K1 and K2 POS Motherboard
(with BIOS Setup)
User Manual (Edition June 2017)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wincor Nixdorf K1

Summary of Contents for Wincor Nixdorf K1

  • Page 1 K1 and K2 POS Motherboard (with BIOS Setup) User Manual (Edition June 2017)

  • Page 2: Table Of Contents

    Overview ..................6 Introduction ..................6 Some Highlights of the K1 and K2 Motherboard ....... 6 Motherboard Specification ............7 Block Diagram ..................7 Internal Connectors ................8 Mainboard assembly variants ............9 CPU support ..................9 Mainboard internal connectors and onboard features ..... 9 Serial ports (internal) ..............
  • Page 3 Sub-Menu ..................28 Info Screen ..................28 Product Name: ................29 BIOS Version: ................29 Ethernet MAC Address: ............... 29 UUID Info: ..................29 System, Main board, Power Supply: ........... 29 Main Menu .................. 30 System Date [MM/DD/YYYY] ............30 System Time [XX: XX: XX].............
  • Page 4 Hardware Prefetcher [Enabled] ........... 38 Adjacent Cache Line Prefetch [Enabled]........38 CPU AES * [Enabled] ..............39 Boot performance mode [Max Non-Turbo Performance] ... 39 EIST [Enabled] ................39 Intel TXT (LT) Support * [Disabled] ..........39 Sub Menu  SATA Configuration ............. 40 SATA Controller(s) [Enabled] ............
  • Page 5 Sub Menu  NTC6106D Super IO Configuration  Parallel Port Configuration ................47 Sub Menu  NTC6106D H/W Monitor ..........48 Sub Menu  Intel TXT Information..........49 Sub Menu  Serial Port Console Redirection ........49 Console Redirection [Enabled] ..........49 Sub Menu ...
  • Page 6 DXE Phase ..................65 DXE Beep Codes ................68 Abbreviations ................69...
  • Page 7 Please send us a copy of this page if you have any constructive criticism. We would like to thank you in advance for your comments. With kind regards, Your opinion: Wincor Nixdorf International GmbH Documentation R&D BLN Wohlrabedamm 31 D-13629 Berlin E-Mail: retail.documentation@wincor-nixdorf.com...
  • Page 8 K1 and K2 POS Motherboard User Manual Edition May 2017...
  • Page 9 All brand and product names mentioned in this document are trademarks of their respective owners. Copyright © Wincor Nixdorf International GmbH, 2017 The re production, transmission or use of this document or its contents is not permitted without ex- press authority. Offenders will be liable for damages. All rights, including rights created by patent grant or registration of a utility model or design, are reserved.
  • Page 11 Contents Overview ..................6 Introduction ..................6 Some Highlights of the K1 and K2 Motherboard ....... 6 Motherboard Specification ............7 Block Diagram ..................7 Internal Connectors ................8 Mainboard assembly variants ............9 CPU support ..................9 Mainboard internal connectors and onboard features ..... 9 Serial ports (internal)..............
  • Page 12 Display Output to COM [Disabled] ..........35 Restore AC Power Loss [Power Off]..........35 Bootorder Menu [Enabled] ............36 VT-d [Enabled] ................36 Sub Menu  CPU Configuration ............37 Hyper-threading [Enabled] ............37 K1 and K2 Motherboard, User Manual...
  • Page 13 WatchDog [Disabled] ..............45 Sub Menu  USB Configuration ............45 Legacy USB Support [Enabled] ............ 46 USB3.0 Support [Enabled] ............46 XHCI Hand-off [Enabled].............. 46 EHCI Hand-off [Enabled] .............. 46 XHCI Mode [Auto] ............... 46 K1 and K2 Motherboard, User Manual...
  • Page 14 Sub Menu  Security Menu  Secure Boot menu ..... 59 Save & Exit Menu ................60 Discard Changes and Exit ............. 60 Save Changes and Reset .............. 60 Discard Changes and Reset ............60 Restore Defaults ................61 K1 and K2 Motherboard, User Manual...
  • Page 15 Test Points Codes ................61 Checkpoint Ranges ..............61 SEC Phase ..................62 PEI Phase ..................62 PEI Beep Codes ................65 DXE Phase ..................65 DXE Beep Codes ................68 Abbreviations ................69 K1 and K2 Motherboard, User Manual...

