Kikusui TOS3200 Interface Manual

Leakage current tester
Hide thumbs Also See for TOS3200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual, User Manual
Communication
Interface Manual
Leakage Current Tester
TOS3200
PART NO. IB026072
Nov. 2016
Selecting
the Interface
SCPI language
Overview
Command
Reference
1
2
3
App

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOS3200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kikusui TOS3200

Summary of Contents for Kikusui TOS3200

  • Page 1 PART NO. IB026072 Nov. 2016 Selecting the Interface SCPI language Overview Communication Command Reference Interface Manual Leakage Current Tester TOS3200...

  • Page 2: About The Tos3200 Manuals

    PC. Indicates information that you should know. TOS3200 Series Manuals are intended for users of the Leak- age Current Tester and their instructors. Explanations are given under the presumption that the reader has knowledge Explanation of terminology or operation principle.

  • Page 3: Table Of Contents

    Contents About the TOS3200 Manuals .................. 2 Notations Used in This Manual ................2 Contents ........................3 Selecting the Interface Remote Control Overview ...................... 6 VISA Library....................... 7 Using the RS232C Interface....................8 Using the GPIB Interface...................... 11 Using the USB Interface....................... 12 SCPI language Overview Overview of Messages ......................
  • Page 4 A A List of Messages ..............68 B A List of Errors ................74 C Processing Time of Main Commands.........77 D A List of Default Settings ............78 Initializing the TOS3200 .................. 78 Default Values of the Panel Memory ............... 80 INDEX............82 TOS3200...

  • Page 5: Selecting The Interface

    リモ┃トコントロ┃ル Selecting the Interface This chapter gives an overview of the remote control function and explains interface setting.

  • Page 6: Remote Control Overview

    14 TOS3200. If the TOS3200 is operating under remote control, the RMT LED on the front panel will illumi- nate. To switch from the remote mode to the local mode (panel operation) from the panel, press the LOCAL key.

  • Page 7: Visa Library

    If you are using a VISA library (VISA COM) for the I/O library, the VISA library must be installed on the PC. A device driver supporting USB T&M Class (USBTMC) is required to control the TOS3200 through the USB interface. The USBTMC driver is automatically installed by the VISA library.

  • Page 8: Using The Rs232C Interface

    The RS232C port on the TOS3200 is a standard D-sub 9-pin male connector. Check that the POWER switches of the TOS3200 and the PC are off, and connect the TOS3200 to the PC using a standard cross cable (null modem cable).
  • Page 9 Sets the communication error trace function. (Common to all interfaces.) ERR TRACE Sets whether or not to display error numbers on the screen when there are SHIFT+F4 key errors in the error queue. Enable the error number display. SHIFT+F4 key Disable the error number display. TOS3200...
  • Page 10 Talk mode Processing on the PC can be reduced by using talk mode, because commands do not need to be sent from the PC. If you connect a serial printer to the TOS3200, the test log can be printed directly.

  • Page 11: Using The Gpib Interface

    Using the GPIB Interface Use a standard IEEE488 cable to connect the TOS3200 to the PC. Press the I/F (SHIFT+SYSTEM) key to display the interface setup screen (INTERFACE). MANUAL Press the SHIFT+F1 key or turn the rotary knob to select GPIB.

  • Page 12: Using The Usb Interface

    Using the USB Interface A device driver supporting USB T&M Class (USBTMC) is required to control the TOS3200 p. 7 through the USB interface. The USBTMC driver is automatically installed by the VISA library. Press the I/F (SHIFT+SYSTEM) key to display the interface setup screen (INTERFACE).

  • Page 13: Scpi Language Overview

    リモ┃トコントロ┃ル SCPI language Overview This chapter explains the SCPI command structure, syntax, and parameters.

  • Page 14: Overview Of Messages

    The information that is exchanged between the PC and the TOS3200 is called a message. The TOS3200 uses the SCPI language for the messages. There are two types of messages, commands that are sent from the PC to the TOS3200 and responses that are sent from the TOS3200 to the PC.

