- Page 1 L1 and L2 POS Motherboard (with BIOS Setup) User Manual...
- Page 2 Please send us a copy of this page if you have any constructive criticism. We would like to thank you in advance for your comments. With kind regards, Your opinion: Wincor Nixdorf International GmbH Documentation R&D SAT 11 Wohlrabedamm 31 D-13629 Berlin E-Mail: retail.documentation@wincor-nixdorf.com...
- Page 3 L1 and L2 POS Motherboard User Manual Edition November 2014...
- Page 4 All brand and product names mentioned in this document are trademarks of their respective owners. Copyright © Wincor Nixdorf International GmbH, 2014 The re production, transmission or use of this document or its contents is not permitted without express authority. Offenders will be liable for damages. All rights, including rights created by patent grant or registration of a utility model or design, are reserved.
-
Page 5: Table Of Contents
Contents Overview ..................1 Introduction ..................1 Some Highlights of the L1 and L2 Motherboard ........ 1 Motherboard Specification ............3 Block Diagram ..................3 Internal Connectors ................4 Mainboard assembly variants ............5 CPU support ..................5 Mainboard internal connectors and onboard features ..... 5 USB 2.0 (internal) ................ - Page 6 UEFI BIOS Setup ................18 Standard UEFI BIOS Version ............. 18 BIOS Menu Bar ................. 19 Legend Screen .................. 19 General Help ..................20 Scroll Bar ..................20 Sub-Menu ..................21 Info Screen ..................21 Product Name: ................22 BIOS Version: ................22 Ethernet MAC Address: ...............
- Page 7 Execute Disable Bit [Enabled] ..........29 Intel Virtualization Technology [Enabled] ........ 29 Hardware Prefetcher [Enabled] ..........29 Adjacent Cache Line Prefetch [Enabled] ........30 CPU AES * [Enabled] ..............30 Boot performance mode [Max Non-Turbo Performance] ..30 EIST [Enabled] ................30 Turbo Mode * [Enabled] ............
- Page 8 WatchDog [Disabled] ............... 37 Sub Menu USB Configuration............37 Legacy USB Support [Enabled] ..........37 USB3.0 Support [Enabled] ............37 XHCI Hand-off [Enabled] ............38 EHCI Hand-off [Enabled] ............38 USB Ports Per-Port Disable Control [Enabled] ......38 USB Mass Storage Driver Support [Enabled] ......
- Page 9 DXE Phase ..................55 DXE Beep Codes ................58 Abbreviations ................59...
-
Page 10: Overview
This manual describes the features of two variants of a Motherboard based on the Intel 8 series chipset Q87 and H81, formerly known as Lynx Point. These L1 and L2 Motherboards were primarily designed for the Wincor Nixdorf Systems EPC_5G, EPC_5G_DC and EPC_5G_Upgrade. - Page 11 MiniPCIe socket (full size) supporting the WN NVRAM module 2 USB3.0 ports Q87: 12 USB2.0 ports, H81: 8x USB ports TPM onboard PC Beeper onboard TFT- displays without DDC are not supported. L1 and L2 Motherboard, User Manual...
-
Page 12: Motherboard Specification
Lynx Point PCH USB2.0 Q87 / H81 Up to 12 PCI Express x1 USB2.0 Ports 1Gb LAN I217LM /1217V USB3.0 PCI Express x1 2x USB3.0 Ports miniPCIe COM 1+2 BIOS 64 / 128Mbit NCT6106D L1 and L2 Motherboard, User Manual... -
Page 13: Internal Connectors
Internal Connectors L1 and L2 Motherboard, User Manual... -
Page 14: Mainboard Assembly Variants
Mainboard internal connectors and onboard features USB 2.0 (internal) 6 USB ports at L1 board and 2 USB ports at L2 are routed to 10pin double row headers with 2.54 mm pitch. Each header provides 2 ports. These headers are intended to connect optional front USB modules or USB hubs. -
Page 15: Mini Pci Express
PCIe functionality (PCIe functionality only supported in conjunction with Q87 chipset according to mini PCI Express Standard Rev 1.1). The L1 motherboard supports PCIe and mSATA functionality, the L2 motherboard supports mSATA functionality only. Connector type: Standard MiniPCIe 1.1 connector full size... -
Page 16: Memory (Internal)
