CM7008T
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 5
Rev.14-09-10
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7008T
Summary of Contents for Furniture of America CM7008T
- Page 1 Assembly Instructions CM7008T ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Headboard Bolt 5/16”x1” #B x 8 pcs #2 x 2 pcs Bolt 5/16”x4”...
- Page 4 Align the two HB/FB legs (#5) with the pre-drilled holes underneath the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#C) onto the SAME bolt (#B), in that order.
- Page 5 Prepare a complete bed slat by connecting two end caps (#E) onto the ends of the slat (#4). Align the two end caps (#E) with the pre-drilled holes on each side of the side rails (#2) and press firmly down on both end caps (#G) to lock with the side rails (#2).