  • Page 15: Command Syntax

    Do not include the braces in the actual program. Characters strings inside brackets indicate optional data. When option data is not sent with the program, the default value will be sent. Do not include the brackets in the actual program. TOS3200...
  • Page 16 CR (ASCII 0x0D) is not a terminator. Common commands The IEEE-488.2 and SCPI standards contain a set of common commands for reset, self-test, p. 21 and other functions. These common commands always start with an asterisk. The commands may have one or multiple parameters. TOS3200...

  • Page 17: Parameters

    Parameters The parameter format of SCPI is derived from the program parameter format defined in IEEE 488.2. The representation system of the program data that is used on the TOS3200 is indicated below. Non-numeric parameters The TOS3200 uses the following three types of non-numeric parameters.
  • Page 18 The following optional prefixes are supported. To enter “µ” in the parameter, use “U” instead. • M (milli) • U (micro) The unit symbols in the International System of Units contain lowercase characters. The IEEE standard uses uppercase characters. SCPI commands are not case sensitive. TOS3200...

  • Page 19: Command Reference

    リモ┃トコントロ┃ル Command Reference This chapter explains details of each command and registers.

  • Page 20: Command Description In This Manual

    Returns the test time in the <NR3> form in response to TC:TIM? or PCC:TIM?. The representation system of the value that is returned when a query is sent. Command items and reference pages Item Page Command syntax Parameter Unit Default values Query Representation system List of messages List of errors TOS3200...

  • Page 21: Ieee488.2 Common Commands

    Response Returns the value of the event status register in the <NR1> form and clears the register. *IDN Queries the model name, serial number, and firmware version of the TOS3200. Command *IDN? Response The response to *IDN? is indicated below.
  • Page 22 For the commands that are affected by *RST, see “Default values. Command *RST *SAV Stores the present TOS3200 settings to memory. The operation is the same as MEM:SAV. p. 78 The settings that are stored are the same as those recalled using the *RCL command. See “Default values.
  • Page 23 Trigger command. This is a substitute command for the IEEE488.1 get message (Group Execute Trigger). Section 10.37 in If the TOS3200 is not in a condition to accept triggers, an SCPI error (-211,“Trigger ignored”) IEEE 488.2-1992 will occur. Command *TRG *TST Executes a self-test.

  • Page 24: Selecting The Operation Mode

    Response Returns the operation mode in the <string> form. If the TOS3200 is displaying the SYSTEM or INTERFACE screen, ”” will be returned. Setting the TC Measurement and PCC Measurement The commands with “TC” in the second-level node are for TC measurement. Commands with “PCC”...

  • Page 25: Setting The Power Line Polarity

    FLTPE Earth line disconnected condition (TC Measurement Mode only) Response Returns the single fault mode in the <character> form. If the connection destination of the measurement terminal is set to between the enclosure and power line, NA is returned. TOS3200...

  • Page 26: Setting The Lower Reference

    Sets the upper limit of the judgment reference (upper reference). This setting is valid when TC:LIM:UPP:STAT or PCC:LIM:UPP:STAT is on. For TC measurement, the setting varies depending on the measurement network and current measurement mode settings. For PCC measurement, the setting varies depending on the current measurement mode setting. TOS3200...

  • Page 27: Setting The Test Time And Test Wait Time

    Sets the test time (TIMER). This setting is valid when TC:TIM:STAT or PCC:TIM:STAT is on. Command [SENSe:]TC:TIMer[:TIME] {<numeric>|MIN|MAX} [SENSe:]TC:TIMer[:TIME]? {MIN|MAX} [SENSe:]PCC:TIMer[:TIME] {<numeric>|MIN|MAX} [SENSe:]PCC:TIMer[:TIME]? {MIN|MAX} Parameter Value: 1 to 999 (The default value is 10.) Unit: Response Returns the test time in the <NR3> form. TOS3200...
  • Page 28 Command [SENSe:]TC:WAIT:STATe {ON|OFF|1|0} [SENSe:]TC:WAIT:STATe? [SENSe:]PCC:WAIT:STATe {ON|OFF|1|0} [SENSe:]PCC:WAIT:STATe? Parameter Value: ON (1) Start the test after the test wait time elapses OFF (0) Start the test immediately (default) Response Returns the whether the test is started immediately in the <NR1> form. TOS3200...