The mainboard provides three standard SATA ports. The ports SATA1 (white) and SATA2 (blue) supporting SATA III connectivity speed. Port SATA3 (black) supports SATA III speed at L1 board, and SATA II speed at L2 board. The RAID functionality is only supported by the L1 motherboard. -
Page 17: Chassis Intrusion Connector (Internal)
4s. But when the OS is shut down correctly, system can be switched on again by the power button. The front panel header also supports speaker connection. L1 and L2 Motherboard, User Manual... -
Page 18: Atx / 12V Power Connector (Internal)
Pin Number Function +12V A 20 pin ATX power cable can be plugged into the 24 pin connector on the motherboard, too. In this case the pins 11,12,23 and 24 are not used and L1 and L2 Motherboard, User Manual... -
Page 19: Lpt (Internal)
Module (TPM) with firmware 3.19 directly soldered on the PCB. Jumper 4 (JP4): Enables/Disables the TPM Chip. Default setting is position 1-2, TPM ena- bled. To disable the TPM set Jumper to position 2-3. L1 and L2 Motherboard, User Manual... -
Page 20: Pci Express Slots (Internal)
Power status Power LED Green S3, S4, S5 Onboard status LEDs and power button work together with an external status LED and power button connected to the front panel connector. L1 and L2 Motherboard, User Manual... -
Page 21: Mainboard Onboard Connectors With External Access
Yellow blinking WOL (wake on LAN) and PXE are supported. USB 2.0 / USB 3.0 (external) 8 USB ports (6 for USB2.0 and 2 for USB3) are located in the mainboard I/O connector area. L1 and L2 Motherboard, User Manual... -
Page 22: Com (External)
There are two standard RS232 COM ports (male 9pin DSUB connectors) at the I/O shield. Audio (external) The mainboard supports a microphone-in, a line-out and a line-in connector in I/O shield. The connector type is stereo 3.5mm diameter. L1 and L2 Motherboard, User Manual... -
Page 23: Technical Data
2x USB 3.0 12x USB 2.0 (L1) 8x USB 2.0 (L2) Expansion Slots 2x PCIe x1 1x PCIe x16 slot 1x MiniPCIe 1.1 (used by L1 only), additional LPC signals Motherboard 1x DVI-D Audio: External I/O 1x LAN (RJ45) + 2x USB3.0... -
Page 24: Supported Sleep States
Suspend to Disk / “Hibernation” Soft Off RAID (L1 Motherboard) The L1 motherboard provides RAID functionality for the SATA interface. Raid level 0 (striping), 1 (mirroring) and 5 (striping with distributed parity) are supported. For RAID 5 three HDD/SSD devices are needed. - Page 25 LED indication to work. SATA 3 SATA 2 SATA 1 Color Function Yellow Read/Write activity indication for SATA2 port Yellow Read/Write activity indication for SATA1 port Failure indication for SATA2 port Failure indication for SATA1 port L1 and L2 Motherboard, User Manual...
-
Page 26: Changing The Battery
Downloads/POSLotterySystems/Manuals/manuals_node.html The lithium battery must be replaced only by identical batteries or types recommended by Wincor Nixdorf International. You can return the used batteries to your Wincor Nixdorf International sales outlet. Batteries containing harmful substances are marked accord- ingly. The chemical denotations are as follows: CD = Cadmium; Pb = Lead, Li = Lithium. -
Page 27: Uefi Bios Setup
UEFI BIOS Setup The mainboard L1.0-Q87-uATX-STD and L2.0-H81-uATX-STD comes with an AMI UEFI BIOS chip that contains the ROM Setup information of your sys- tem. This chip serves as an interface between the processor and the rest of the mainboard’s components. This section explains the information con- tained in the Setup program and tells you how to modify the settings according to your system configuration. -
Page 28: Bios Menu Bar
The right frame displays the key legend. The keys in the legend frame allow you to navigate through the various setup menus. The following table lists the keys found in the legend with their corresponding alternates and func- tions. L1 and L2 Motherboard, User Manual... -
Page 29: General Help
Use <PgUp> and <PgDn> or the up and down keys to scroll through the en- tire help document. Press <Home> to display the first page, press <End> to reach the last page. To exit the help window, press the <Enter> or <Esc> key. L1 and L2 Motherboard, User Manual... -