  • Page 16: Overview

    This manual describes the features of two variants of a Motherboard based on the Intel 8 series chipset Q87 and H81, formerly known as Lynx Point. Some Highlights of the K1 and K2 Motherboard 4th Generation Intel® Core™ Processors, formerly known as Haswell ...

  • Page 17: Motherboard Specification

    USB2.0 Q87 / H81 PCI Express x1 Up to 10 USB2.0 1Gb LAN Ports I217LM/I217V USB3.0 PCI Express x1 2x USB3.0 Ports miniPCIe TPM Header Up to 6x COM BIOS 64/128Mbit NCT6106D PS/2 PS/2 K1 and K2 Motherboard, User Manual...

  • Page 18: Internal Connectors

    Internal Connectors K1 and K2 Motherboard, User Manual...

  • Page 19: Mainboard Assembly Variants

    Mainboard assembly variants As mentioned above there are two motherboard variants: The K1 board with Q87 chipset supporting AMT and RAID and the K2 board with H81 chipset as value edition supporting lesser features. CPU support CPU# #CPU #Threads GHz...

  • Page 20: Usb 2.0 (Internal)

    +12 V USB 2.0 (internal) 8 USB ports at K1 board and 4 USB ports at K2 are routed to 10pin double row headers with 2.54 mm pitch. Each header provides 2 ports. These headers are intended to connect optional front USB modules or USB hubs.

  • Page 21: Mini Pci Express

    PCIe functionality (PCIe functionality only supported in conjunction with Q87 chipset according to mini PCI Express Standard Rev 1.1). The K1 motherboard supports PCIe and mSATA functionality, the K2 motherboard supports mSATA functionality only. Connector type: Standard MiniPCIe 1.1 connector full size...

  • Page 22: Memory (Internal)

    The mainboard provides three standard SATA ports. The ports SATA1 (white) and SATA2 (blue) supporting SATA III connectivity speed. Port SATA3 (black) supports SATA III speed at K1 board, and SATA II speed at K2 board. The RAID functionality is only supported by the K1 motherboard.

  • Page 23: Chassis Intrusion Connector (Internal)

    4s. But when the OS is shut down correctly, system can be switched on again by the power button. The front panel header also supports speaker connection. K1 and K2 Motherboard, User Manual...

  • Page 24: Atx / 12V Power Connector (Internal)

    Pin Number Function +12V A 20 pin ATX power cable can be plugged into the 24 pin connector on the motherboard, too. In this case the pins 11,12,23 and 24 are not used and K1 and K2 Motherboard, User Manual...

  • Page 25: Lpt (Internal)

    Connector type: 26 pin shrouded header, 2.54mm pitch Function Function STR# AFD# ERR# PINIT# ACK# LPT_SLIN# BUSY SLCT The mainboard supports one dedicated TPM port. This connector slot is placed on top and is accessable without removing any other components. K1 and K2 Motherboard, User Manual...

  • Page 26: Pci Express Slots (Internal)

    The PCIe slot at the outer side of the mainboard supports USB signals on PCIe pins A5 (D-) and A8 (D+) as USB uplink connection and A6+A7 (VBUS) to Retail specific PCIe card. The same USB port is routed to the USB3 connector. K1 and K2 Motherboard, User Manual...

  • Page 27: Mainboard Onboard Connectors With External Access

    The PanelLink 2.0 interface is based on a DVI-I connector and uses DVI-D signals. There is no analog VGA connection even if it is a DVI-I connector. Unused pins of the connector are connected to USB signals. K1 and K2 Motherboard, User Manual...
  • Page 28 TMDS CLK+ TMDS CLK- TMDS CLK- n.c. (red) n.c. (green) n.c. (Blue) USB- n.c. (HSYNC) USB+ The +12V signals are protected by a self-resettable fuse and are able to deliver a current of 2.5A. K1 and K2 Motherboard, User Manual...
  • Page 29 This voltage rail is only enabled if a monitor DDC identification is passed and a PL2-capable monitor was detected, e.g. vendor ID is Wincor Nixdorf (05dh 0d8h) and device ID is in the range of 30000…34999. This output is designed according to UL regulations as limited power out- put.

  • Page 30: Vga (External)

    Four USB ports (two for USB2.0 and two for USB3.0) are located in the mainboard I/O connector area. Audio (external) The mainboard supports a microphone-in, a line-out and a line-in connector in I/O shield. The connector type is stereo 3.5mm diameter. K1 and K2 Motherboard, User Manual...

