- Page 1 FEV300 Electrical Vehicle Charging Station Test Adapter Users Manual PN 5361878, May 2022 © 2022 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
-
Page 2: Product Disposal
Introduction The FEV300 (the Product or test adapter) tests the functions and the safety of charging stations mode 3 for AC charging. The adapter imitates a car and opens up a charging cycle (activate voltage/current output). This adapter allows you to conduct tests in combination with appropriate test instruments like Installation Tester, multimeter and/or Scope Meters (oscilloscope). -
Page 3: Contact Fluke
Contact Fluke Fluke Corporation operates worldwide. For local contact information, go to our website: www.fluke.com To register your product, view, print, or download the latest manual or manual supplement, go to our website. Fluke Corporation Fluke Europe B.V P.O. Box 9090... -
Page 4: Transport And Storage
• Test of CP signal – two 4 mm safety sockets for connection to a multimeter or oscilloscope. Optional Accessories • FEV300-CON-TY1 Type 1 Plug for Test Adapter EV Charging • FEV300-CON-TY2 Type 2 Plug for Test Adapter EV Charging... -
Page 5: Operation Elements And Connectors
(marked with ) is connected to PE Test cable input with 7-pole male connector Test cable TYPE 1/2: - FEV300-CON-TY2 Type 2 plug for test adapter EV charging - FEV300-CON-TY1 Type 1 plug for test adapter EV charging... - Page 6 Figure 3. Top of the Product Figure 4. Back of the Product Test cable input CP Signal output terminal (yellow) CP Signal output terminal (connected to PE) (green) Testing Charging Stations WX Warning To prevent possible electric shock, fire, or personal injury: •...
- Page 7 - Mechanical locking of EV plug at the charging station - Rotary field / phase sequence of output voltage - Other tests Connection of the Product to Charging Station Figure 5. Available test cables for the test adapter series FEV300-CON-TY2 TYPE 2 plug 7-pole male connector...
- Page 8 The Product Series can accept the following connection cables: • FEV300-CON-TY2 - Type 2 plug for test adapter EV charging • FEV300-CON-TY1 - Type 1 plug for test adapter EV charging Steps for connecting the test adapter to the charging station: 1.
- Page 9 Testing a charging station PE Pre-Test Figure 9. PE pretest FEV300-CON-TY2 Charging Station Type 2 (with panel mount socket outlet) as example FEV300 The PE Pre-Test is a safety feature of the Product. The PE Pre-Test allows the operator to test the PE conductor for possible presence of dangerous voltage against earth.
- Page 10 Proximity Pilot (PP) State (Cable Simulation) To simulate various current capabilities of the charging cable, connect the test adapter to the charging station and set the PP State rotary switch (item , Figure 2). The adapter simulates the current capabilities with different resistances connected between PP and PE conductors.
- Page 11 Initiating a charging cycle: 1. Turn CP switch to A position and connect the adapter cable to the charging station. 2. Turn CP switch to B position and wait 3 to 5 seconds – in commercial stations this may initiate a station to ask for payment information 3.
- Page 12 8 % ≤ Duty Cycle < 10 %, Maximum current = 6 A 10 % ≤ Duty Cycle ≤ 85 %, Maximum current = (duty cycle %) x 0.6 85 % < Duty Cycle ≤ 96 %, Maximum current = (duty cycle % - 64) x 2.5 96 % <...
-
Page 13: Maintenance
The terminals can be used to perform measurements like earth bond, insulation, loop/line impedance, RCD trip test, voltage and Power Quality. An appropriate measurement instrument (for example the FLUKE 166x series) is needed. Maintenance When using the test adapter in compliance with the user manual, no special maintenance is required. -
Page 14: Specifications
480 V (three phase system), 50/60 Hz, max 10 A Internal power consumption ..3 W max. FEV300-CON-TY2 Plug ....AC charging mode 3, suitable to IEC 62196-2 type 2 socket outlet or fixed cable with vehicle connector (type 2, 7P three-phase) FEV300-CON-TY1 Plug .... - Page 15 LIMITED WARRANTY AND LIMITATION OF LIABILITY Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is three years and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days.
