Remark:
The list of GSD files is only valid for PNO ID selection Matic C DPV1 according S6.2=0 and
S6.3=0.

5.2 Set parameter telegram

5.2.1 Standard parameter (7 Bytes)

The Profibus interface supports parameterization with different PNO-IDs in Byte 5 and 6 of the
standard parameters, which can be set by DIL switch S6.
This enables the operation of the device with control stations using 3rd party parameterizations.
The other bytes of the standard parameters have the meaning as described in Profibus
specifications.
Single ASC Dual ASIC
0C27 0C26
0686
05CD 05CD
056D

5.2.2 User specific parameters (UsrPrm data)

The interface accepts a different amount of user parameter data:
Length Usr_Prm
3
80 00 00
5
00 00 00
00 00
4
80 00 00
00
37
80 00 00
00 .. 00
The parameter telegram can be extended with a block of 8 bytes for the parameterization by the
RedCom layer.
DREHMO - MaticC Profibus DPV0/DPV1
Complementary operating manual
PNO Id of
Matic C DPV1
0686 Matic C DPV0
AUMA
056E SIPOS
Description
Default value.
3 DPV1 bytes.
Matic C DPV0 compatible
3 DPV1 bytes.
Matic C DPV1 user specific (Reserved, always = 00)
Sipos compatible
3 DPV1 bytes.
Sipos user specific (Activation of internal position controller (If
equipped). 00=disabled; 01=enabled)
AUMA compatible
3 DPV1 bytes.
34 bytes acc. AUMA GSD