  • Page 31: Technical Data

    10x USB 2.0 (K1) 6x USB 2.0 (K2) Expansion Slots 2x PCIe x1 1x PCIe x16 slot 1x MiniPCIe 1.1 (used by K1 only), additional LPC signals 1x TPM slot Motherboard Ex- 2x Plink2.0 / DVI-D Audio: ternal I/O Con- 1x LAN (RJ45) + 2x USB3.0...

  • Page 32: Supported Sleep States

    Internal I/O Con- 4x USB 2.0 headers supporting 2 ports each (K1) nectors 2x USB 2.0 headers supporting 2 ports each (K2) 1x PCIe x16 2x PCIe x1 1x MiniPCIe, v1.1 2x DDR3 SODIMM 3x SATA 1x CPU fan 4pin...

  • Page 33: Raid (K1 Motherboard)

    RAID (K1 Motherboard) The K1 motherboard provides RAID functionality for the SATA interface. Raid level 0 (striping), 1 (mirroring) and 5 (striping with distributed parity) are supported. For RAID 5 three HDD/SSD devices are needed. To enable the RAID functionality please see the corresponding chapter in the BIOS setup description.

  • Page 34: Changing The Battery

    Downloads/POSLotterySystems/Manuals/manuals_node.html The lithium battery must be replaced only by identical batteries or types recommended by Wincor Nixdorf International. You can return the used batteries to your Wincor Nixdorf International sales outlet. Batteries containing harmful substances are marked accordingly. The chemical denotations are as follows: CD = Cadmium; Pb = Lead, Li = Lithium.

  • Page 35: Uefi Bios Setup

    UEFI BIOS Setup The mainboard K1.x-Q87-uATX-STD and K2.x-H81-uATX-STD comes with an AMI UEFI BIOS chip that contains the ROM Setup information of your system. This chip serves as an interface between the processor and the rest of the mainboard’s components. This section explains the information contained in the Setup program and tells you how to modify the settings according to your system configuration.

  • Page 36: Bios Menu Bar

    The right frame displays the key legend. The keys in the legend frame allow you to navigate through the various setup menus. The following table lists the keys found in the legend with their corresponding alternates and functions. K1 and K2 Motherboard, User Manual...

  • Page 37: General Help

    Use <PgUp> and <PgDn> or the up and down keys to scroll through the en- tire help document. Press <Home> to display the first page, press <End> to reach the last page. To exit the help window, press the <Enter> or <Esc> key. K1 and K2 Motherboard, User Manual...

  • Page 38: Sub-Menu

    Wincor Nixdorf Info Page Product Name: #.#-###-uATX-STD Bios Version: xx/yy Bios Date: MM/DD/YYYY Ethernet MAC-Address: AC-DC-FA-DE-BE-EF UUID: d716af80-6f0a-1018-8789-fbd248a1242f System: --------------------------- --- ------------------------------ ###--------------------------------------------------------- Mainboard: --------------------------- --- ------------------------------ -------------------------------------------------------------- Power Supply: --------------------------- --- ------------------------------ -------------------------------------------------------------- K1 and K2 Motherboard, User Manual...

  • Page 39: Product Name

    Product Name: This text is fixed for your mainboard with standard UEFI BIOS. This board is also called “K1.x-Q87-uATX-STD” or “K2.x- H81-uATX-STD” BIOS Version: The UEFI BIOS version is displayed in the WN release format xx/yy The UEFI BIOS Date is displayed the date of release in international format:...

  • Page 40: Main Menu

    On the upper right frame find the keys listed to modify the values. Processor and Chipset Information This enters a Sub-Menu with summaries of used processor and chipset. K1 and K2 Motherboard, User Manual...

  • Page 41: Advanced Menu

    Intel TXT Information  Serial Port Console Redirection  Network Stack Configuration  CMOS  Intel(R) Ethernet Network Connection  Driver Health Sub Menu ACPI Settings  ACPI Settings Enable ACPI Auto Configuration [Enabled] K1 and K2 Motherboard, User Manual...

  • Page 42: Enable Acpi Auto Configuration [Enabled]

    TPM State [Disabled] This option changes the actual state of the security module. Select the TPM operation after the next automated reboot of the system. Pending operation [None] [None]: The TPM state will be untouched. K1 and K2 Motherboard, User Manual...

  • Page 43: Sub Menu  Hardware Configuration

    Wake On LAN [Disabled] This allows enabling or disabling power up the BEETLE when the LAN con- troller receives a call while the BEETLE is in Soft-Off or Hibernate mode. Configuration options: [Disabled] [Enabled]. K1 and K2 Motherboard, User Manual...