Page 30: Sub-Menu
Wincor Nixdorf Info Page Product Name: #.#-###-uATX-STD Bios Version: xx/yy Bios Date: MM/DD/YYYY Ethernet MAC-Address: AC-DC-FA-DE-BE-EF UUID: d716af80-6f0a-1018-8789-fbd248a1242f System: --------------------------- --- ------------------------------ ###--------------------------------------------------------- Mainboard: --------------------------- --- ------------------------------- -------------------------------------------------------------- Power Supply: --------------------------- --- ------------------------------- --------------------------------------------------------------- L1 and L2 Motherboard, User Manual... -
Page 31: Product Name
Product Name: This text is fixed for your mainboard with standard UEFI BIOS. This board is also called “L1.0-Q87-uATX-STD” or “L2.0- H81-uATX-STD” BIOS Version: The UEFI BIOS version is displayed in the WN release format xx/yy The UEFI BIOS Date is displayed the date of release in international format:... -
Page 32: Main Menu
On the upper right frame find the keys listed to modify the values. Processor and Chipset Information This enters a Sub-Menu with summaries of used processor and chipset. L1 and L2 Motherboard, User Manual... -
Page 33: Advanced Menu
USB Configuration NCT6106D Super IO Configuration NCT6106D HW Monitor Serial Port Console Redirection CMOS Intel(R) Ethernet Network Connection Sub Menu ACPI Settings ACPI Settings Enable ACPI Auto Configuration [Enabled] L1 and L2 Motherboard, User Manual... -
Page 34: Enable Acpi Auto Configuration
TPM State [Disabled] This option changes the actual state of the security module. Select the TPM operation after the next automated reboot of the system. Pending operation [None] [None]: The TPM state will be untouched. L1 and L2 Motherboard, User Manual... -
Page 35: Sub Menu Hardware Configuration
BEETLE is in Soft-Off or Hibernate mode. The BEETLE cannot receive or transmit data until the system and applications are fully running, thus connection cannot be made on the first try. Turning an external modem off and then L1 and L2 Motherboard, User Manual... -
Page 36: Wake On Pcie Slot [Disabled]
[Power off] leaves the system off until pressing the power button. [Last State] reboots the system automatically if it was active before power loss. [Follow AC Power] will start up anytime power is available. Configuration options: [Power off] [Last State] [Follow AC Power]. L1 and L2 Motherboard, User Manual... -
Page 37: Bootorder Menu [Enabled]
CPU Configuartion Parameters Hyper-threading [Enabled] This option allows enabling or disabling the Intel(R) Hyper-threading Tech- nology to uses processor resources more efficiently, enabling multiple threads to run on each core. Configuration options: [Disabled] [Enabled]. L1 and L2 Motherboard, User Manual... -
Page 38: Active Processor Cores [All]
The processor has a hardware prefetcher that automatically analyses its requirements and prefetches data and instructions from the memory into the Level 2 cache. This reduces the latency associated with memory reads. Configuration options: [Disabled] [Enabled] L1 and L2 Motherboard, User Manual... -
Page 39: Adjacent Cache Line Prefetch [Enabled]
This option enables or disables the Turbo Mode of several Intel processors. Configuration options: [Disabled] [Enabled] Intel TXT (LT) Support * [Enabled] Intel Trusted Execution Technology (TXT) is supported by several Intel processors. Configuration options: [Disabled] [Enabled] L1 and L2 Motherboard, User Manual... -
Page 40: Sub Menu Sata Configuration
SATA Mode selection [IDE] This option selects the SATA controller mode. The option [RAID] is only available on L1 boards with Q87 Chipset. Configuration options: [AHCI] [IDE][RAID]. Following two menu items are only available if SATA Mode selection is set... -
Page 41: Sub Menu Platform Thermal Configuration
This value controls the temperature of the ACPI Active Trip Point 1. Configuration options: [Disabled] [15 C] [23 C] [31 C] [39 C] [47 C] [55 C] [63 C] [71 C] [79 C] [87 C] [95 C] [103 C] [111 C] [119 C]. L1 and L2 Motherboard, User Manual... -
