4.3.2 DIL Switch S4

Bit
Value
1
0
1
3..2
6..4
000
001
010
011
100
111
7
0
1
8
0
1

4.3.3 DIL Switch S6

Bit
Value
Description
1
Address offset of second Profibus channel (Only for Dual ASIC)
0
No address offset for second channel
1
Address offset 64 for second channel
1
Line redundancy monitoring/switching (only if S6.4 and S6.5 = 1)
0
Use fast monitoring/switching mechanism
1
Switch channel only in case of slave watchdog tripping
3..2
PNO ID selection for emulation mode
00
Matic C DPV1 (DUAL ASIC: 0x0C26 / SINGLE ASIC: 0x0C27)
01
Matic C DPV0 (0x0686)
10
AUMA (0x05CD)
11
SIPOS (DUAL ASIC: 0x056E / SINGLE ASIC: 0x056D)
5..4
Redundancy mode Protocol / Media access
Dual ASIC
00
DREHMO redundancy
GSD-File: DREM0C26
01
System redundancy acc. PNO
Spec. 2212
GSD-File: DREM0C26
10
ABB redundancy
GSD-File: DREM0C26
DREHMO - MaticC Profibus DPV0/DPV1
Complementary operating manual
Description
Enable Host communication
Host communication disabled. (Only for testing purposes)
Host communication enabled. (Default)
Reserved
Fail safe delay time
(Added to the watchdog timeout provided by the Profibus Master)
0 Seconds
5 Seconds
10 Seconds
20 Seconds
40 Seconds
Fail safe disabled
Fail Safe behaviour on GCC (Global Control Clear)
Fail as is on GCC
Fail safe on GCC
Simulate external diagnosis
No simulation of external diagnosis (default)
Simulate external diagnosis (only for testing purposes)
Single ASIC
No redundancy; 1 ASIC on channel 1
GSD-File: DREM0C27
No redundancy; 1 ASIC on channel 1
GSD-File: DREM0C27
No redundancy; 1 ASIC on channel 1
GSD-File: DREM0C27
Page 14 of 28