  • Page 44: Wake On Ring [Disabled]

    Configuration options: [Disabled] [Enabled]. Wake On LAN (S3) [Disabled] Enable or Disable wakeup system via LAN while the system is in S3. If set to [Auto] it will follow OS related settings. Configuration options: [Disabled] [Enabled]. K1 and K2 Motherboard, User Manual...

  • Page 45: Wake-On Modes

    [Last State] reboots the system automatically if it was active before power loss. [Follow AC Power] will start up anytime power is available. The front button will be disabled to prevent an accidental shutdown. K1 and K2 Motherboard, User Manual...

  • Page 46: Bootorder Menu [Enabled]

    This option enables or disables the popup menu to change the boot order by pressing F10 during POST. [Enabled] Popup menu is available during POST [Disabled] Popup menu is not available during POST VT-d [Enabled] Check to enable VT-d function on MCH Configuration options: [Disabled] [Enabled]. K1 and K2 Motherboard, User Manual...

  • Page 47: Sub Menu  Cpu Configuration

    Configuration options: [Disabled] [Enabled]. Active Processor Cores [All] This option enables all or several cores of an Intel processor. The numbers of cores are depends of used processor type. Configuration options: [All] [Number of cores 1-x]. K1 and K2 Motherboard, User Manual...

  • Page 48: Overclocking Lock [Disabled]

    Adjacent Cache Line Prefetch [Enabled] The processor has a hardware adjacent cache line prefetch mechanism that automatically fetches an extra 64-byte cache line whenever the pro- cessor requests for a 64-byte cache line. This reduces cache latency by K1 and K2 Motherboard, User Manual...

  • Page 49: Cpu Aes * [Enabled]

    This option enables or disables the Enhanced Intel SpeedStep Technology of an Intel processor. Configuration options: [Disabled] [Enabled]. Intel TXT (LT) Support * [Disabled] Intel Trusted Execution Technology (TXT) is supported by several Intel processors. Configuration options: [Disabled] [Enabled] K1 and K2 Motherboard, User Manual...

  • Page 50: Sub Menu  Sata Configuration

    SATA Mode selection [AHCI] This option selects the SATA controller mode. The option [RAID] is only available on K1 boards with Q87 Chipset. Configuration options: [AHCI] [IDE] [RAID]. Following two menu items are only available if SATA Mode selection is set...

  • Page 51: Sata 0, 1, 5

    ME FW Version 9.1.1.1000 ME Firmware Mode Normal Mode ME Firmware Type Full Sku Firmware ME Firmware SKU NFC Capability State [Disabled] MEBx Type [None] MDES BIOS State Code [Disabled]  Firmware Update Configura- tion K1 and K2 Motherboard, User Manual...

  • Page 52: Intel Me (Management Engine) Subsystem

    Intel ME (Management Engine) Subsystem Intel ME (Management Engine) Subsystem is a separated microcontroller embedded in the chipset driven by a special firmware. For systems with K1 mainboard the ME handles an own setup and can be entered while booting the system by pressing the keys CTRL + P.

  • Page 53: Sub Menu  Amt Configuration

    Sub Menu  AMT Configuration Intel® Active-Management-Technology is a technology for remotely managing and securing PCs out-of-band. Intel AMT is only available at K1 mainboards. Intel AMT [Enabled] BIOS Hotkey Pressed [Disabled] MEBx Selection Screen [Disabled] Hide Un-Configure ME Confirmation...

  • Page 54: Mebx Selection Screen [Disabled]

    Configuration options: [Disabled] [Enabled] USB Configure [Disabled] This option enables or disables the USB configuration function. Configuration options: [Disabled] [Enabled] PET Progress [Enabled] This option enables or disables the PET events progress. Configuration options: [Disabled] [Enabled] K1 and K2 Motherboard, User Manual...

  • Page 55: Watchdog [Disabled]

    Enable USB 3.0 pins [Disable all Pins] USB Ports Per-Port Disable Control [Disabled] USB Mass Storage Driver Support [Enabled] PORT 60/64 Emulation [Enabled] USB Hardware delays and time outs: Device power- up delay [Auto) K1 and K2 Motherboard, User Manual...