Page 42: Active Trip Point 1 Fan Speed 75
OS will read the temperature when passive cooling is enabled. Configuration options: 2 - 32 PCH Thermal Device [Disabled] This option enables or disables the PCH Thermal device (D31:F6). Configuration options: [Disabled] [Enabled]. L1 and L2 Motherboard, User Manual... -
Page 43: Sub Menu Pch-Fw Configuration
Intel ME (Management Engine) Subsystem is a separated microcontroller embedded in the chipset driven by a special firmware. For systems with mainboard “L1.0-Q87-uATX-STD” the ME handles an own setup and can be entered while booting the system by pressing the keys CTRL + P. -
Page 44: Sub Menu Amt Configuration
AMT. All other options are not available if AMT is disabled. Configuration options: [Disabled] [Enabled] BIOS Hotkey Pressed [Disabled] This option enables or disables the BIOS hotkey press. Configuration options: [Disabled] [Enabled] L1 and L2 Motherboard, User Manual... -
Page 45: Mebx Selection Screen [Disabled]
Configuration options: [Disabled] [Enabled] USB Configure [Enabled] This option enables or disables the USB configuration function. Configuration options: [Disabled] [Enabled] PET Progress [Enabled] This option enables or disables the PET events progress. Configuration options: [Disabled] [Enabled] L1 and L2 Motherboard, User Manual... -
Page 46: Watchdog [Disabled]
USB devices are connected. Disable this option keep USB de- vices available only for EFI applications. Configuration options: [Disabled] [Enabled] [Auto] USB3.0 Support [Enabled] This option enables the USB 3.0 (XHCI) Controller support. Configuration options: [Disabled] [Enabled] L1 and L2 Motherboard, User Manual... -
Page 47: Xhci Hand-Off [Enabled]
Configuration options: [Disabled] [Enabled] Sub Menu NTC6106D Super IO Configuration NTC6106D Super IO Configuration NTC6106D Super IO Chip NTC6106D Serial Port 1 Configuration Serial Port 2 Configuration Parallel Port Configuration L1 and L2 Motherboard, User Manual... -
Page 48: Parallel Port Configuration
: 1630 RPM PSU Fan Speed : 1285 RPM VCORE : +1.056 V : +5.032 V +12V : +12.406 V AVCC : +3.396 V VCC3V : +3.331 V VSB3 : +3.356 V VBAT : +3.024 V L1 and L2 Motherboard, User Manual... -
Page 49: Sub Menu Serial Port Console Redirection
Configuration options: [Disabled] [Enabled] Sub Menu Serial Port Console Redirection Console Redirection Settings Out-of-Band Mgmt [Com0 (Disabled)] Terminal Type [VT-UTF8] Bits per second [115200] Flow Control [None] Data Bits Parity None Stop Bits L1 and L2 Motherboard, User Manual... -
Page 50: Sub Menu Cmos
Sub Menu CMOS CMOS Settings/Information Bad battery detected: [False] First boot detected [False] Defaults loaded [False] Bad checksum detected [False] The CMOS menu is only an information screen which shows some specific CMOS information. L1 and L2 Motherboard, User Manual... -
Page 51: Sub Menu Intel(R) Ethernet Network Connection
Wake On LAN [Enabled] This allows enabling or disabling power up the BEETLE when the LAN con- troller receives a call while the BEETLE is in Soft-Off or Hibernate mode. Configuration options: [Disabled] [Enabled]. L1 and L2 Motherboard, User Manual... -
Page 52: Chipset Menu
This option enables or disables the BIOS lock enable (BLE) bit. Configuration options: [Disabled] [Enabled] BIOS Interface Lock [Enabled] This option handles the NVRAM access. For using a NVRAM module set this option to [Disabled]. Configuration options: [Disabled] [Enabled] L1 and L2 Motherboard, User Manual... -
Page 53: Sub Menu System Agent (Sa) Configuration
This option sets the Graphics Turbo IMON current value. Configuration options: 14-31 Primary Display [Auto] This option selects which graphics device IGFX, PEG, PCI should be the pri- mary display. Configuration options: [Auto] [IGFX] [PEG] [PCIE] L1 and L2 Motherboard, User Manual... - Page 54 [Enabled] This option is application for SFF only Configuration options: [Disabled] [Enabled] Internal Graphics Port Order [Disp.1>VGA] This option selects which device may be used as primary display first Configuration options: [VGA>Disp.1] [Disp.1> VGA] L1 and L2 Motherboard, User Manual...
