- Page 1 COMMUNICATION SOFTWARE FOR MM-122A MA-716A OPERATION MANUAL U02M0697E-04...
- Page 2 MA-716A Thank you for purchasing the Amada Miyachi Communication Software for MM-122A MA-716A. This operation manual describes its method of operation and precautions for use. Read this operation manual carefully prior to use. Store appropriately for ready reference. Contents 1. Features ··············································1-1 2.
- Page 3 Miyachi’s Weld Checker MM-122A. The MA-716A has following features. ● Easy connection The MM-122A can be connected easily to PC using the MA-716A. (The connecting cable is optional.) ● Reading the measured data The value measured on MM-122A can be read in PC.
- Page 4 MA-716A 2. System Requirements ● CPU and Memory Environment that Microsoft Windows and Microsoft Excel you use can be operated. When the welding interval is short, however, a high-performance PC is required. (1GHz or higher CPU and 1GB or larger memory are recommended.) ●...
- Page 5 3) When CD-ROM is opened, double click [setup] folder. 4) When [setup] folder is opened, double click [setup.exe]. 5) When [MM-122A-Test Setup] is started, click OK . 6) When the setting screen for folder to be setup is opened, click the button that a computer is illustrated on.
- Page 6 MA-716A 7) When the setting screen for program group is opened, click Continue . 8) When the end screen is displayed, click to end the setup. 3. Connection...
- Page 7 For details, see the operation manual for the MM-122A. ① RS-232C One MM-122A is connected even when the communication method of the MM-122A is set to “232Sy” for the setting change or “232Fr” for the measured-value reading. MM-122A side Host computer...
- Page 8 ① Setting of the MM-122A Set the communication method of the MM-122A. When connecting with RS-232C, set to [232Fr]. When connecting with RS-485, set to [485Fr]. Set the transmission rate to [9600bps]. For details, see the operation manual for the MM-122A. 3. Connection...
- Page 9 ・ the communication port is set to be unusable. End the software and check the settings of PC • Set the transmission rate set to the MM-122A in ② (9600bps) for [Transmission rate]. *1: See the operation manual for PC you use.
- Page 10 MA-716A ④ Checking Communication Measure the welding current several times on the MM-122A. • When the communication data is received normally [!!OK!!] is displayed for [Communication] and the received data is displayed for each item of [Data]. • When communication is not made normally Nothing or [!!ERROR!!] is displayed for [Communication].
- Page 11 When the settings are as above, copy “╲ excel_receive╲ ac mode╲ mon_ac_96_com2.xls”. ① AC Mode When the current setting to be measured on the MM-122A is set to [AC], [AC---] or [dccyc], copy one of the following files. ・When Transmission Rate is 9600bps Communication Port 1: ╲...
- Page 12 MA-716A ② DC Mode When the current setting to be measured on the MM-122A is set to [ACSEC] or [dcSEC], copy one of the following files. ・When Transmission Rate is 9600bps Communication Port 1: ╲ excel_receive╲ dc mode╲ mon_dc_96_com1.xls Communication Port 2: ╲ excel_receive╲ dc mode╲ mon_dc_96_com2.xls Communication Port 3: ╲...
- Page 13 MA-716A (3) Reading the Measured Value ① Security Setting of Microsoft Excel Since the MA-716A uses the macro function of Microsoft Excel, the security setting of Microsoft Excel 2003 is required. Select Tool → Macro → Security from the menu bar. Set the security level to Middle or Low When the security level is set to Middle or Low, defense against a virus...
- Page 14 MA-716A ③ Starting reading the measured value Pressing Start button starts reading the measured value. ・Schedule No. ・Step No. ・Count ・PEAK current judgment ・PEAK current ・RMS current judgment ・RMS current ・Weld time judgment ・Weld time ・Conduction angle ・TP time judgment ・TP time ・TH time judgment ・TH time...
- Page 15 Up to thirty-one MM-122As can be connected per host computer. Set the transmission rate to [9600bps] or [19200bps]. For details, see the operation manual for the MM-122A. (2) Copying the Setting-Changing Software Copy the setting-changing software to [My Documents] on the hard disk using Explorer.
- Page 16 MA-716A Select Tool → Macro → Security from the menu bar. Set the security level to Middle or Low When the security level is set to Middle or Low, defense against a virus using the macro function weakens. Use software for virus so that it does not cause any trouble if a virus invades macro.
- Page 17 MM-122A. If the system setting is not read, the setting on PC side and that of the MM-122A side become inconsistent, and a trouble occurs when writing in the MM-122A. ・ All read button reads all settings from the MM-122A.
- Page 18 When changing the settings, read the system setting from the MM-122A. If the system setting is not read, the setting on PC side and that of the MM-122A side become inconsistent and a trouble occurs when writing in the MM-122A.
- Page 19 When changing the schedules, read the system setting from the MM-122A. If the system setting is not read, the setting on PC side and that of the MM-122A side become inconsistent and a trouble occurs when writing in the MM-122A.
- Page 20 MA-716A ⑨ Initializing Method Select [Default setting] tab and press Default button to initialize the settings. (Remarks) (a) Default (Initializes settings) 5. Changing the Setting...