  • Page 56: Legacy Usb Support [Enabled]

    This option enables or disables the USB Mass storage driver support. Configuration options: [Disabled] [Enabled] PORT 60/64 Emulation [Enabled] This option enables or disables the I/O port 60/64h emulation support. Configuration options: [Disabled] [Enabled] K1 and K2 Motherboard, User Manual...

  • Page 57: Device Power-Up Delay [Auto]

    Sub Menu  NTC6106D Super IO Configuration  Parallel Port Configuration Parallel Port [Enabled] This option enables or disables parallel port (LPT/LPTE). Configuration options: [Disabled] [Enabled] Change Settings [Auto] This option selects several settings for parallel port (LPT/LPTE). K1 and K2 Motherboard, User Manual...

  • Page 58: Sub Menu  Ntc6106D H/W Monitor

    : +12.096 V AVCC : +3.312 V VCC3V : +3.376 V VSB3 : +3.348 V VBAT : +3.056 V The H/W Monitor is only an information screen which shows all system temperatures, voltages and fan speeds. K1 and K2 Motherboard, User Manual...

  • Page 59: Sub Menu  Intel Txt Information

     Legacy Console Redirection Settings Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection [Enabled]  Console Redirection Settings Console Redirection [Enabled] This option enables or disables the console redirection. Configuration options: [Disabled] [Enabled] K1 and K2 Motherboard, User Manual...

  • Page 60: Sub Menu  Serial Port Console Redirection  Console Redirection Settings

    Bits per second [VT-UTF8] This option selects the serial port transmission speed. Configuration options: [9600] [19200] [57600] [115200] Flow Control [None] This option selects the serial port flow control. Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff] K1 and K2 Motherboard, User Manual...

  • Page 61: Sub Menu  Network Stack Configuration

    Sub Menu  CMOS CMOS Settings/Information Bad battery detected: [False] First boot detected [False] Defaults loaded [False] Bad checksum detected [False] The CMOS menu is only an information screen which shows some specific CMOS information. K1 and K2 Motherboard, User Manual...

  • Page 62: Sub Menu  Intel(R) Ethernet Network Connection

    Half] [100 Mbps Full]. Wake On LAN [Enabled] This allows enabling or disabling power up the BEETLE when the LAN controller receives a call while the BEETLE is in Soft-Off or Hibernate mode. Configuration options: [Disabled] [Enabled]. K1 and K2 Motherboard, User Manual...

  • Page 63: Chipset Menu

    This option enables or disables the BIOS lock enable (BLE) bit. Configuration options: [Disabled] [Enabled] BIOS Interface Lock [Enabled] This option handles the NVRAM access. For using a NVRAM module set this option to [Disabled]. Configuration options: [Disabled] [Enabled] K1 and K2 Motherboard, User Manual...

  • Page 64: Sub Menu  System Agent (Sa) Configuration

    This option sets the Graphics Turbo IMON current value. Configuration options: 14-31 Primary Display [Auto] This option selects which graphics device IGFX, PEG, PCI should be the primary display. Configuration options: [Auto] [IGFX] [PEG] [PCIE] K1 and K2 Motherboard, User Manual...
  • Page 65 This option is application for SFF only Configuration options: [Disabled] [Enabled] Internal Graphics Port Order [VGA>Disp.1>Disp.2] This option selects which device may be used as primary display first Configuration options: [VGA>Disp.1>Disp.2] [Disp.1>Disp.2>VGA] [VGA>Disp.2>Disp.1] [Disp.2>Disp.1>VGA] [Disp.1> VGA>Disp.2] [Disp.2> VGA>Disp.1] K1 and K2 Motherboard, User Manual...

  • Page 66: Boot Menu

    [USB Floppy] Boot Option #2 [USB Key] Boot Option #3 [USB Hard Disk] Boot Option #4 [USB CD/DVD] Boot Option #5 [CD/DVD] Boot Option #6 [Hard Disk] Boot Option #7 [Network]  CSM parameters K1 and K2 Motherboard, User Manual...

  • Page 67: Bootup Numlock State [On]

    Every entry (from #1 till #7) specifies a boot group. Each boot device found while POST is running will be sorted in one of a BBS group. Enter a BBS group to swap the boot order of the BBS device. K1 and K2 Motherboard, User Manual...

  • Page 68: Security Menu

    After this warning the boot process stops and the user has to enter the UEFI BIOS setup which resets the open case detection automatically. Additionally is a viewing point of the case open switch K1 and K2 Motherboard, User Manual...

