The Connector Adapter
The troubleshooter has an SC connector adapter that you can
remove to clean the fiber endface in the port.
Lock
How to Remove and Install the Connector Adapter
Unlock
The Connector Adapter
Remove
Ferrule and fiber
endface
fjy02.eps
7
