progress [Enabled] Enable/Disable PET events progress to receive PET events. M1 and M2 Motherboard, User Manual... -
Page 62: Asf Support [Enabled]
ASF support [Enabled] Enable/Disable Alert Standard Format support. WatchDog [Disabled] Enable/Disable WatchDog timer. M1 and M2 Motherboard, User Manual... -
Page 63: Network Stack Configuration
Enable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot option will not be created. Ipv6 PXE Support [Enabled] Enable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot option will not be created. M1 and M2 Motherboard, User Manual... -
Page 64: Graphics Configuration
Primary Display Selects which graphics controller has connected the primary display. Internal Graphics The BIOS detects automatically if the internal graphics controller can be disabled, but it can manually be forced to enabled or disabled. M1 and M2 Motherboard, User Manual... -
Page 65: Dvmt Shared Memory Size
DVMT Shared Memory Size Select DVMT 5.0 pre-allocated (fixed) memory size used by the internal graphics controller. DVMT Total Graphics Memory Size Select DVMT 5.0 total memory size used by the internal graphics controller. M1 and M2 Motherboard, User Manual... -
Page 66: Acpi Settings
Select the highest ACPI sleep state the system will enter when SUSPEND button is pressed. Lock Legacy Resources [Disabled] Enables or Disables Lock Legacy Resources. S3 Video Repost [Disabled] Enable or Disable S3 Video Repost. M1 and M2 Motherboard, User Manual... -
Page 67: Oem Settings
Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. BIOS Lock [Enabled] Enable/Disable the PCH BIOS Lock Enable feature. Required to be enabled to ensure SMM protection of flash Prevent External NVRAM Module [Enabled] For using NVRAM set to Disabled. M1 and M2 Motherboard, User Manual... -
Page 68: Intel Ethernet Connection
Intel Ethernet Connection NIC Configuration Click to configure the network device port. Link Speed Specifies the port speed for the selected boot protocol. M1 and M2 Motherboard, User Manual... -
Page 69: Security
UEFI BIOS Setup menu. To clear the password, highlight this field and press <Enter>. Enter your current password. Then you will be asked to enter the new password. Press <Enter> and the password will be deleted. M1 and M2 Motherboard, User Manual... -
Page 70: Intrusion Detection [Disabled]
Changing the system firmware version is possible only if Enabled or Restricted. Enabled Windows Update (WU) and BIOS update tools can change/update the system firmware version. Restricted Only BIOS update tools can change/update the system firmware version. Windows Update (WU) is blocked. M1 and M2 Motherboard, User Manual... -
Page 71: Secure Boot Configuration
Configuration options: [Disabled] [Enabled] Secure Boot Mode [Standard] This is the secure mode selector. The ‘Custom’ mode enables user to change the Image Execution policy and mange Secure Boot Keys Configuration options: [Standard] [Custom] M1 and M2 Motherboard, User Manual... -
Page 72: Power
Last State Switch to the state the system was in before power failure. USB Power[Always off] When the system is switched off (S4/S5 the USB-Ports): [Always Off] Remain powered off [Always ON] Remain powered on M1 and M2 Motherboard, User Manual... -
Page 73: Wake-Up Resources
If enabled, any PS/2 keyboard button press will power on the system USB power option must be enabled to support PS/2 power on. Wake On Time [Disabled] Allows the system to be switched on via an internal timer. M1 and M2 Motherboard, User Manual... -
Page 74: Power Control
OS, but you can enable system from S5 RMT Button Display1 [Enabled] Enable or disable the remote button of display1. RMT Button Display2 [Enabled] Enable or disable the remote button of display2. M1 and M2 Motherboard, User Manual... -
Page 75: Event Logs
The SMBIOS event Log is deleted once during the next system boot up. Afterwards, this option is automati- cally reset to No. Yes, every reset The SMBIOS event log is deleted every time the sys- tem is booted. M1 and M2 Motherboard, User Manual... - Page 76 The SMBIOS event log must first be deleted before new entries can be added. Erase Immediately When the SMBIOS event log is full, it will be erased immediately. All existing entries will be deleted! M1 and M2 Motherboard, User Manual...
