4..7
Reserved
1
0..7
Reserved
2
Setpoint HI
3
Setpoint LO
*) Not supported yet
5.3.2 PPO2: (Matic C compatible)
This process image is activated by the following configuration:
Length
Cfg
2
21 11
Input data (Data from actuator to controller)
Byte
Bit
Signal
0
0
Collective fault
1
Running OPEN /
Intermediate pos. 1
2
Running CLOSE /
Intermediate pos. 2
3
Mode REMOTE
4
Final position OPEN
5
Final position CLOSE
6
Switch off OK OPEN
7
Switch off OK CLOSE
1
0..7
Actual position
*) Not supported yet
**) Depending on TR11 setting on the base board of the control unit (from FW 1.05.0020 at DMC-14)
Output data (Data from controller to actuator)
Byte
Bit
Signal
0
0
Command AUTO
1
Command STOP
2
Command CLOSE
3
Command OPEN
4..7
Reserved
1
0..7
Setpoint
DREHMO - MaticC Profibus DPV0/DPV1
Complementary operating manual
Position setpoint for positioner
(CLOSE = 0 Dez / OPEN = 1000 Dez)
Description
Default value: 2 bytes input / 2 bytes output
Description
Collective fault indication
Running indication OPEN (TR11 open) /
Intermediate position 1 (TR11 closed) **)
Running indication CLOSE (TR11 open) /
Intermediate position 2 (TR11 closed) **)
Actuator can be controlled by external commands
Final position indication according to settings
Final position indication according to settings
Switch off OK in OPEN direction *)
Switch off OK in CLOSE direction *)
Position feedback
(CLOSE = 46 Dez / OPEN = 230 Dez)
Description
Activates the internal position controller
(Position controlling according setpoint / actual value
comparison)
Stops the actuator. (Signal has higher priority than
AUTOMATIK, CLOSE and OPEN)
Command CLOSE, if AUTO = 0
Command OPEN, if AUTO = 0
position setpoint for position controller
(CLOSE = 46 Dez / OPEN = 230 Dez)
Page 21 of 28
