To Configure Microsoft Exchange Server; Email Parameters - HP StorageWorks D2D User Manual

Table 6 Email parameters
SMTP Server:
Username and
Password:
Sender's Email
Account:
Recipient's Email
Address 1/2/3/4:
To configure Microsoft Exchange Server
NOTE:
Please refer to the Linux Configuration Guide on the CD-ROM for information abut configuring SMTP
with Linux.
It is important to check the SMTP server's security configuration parameters to ensure that the Sender's
Email Account can be recognized. Security configuration parameters are found within the SMTP virtual
server's property pages. To view or modify them:
1.
Open the Exchange Management console.
2.
Click on Servers and then the server you wish to configure.
3.
Click on Protocols and then SMTP.
4.
You will see the default virtual SMTP server. Right click on this and select Properties.
5.
Select the Access Control tab and then select Authentication.
6. The HP D2D Backup System may be used with one of the following settings:
This is the IP address of the email server.
Some email servers require authentication to send email alerts. If required, enter
a Username and a Password here that are valid on the SMTP server entered in
the previous box.
This is the email account to which the email will be attributed in the recipient's
inbox. The account must exist on the email server. For example, you may like to
create an account called "MyD2D@MyServer.com".
This is the email address of the person who should receive the message. Up to four
email addresses may be specified. You may only enter one address per line. Once
you have configured an email recipient, there is a Test button that you can use to
send a test email to the specified address.
D2D Backup System
75