  • Page 29: Setting The Measurement Network (Tc Measurement Only)

    TC:MODE / PCC:MODE * RST * * RCL Sets the current measurement mode (MODE). Command [SENSe:]TC:MODE {RMS|DC|PEAK} [SENSe:]TC:MODE? [SENSe:]PCC:MODE {RMS|DC|PEAK} [SENSe:]PCC:MODE? Parameter Value: Rms measurement (default) DC measurement PEAK Peak measurement Response Returns the current measurement mode in the <character> form. TOS3200...

  • Page 30: Setting The Measurement Range

    NA is always returned for the measurement network and connection destination in response to PCC?. NA may be returned for the polarity and single fault mode. TOS3200...

  • Page 31: Saving And Recalling From The Panel Memory

    Panel memory number "<string>" Value: Enter the program name. Double quotation, single quotation, comma, and “@” Panel Control cannot be used. Basics on the User’s Up to 12 characters. Manual Response Returns the memory name in the <string> form. TOS3200...

  • Page 32: Executing The Test (Trigger Function)

    WTG. IDLE state The TOS3200 is in the IDLE state when the power is turned on. In this state, the trigger sub- systems ignore all triggers. Sending ABOR, *RST, or *RCL command at any time also returns the trigger subsystems to the IDLE state.
  • Page 33 Command TRIGger[:SEQuence[1]]:SOURce {IMMediate|BUS} TRIGger[:SEQuence[1]]:SOURce? TRIGger[:TEST]:SOURce {IMMediate|BUS} TRIGger[:TEST]:SOURce? Parameter Value: Start the test immediately (default) Wait for a software trigger (*TRG, TRIG, or IEEE488.1 get (Group Execute Trigger)) to start the test Response Returns the trigger source in the <character> form. TOS3200...
  • Page 34 Command CommandDISPlay:UXV {ON|OFF|1|0} DISPlay:UXV? Parameter Value: ON (1) Displays the voltage OFF (0) Does not display the voltage Response Returns whether or not the voltage is displayed in expanded numeric display mode. The value is returned in the <NR1> form. TOS3200...
  • Page 35 Returns -1 for the program number and step number. If TIMER OFF is selected, +9.9E+37 is returned for the time remaining. Response form <character> STOP Test stopped WAIT Waiting for trigger TEST Test in progress <elapsed time_NR3>elapsed time, <remaining time_NR3>remaining time Unit: TOS3200...
  • Page 36 Test in progress Interval time <elapsed time_NR3>elapsed time, <remaining time_NR3>remaining time Unit: ABOR Aborts the test. The trigger status immediately after the power is turned on is the same as the condition when the ABOR command is sent. Command ABORt TOS3200...

  • Page 37: Saving And Querying The Test Result

    (Change between MANUAL TEST and AUTO TEST is not allowed. Change between TC and PCC is allowed.) or change the display to the SYSTEM or INTERFACE screen, the result can no longer be saved. Command RESult:MANual:SAVE <NR1> RESult:AUTO:SAVE <NR1> Parameter Value: 1 to 50 Memory number TOS3200...

  • Page 38: Querying The Result

    For TC measurement/PCC measurement (RES:MAN:DATA), the test data information of the specified memory number is returned. For the program test (RES:AUTO:DATA), the test data information of the specified memory number and step number is returned. Command RESult:MANual:DATA? <PROGRAM_NR1> RESult:AUTO:DATA? <PROGRAM_NR1>,<STEP_NR1> TOS3200...

  • Page 39: Deleting The Test Results

    Deleting the Test Results RES:MAN:DEL / RES:AUTO:DEL Deletes the contents of the specified memory number. Command RESult:MANual:DELete <NR1> RESult:AUTO:DELete <NR1> Parameter Value: 1 to 50 Memory number RES:MAN:DEL:ALL / RES:AUTO:DEL:ALL Deletes the contents of all memories (specified test only). Command RESult:MANual:DELete:ALL RESult:AUTO:DELete:ALL TOS3200...