  • Page 69: Sub Menu  Security Menu  Secure Boot Menu

    Configuration options: [Disabled] [Enabled] Secure Boot Mode [Standard] This is the secure mode selector. The ‘Custom’ mode enables user to change the Image Execution policy and mange Secure Boot Keys Configuration options: [Standard] [Custom] K1 and K2 Motherboard, User Manual...

  • Page 70: Save & Exit Menu

    This option should only be used if the changes made in Setup should not save. If made some changes to fields other than system date, system time, and password, the system will ask for confirmation before exiting and reset the system. K1 and K2 Motherboard, User Manual...

  • Page 71: Restore Defaults

    0x90 – 0xCF BDS execution 0xD0 – 0xDF DXE errors 0xE0 – 0xE8 S3 Resume (PEI) 0xE9 – 0xEF S3 Resume errors (PEI) 0xF0 – 0xF8 Recovery (PEI) 0xF9 – 0xFF Recovery errors (PEI) K1 and K2 Motherboard, User Manual...

  • Page 72: Sec Phase

    Pre-memory CPU initialization (CPU module specific) 0x14 Pre-memory CPU initialization (CPU module specific) 0x15 Pre-memory North Bridge initialization is started 0x16 Pre-Memory North Bridge initialization (North Bridge module specific) 0x17 Pre-Memory North Bridge initialization (North Bridge module specific) K1 and K2 Motherboard, User Manual...
  • Page 73 0x3A Post-Memory North Bridge initialization (North Bridge module specific) 0x3B Post-Memory South Bridge initialization is started 0x3C Post-Memory South Bridge initialization (South Bridge module specific) 0x3D Post-Memory South Bridge initialization (South Bridge module specific) K1 and K2 Motherboard, User Manual...
  • Page 74 S3 Resume Boot Script Error 0xEB S3 OS Wake Error 0xEC-0xEF Reserved for future AMI error codes Recovery Progress Codes 0xF0 Recovery condition triggered by firmware (Auto recovery) 0xF1 Recovery condition triggered by user (Forced recovery) K1 and K2 Motherboard, User Manual...

  • Page 75: Pei Beep Codes

    CPU DXE initialization (CPU module specific) 0x65 CPU DXE initialization (CPU module specific) 0x66 CPU DXE initialization (CPU module specific) 0x67 CPU DXE initialization (CPU module specific) 0x68 PCI host bridge initialization 0x69 North Bridge DXE initialization is started K1 and K2 Motherboard, User Manual...
  • Page 76 PCI Bus initialization is started 0x93 PCI Bus Hot Plug Controller Initialization 0x94 PCI Bus Enumeration 0x95 PCI Bus Request Resources 0x96 PCI Bus Assign Resources 0x97 Console Output devices connect 0x98 Console input devices connect K1 and K2 Motherboard, User Manual...
  • Page 77 0xB7 Configuration Reset (reset of NVRAM settings) 0xB8 – Reserved for future AMI codes 0xBF 0xC0 – OEM BDS initialization codes 0xCF DXE Error Codes 0xD0 CPU initialization error 0xD1 North Bridge initialization error K1 and K2 Motherboard, User Manual...

  • Page 78: Dxe Beep Codes

    Some of the Architectural Protocols are not available No Console Output Devices are found No Console Input Devices are found Flash update is failed Reset protocol is not available Platform PCI resource requirements cannot be met K1 and K2 Motherboard, User Manual...

  • Page 79: Abbreviations

    Extended BIOS Data Area Extended Capabilities Port EEPROM Electrical Erasable Read Only Memory Extensible Firmware Interface E-IDE Enhanced Integrated Drive Electronics Expanded Memory System ESCD Extended System Configuration Data Enhanced Parallel Port Front Side Bus K1 and K2 Motherboard, User Manual...
  • Page 80 Read Only Memory Retail Systems SATA Serial AT Attachment (new version of hard disk interface) System Locked Pre-Installation System Management Interrupt System Management Mode SMRAM System Management RAM SPGA Staggered Pin Grid Array Thin-film transistor K1 and K2 Motherboard, User Manual...
  • Page 81 Trusted Platform Module UEFI Unified Extensible Firmware Interface Uninterruptible Power Supply Universal Serial Bus UUID Universal Unique Identifier Video Graphics Array Wake On LAN Wake On Modem K1 and K2 Motherboard, User Manual...
  • Page 83 Wincor Nixdorf International GmbH D-33094 Paderborn Order No.: 010750266921B...