-
Page 55: Boot Menu
[USB CD/DVD] Boot Option #2 [Hard Disk] Boot Option #3 [Disabled] Boot Option #4 [Disabled] Boot Option #5 [Disabled] Boot Option #6 [Disabled] Boot Option #7 [Disabled] CSM parameters Hard Disk Drive BBS Priorities L1 and L2 Motherboard, User Manual... -
Page 56: Quiet Boot [Disabled]
Every entry (from #1 till #7) specifies a boot group. Each boot device found while POST is running will be sorted in one of a BBS group. Enter a BBS group to swap the boot order of the BBS device. L1 and L2 Motherboard, User Manual... -
Page 57: Security Menu
After this warning the boot process stops and the user has to enter the UEFI BIOS setup which resets the open case detection automatically. Additionally is a viewing point of the case open switch L1 and L2 Motherboard, User Manual... -
Page 58: Sub Menu Security Menu Secure Boot Menu
Configuration options: [Disabled] [Enabled] Secure Boot Mode [Standard] This is the secure mode selector. The ‘Custom’ mode enables user to change the Image Execution policy and mange Secure Boot Keys Configuration options: [Standard] [Custom] L1 and L2 Motherboard, User Manual... -
Page 59: Save & Exit Menu
NVRAM. The NVRAM is sustained by an onboard backup battery and stays on even when the BEETLE is turned off. Once this option is selected, a confirmation is asked. Select [Ok] to save changes and reset the system. L1 and L2 Motherboard, User Manual... -
Page 60: Discard Changes And Reset
PEI execution up to and including memory detection 0x30 – 0x4F PEI execution after memory detection 0x50 – 0x5F PEI errors 0x60 – 0x8F DXE execution up to BDS 0x90 – 0xCF BDS execution L1 and L2 Motherboard, User Manual... -
Page 61: Sec Phase
Microcode not loaded PEI Phase Status Code Description Progress Codes 0x10 PEI Core is started 0x11 Pre-memory CPU initialization is started 0x12 Pre-memory CPU initialization (CPU module specific) 0x13 Pre-memory CPU initialization (CPU module specific) L1 and L2 Motherboard, User Manual... - Page 62 0x36 CPU post-memory initialization. System Management Mode (SMM) initialization 0x37 Post-Memory North Bridge initialization is started 0x38 Post-Memory North Bridge initialization (North Bridge module specific) 0x39 Post-Memory North Bridge initialization (North Bridge module specific) L1 and L2 Motherboard, User Manual...
- Page 63 Video repost 0xE3 OS S3 wake vector call 0xE4-0xE7 Reserved for future AMI progress codes S3 Resume Error Codes 0xE8 S3 Resume Failed 0xE9 S3 Resume PPI not Found 0xEA S3 Resume Boot Script Error L1 and L2 Motherboard, User Manual...
-
Page 64: Pei Beep Codes
S3 Resume failed Reset PPI is not available DXE Phase Status Description Code 0x60 DXE Core is started 0x61 NVRAM initialization 0x62 Installation of the South Bridge Runtime Services 0x63 CPU DXE initialization is started L1 and L2 Motherboard, User Manual... - Page 65 PCI Bus Enumeration 0x95 PCI Bus Request Resources 0x96 PCI Bus Assign Resources 0x97 Console Output devices connect 0x98 Console input devices connect 0x99 Super IO Initialization 0x9A USB initialization is started 0x9B USB Reset L1 and L2 Motherboard, User Manual...
- Page 66 DXE Error Codes 0xD0 CPU initialization error 0xD1 North Bridge initialization error 0xD2 South Bridge initialization error 0xD3 Some of the Architectural Protocols are not available 0xD4 PCI resource allocation error. Out of Resources L1 and L2 Motherboard, User Manual...
- Page 67 Some of the Architectural Protocols are not available No Console Output Devices are found No Console Input Devices are found Flash update is failed Reset protocol is not available Platform PCI resource requirements cannot be met L1 and L2 Motherboard, User Manual...
- Page 68 Digital Video Interface EBDA Extended BIOS Data Area Extended Capabilities Port EEPROM Electrical Erasable Read Only Memory Extensible Firmware Interface E-IDE Enhanced Integrated Drive Electronics Expanded Memory System ESCD Extended System Configuration Data Enhanced Parallel Port L1 and L2 Motherboard, User Manual...
- Page 69 Ring Indicator Read Only Memory Retail Systems SATA Serial AT Attachment (new version of hard disk interface) System Locked Pre-Installation System Management Interrupt System Management Mode SMRAM System Management RAM SPGA Staggered Pin Grid Array L1 and L2 Motherboard, User Manual...
- Page 70 Thin-film transistor Trusted Platform Module UEFI Unified Extensible Firmware Interface Uninterruptible Power Supply Universal Serial Bus UUID Universal Unique Identifier Video Graphics Array Wake On LAN Wake On Modem L1 and L2 Motherboard, User Manual...
- Page 71 Wincor Nixdorf International GmbH D-33094 Paderborn Order No.: 010750266922A...