  • Page 40: Setting The Program Test

    You can query the upper limit that you can specify using PROG:COUN:FREE. default values PROG:STEP:EDIT:LINE PROG:STEP:EDIT:PAR commands are set in the added steps. Command PROGram:ADD <NR1> Parameter Value: 1 to PROG:COUN:FREE?Required number of steps (up to 100 steps) TOS3200...
  • Page 41 For TC measurement, the range is determined by the upper refer- p. 30 ence, measurement network, and current measurement mode set- tings. For PCC measurement, the range is determined by the upper refer- ence and current measurement mode settings. Response Returns the measurement range in the <character> form. TOS3200...
  • Page 42 ON (1) Abort the program test if a FAIL judgment occurs OFF (0) Continue the program test even if a FAIL judgment occurs (default) Response Returns whether the program test continues if a FAIL judgment occurs in the <NR1> form. TOS3200...
  • Page 43 If 99 is exceeded, 9.9E37 will be set. The default value is 1.) 9.9E37 HOLD Unit: Response Returns the operation mode, connection destination of the measurement terminal, power line polarity, single fault mode, and interval time in order in the comma-separated <FUNC_character>,<PROBE_character>,<POL_character>,<COND_character>, <INTERV_NR1> form. TOS3200...
  • Page 44 Start the test immediately (default) Response Returns the lower reference, lower reference judgment, upper reference, upper reference judgment, test time, test time on/off, test wait time, and test wait time on/off in order in the comma-separated <L_FAIL_NR3>,<L_FAIL_STAT_NR1>,<U_FAIL_NR3>, <U_FAIL_STAT_NR1>,<TIM_NR1>,<TIM_STAT_NR1>,<WAIT_NR1>,<WAIT_STAT_NR1> form. TOS3200...

  • Page 45: Setting The Meter Mode Measurement

    CURR:MODE / VOLT:MODE * RST * * RCL Sets the measurement mode (MODE). Command [SENSe:]CURRent:MODE {RMS|DC|PEAK} [SENSe:]CURRent:MODE? [SENSe:]VOLTage:MODE {RMS|DC|PEAK} [SENSe:]VOLTage:MODE? Parameter Value: Rms measurement (default) DC measurement PEAK Peak measurement Response Returns the current measurement mode in the <character> form. TOS3200...

  • Page 46: Setting The Measurement Range (Current Measurement Only)

    <string> form in response to CURR? or VOLT?. NA is always returned for the measurement network and measurement range in response to VOLT?. (Example) If measurement mode: RMS, measurement network: A, and measurement range: AUTO are specified In response to CURR? Returns "RMS,A,AUTO". In response to VOLT? Returns "RMS,NA,NA". TOS3200...

  • Page 47: Querying The Measured Value

    READ:VOLT:UX / MEAS:VOLT:UX Queries the measured voltage between the measurement network reference points. Specifications on the User’s Manual Command READ[:SCALar]:VOLTage:UX? MEASure[:SCALar]:VOLTage:UX? Response Returns the measured voltage between reference points. The value is returned in the <NR3> form. Unit: TOS3200...

  • Page 48: Querying The Measured Voltage Between Measurement Terminals A And B (Volt- Age Measurement Only)

    MEASure[:SCALar]:VOLTage:UX:MAXimum? Response Returns the maximum measured voltage between reference points that is retained on the TOS3200. The value is returned in the <NR3> form. This query returns the same value as READ:VOLT:UX/MEAS:VOLT:UX during the test wait time. Unit: Querying the Measured Voltage between Measurement Ter-...

  • Page 49: Voltage, Current, And Power Of The Eut

    Command READ[:SCALar]:VOLTage:LINE? MEASure[:SCALar]:VOLTage:LINE? Response Returns the voltage of the EUT in the <NR3> form. Unit: READ:POW:LINE / MEAS:POW:LINE Queries the power of the EUT. Command READ[:SCALar]:POWer:LINE? MEASure[:SCALar]:POWer:LINE? Response Returns the power of the EUT in the <NR3> form. Unit: TOS3200...