-
Page 77: Boot
NumLock is disabled, the numeric keypad keys can be used to control the cursor. The Num indicator light on your keyboard shows the current boot up Num- Lock state. The Num key on the keyboard can be used to toggle between ON and OFF. M1 and M2 Motherboard, User Manual... -
Page 78: Quiet Boot
Every entry (from #1 till #7) specifies a boot group. Each boot device found while POST is running will be sorted in one of a BBS group. Enter a BBS group to swap the boot order of the BBS device. M1 and M2 Motherboard, User Manual... -
Page 79: Save & Exit
Save Changes and Power off Powers off the system after saving changes. Changed Power Settings be- come effective after next Power On. M1 and M2 Motherboard, User Manual... -
Page 80: Restore Defaults
RAM. Boot Override With this option choose a boot device that is listed below this menu entry. Every entry specifies a boot device that enumerate during POST. M1 and M2 Motherboard, User Manual... -
Page 81: Test Points Codes
0x90 – 0xCF BDS execution 0xD0 – 0xDF DXE errors 0xE0 – 0xE8 S3 Resume (PEI) 0xE9 – 0xEF S3 Resume errors (PEI) 0xF0 – 0xF8 Recovery (PEI) 0xF9 – 0xFF Recovery errors (PEI) M1 and M2 Motherboard, User Manual... -
Page 82: Standard Checkpoints
South Bridge initialization after microcode loading 0x0A OEM initialization after microcode loading 0x0B Cache initialization SEC Error Codes 0x0C – 0x0D Reserved for future AMI SEC error codes 0x0E Microcode not found 0x0F Microcode not loaded M1 and M2 Motherboard, User Manual... -
Page 83: Pei Phase
Memory initialization (other). 0x30 Reserved for ASL (see ASL Status Codes section below) 0x31 Memory Installed 0x32 CPU post-memory initialization is started 0x33 CPU post-memory initialization. Cache initialization 0x34 CPU post-memory initialization. Application Processor(s) (AP) initialization M1 and M2 Motherboard, User Manual... - Page 84 CPU self test failed or possible CPU cache error 0x59 CPU micro-code is not found or micro-code update is failed 0x5A Internal CPU error 0x5B reset PPI is not available 0x5C PEI phase BMC self-test failure M1 and M2 Motherboard, User Manual...
- Page 85 Reserved for future AMI progress codes Recovery Error Codes 0xF8 Recovery PPI is not available 0xF9 Recovery capsule is not found 0xFA Invalid recovery capsule 0xFB – 0xFF Reserved for future AMI error codes M1 and M2 Motherboard, User Manual...
-
Page 86: Pei Beep Codes
0x6D North Bridge DXE initialization (North Bridge module specific) 0x6E North Bridge DXE initialization (North Bridge module specific) 0x6F North Bridge DXE initialization (North Bridge module specific) 0x70 South Bridge DXE initialization is started M1 and M2 Motherboard, User Manual... - Page 87 USB Enable 0x9E – 0x9F Reserved for future AMI codes 0xA0 IDE initialization is started 0xA1 IDE Reset 0xA2 IDE Detect 0xA3 IDE Enable 0xA4 SCSI initialization is started 0xA5 SCSI Reset 0xA6 SCSI Detect M1 and M2 Motherboard, User Manual...
- Page 88 Invalid password 0xD9 Error loading Boot Option (LoadImage returned error) 0xDA Boot Option is failed (StartImage returned error) 0xDB Flash update is failed 0xDC Reset protocol is not available 0xDD DXE phase BMC self-test failure M1 and M2 Motherboard, User Manual...
- Page 89 System is waking up from the S4 sleep state 0xAC System has transitioned into ACPI mode. Interrupt controller is in PIC mode. 0xAA System has transitioned into ACPI mode. Interrupt controller is in APIC mode. M1 and M2 Motherboard, User Manual...
- Page 90 OEM SEC initialization after microcode loading 0x1D – 0x2A OEM pre-memory initialization codes 0x3F – 0x4E OEM PEI post memory initialization codes 0x80 – 0x8F OEM DXE initialization codes 0xC0 – 0xCF OEM BDS initialization codes M1 and M2 Motherboard, User Manual...
- Page 91 Dynamic Video Memory Technology Digital Video Interface EBDA Extended BIOS Data Area Extended Capabilities Port EEPROM Electrical Erasable Read Only Memory Extensible Firmware Interface E-IDE Enhanced Integrated Drive Electronics Expanded Memory System ESCD Extended System Configuration Data M1 and M2 Motherboard, User Manual...
- Page 92 POST Power On Self Test Random Accessible Memory Ring Indicator Read Only Memory Retail Systems SATA Serial AT Attachment (new version of hard disk interface) System Locked Pre-Installation System Management Interrupt System Management Mode M1 and M2 Motherboard, User Manual...
- Page 93 SPGA Staggered Pin Grid Array Thin-film transistor Trusted Platform Module UEFI Unified Extensible Firmware Interface Uninterruptible Power Supply Universal Serial Bus UUID Universal Unique Identifier Video Graphics Array Wake On LAN Wake On Modem M1 and M2 Motherboard, User Manual...
- Page 95 Wincor Nixdorf International GmbH D-33094 Paderborn Order No.: 01750297725A...