  • Page 50: Various Settings

    Converting Measured Current Based on the Specified Line Voltage SYST:CONF:CONV Sets the supply voltage used to convert to current (CONV). Command SYSTem:CONFigure:CONVersion {<numeric>|MIN|MAX} SYSTem:CONFigure:CONVersion? {MIN|MAX} Parameter Value: Not convert the current (default) 80.0 to 300.0 Unit: Response Returns the supply voltage in the <NR3> form. TOS3200...

  • Page 51: Setting The Safety Extra Low Voltage (Selv)

    Returns the buzzer volume for PASS judgments in the <NR3> form. SYST:BEEP:VOL:FAIL Sets the volume of the buzzer that sounds when the judgment is FAIL. Command SYSTem:BEEPer:VOLume:FAIL {<numeric>|MIN|MAX} SYSTem:BEEPer:VOLume:FAIL? {MIN|MAX} Parameter Value: 0 to 10 (default: 3) Response Returns the buzzer volume for FAIL judgments in the <NR3> form. TOS3200...

  • Page 52: Setting The Screen Brightness

    Returns the year, month, and day in order in the <NR1>,<NR1>,<NR1> form. SYST:TIME Sets the time. Command SYSTem:TIME <HOUR_NR1>,<MIN_NR1>,<SEC_NR1> SYSTem:TIME? Parameter <HOUR_NR1> Hour Value: 0 to 23 <MIN_NR1> Minute, <SEC_NR1>Second Value: 0 to 59 Response Returns the hour, minute, and second in order in the <NR1>,<NR1>,<NR1> form. TOS3200...

  • Page 53: Turning The Power Line To The Eut On/Off

    Communication error trace function on OFF (0) Communication error trace function off (default) Response Returns the on/off setting of the communication error trace function in the <NR1> form. Releasing the Protection Status SYST:PROT:CLE Releases the protection status. Command SYSTem:PROTection:CLEar TOS3200...

  • Page 54: Other Settings

    IEEE488.1 REN message (Remote Disable). SYST:REM or SYST:RWL is used to return to remote mode. Command SYSTem:LOCal SYST:OPT Queries the option (HP21-TOS only) that is installed in the TOS3200. The operation is the same as *OPT?. Command SYSTem:OPTion? Response If the HP21-TOS is installed, “HP21-TOS”...
  • Page 55 Various Settings SYST:REM (RS232C and USB only) Sets the TOS3200 operation to remote mode. All panel keys except the LOCAL key and STOP switch are locked. This is a substitute command for the IEEE488.1 REN message (Remote Enable) and address designation.

  • Page 56: Status Register And Status Report Function

    Fig. 3-2 shows the SCPI status register structure. The character “+” represents the the logical OR of the register bits. CONDition register The CONDition register transits automatically and reflects the condition of the TOS3200 in real-time. Reading this register does not affect the contents. EVENt register The EVENt register bits are automatically set according to the changes in the CONDition reg- ister.
  • Page 57 NOT USED HOLD NOT USED PASS FAIL TEST STOP WAIT PROG NOT USED Operation Complete Request Control Query Error Device Dependent Error Execution Error Command Error Reserved Power On Partially changed SCPI Standard 1999.0 Volume1 fig.9-1. Fig. 3-2 Status register TOS3200...

  • Page 58: Ieee488.2 Register Model

    This bit is set to true when a request is received from the digital programming inter- Message Available (MAV) face and the TOS3200 is ready to output the data byte. Standard Event Status Bit This bit is set to true when a bit is set in the Summary (ESB) event status register.

  • Page 59: Event Status Register

    Device Dependent Error Set when there is a device-specific error. (DDE) Set when the TOS3200 evaluates the pro- gram data following the header is outside the formal input range or does not match the Execution Error (EXE) performance of the TOS3200.

  • Page 60: Scpi Register Model

    SCPI Register Model OPERation Status Register The OPERation status register is a 16-bit register which contains information about condi- tions which are part of the TOS3200 normal operation. Decimal Bit name Description value Terminal [A] is active Terminal A is active.
  • Page 61 Returns the positive transition of the OPERation status register in the <NR1> form. STAT:OPER:NTR Sets the negative transition of the OPERation status register. Command STATus:OPERation:NTRansition <NRf> STATus:OPERation:NTRansition? Parameter Value: 0 to 32767 Response Returns the negative transition of the OPERation status register in the <NR1> form. TOS3200...

  • Page 62: Questionable Status Register

    QUEStionable Status Register The QUEStionable status register is a 16-bit register that stores information related to the questionable events and status during TOS3200 operation. These register bits may indicate problems with the measured data of the TOS3200. Decimal Bit name...

  • Page 63: Preset Status

    Returns the negative transition of the QUEStionable status register in the <NR1> form. Preset Status STAT:PRES Resets the ENABle, PTRansition, NTRansition filter registers of all status registers (including sub registers) to their default values. Default values: STATus:ENABle = 0x0000 STATus:PTRansition = 0x7FFF STATus:NTRansition = 0x0000 Command STATus:PRESet TOS3200...

  • Page 64: Tutorial

    After you specify the settings, start the test (when performing the test without using the trig- ger). You cannot start the test while the memory is being recalled/saved, when the power line of the EUT is on, when the TOS3200 is in the protection status, and when PASS/FAIL judgment is in progress. TRIG:SOUR IMM INIT When you send INIT, the test starts.

  • Page 65: Program Test (Auto Test)

    After you specify the settings, start the test (when performing the test without using the trig- ger). You cannot start the test while the memory is being recalled/saved, when the power line of the EUT is on, when the TOS3200 is in the protection status, and when PASS/FAIL judgment is in progress. TRIG:SOUR IMM INIT When you send INIT, the test starts.

  • Page 66: Meter Mode Measurement

    For a current measurement, query the measured value using the MEAS/READ command after setup. FUNC "CURR" CURR:NETW "A";MODE RMS CURR:RANG:SEL AUTO MEAS:CURR:LEAK? MEAS:CURR:LEAK:MAX? For a voltage measurement, query the measured value using the MEAS/READ command after setup. FUNC "VOLT" VOLT:MODE RMS MEAS:VOLT:AB? MEAS:VOLT:AB:MAX? TOS3200...

  • Page 67: A A List Of Messages

    Appendix A List of Messages A List of Errors Processing Time of Main Commands A List of Default Settings...
  • Page 68 SCPI command: Command name in the short form. Affected: Yes for commands that are affected by *RST and *RCL. R/W: Query command (R)/set command (W). *: 1, 2, and 3 indicate SCPI standard command, command in review, and KIKUSUI original command, respectively. PROGram subsystem SCPI Command...
  • Page 69 Specify MAN to save and query the manual test. Specify AUTO to save and query that auto test. Queries the header information of the specified memory number. Response format: YYYY/MM/DD hh:mm:ss AUTO only. Queries the test data information of the specified memory number and step (auto test only). TOS3200...
  • Page 70 :STAT bool Yes Turns on/off the test wait time. R/W 3 Specify TC for touch current measurement and PCC for PCC measurement. FLTPE available only for TC. Varies depending on the current measurement mode and the measurement network settings. TOS3200...
  • Page 71 [:EVEN] Queries the event register. :COND Queries the register status. :ENAB 0 to 32767 R/W 1 Enable. :NTR 0 to 32767 R/W 1 Positive transition. :PTR 0 to 32767 R/W 1 Negative transition. OPERation status register. QUEStionable status register. TOS3200...
  • Page 72 :TIME 0 to 59 Sets the minute. R/W 1 0 to 59 Sets the second. Queries the SCPI specification version :VERS 1999.0 with which the TOS3200 complies. TRIGger subsystem SCPI Command Setting Respon Affec Default Description R/W * Program header...
  • Page 73 Queries the contents of the status byte register and the master summary status *STB message. *TRG Trigger command. *TST Executes a self-test. Prevents the device from executing subsequent commands or queries until all *WAI operations in standby are complete. TOS3200...

  • Page 74: B A List Of Errors

    Generated when parsing a suffix. The suffix does not follow the syntax, or the suffix is inappropriate for -131 Invalid suffix the TOS3200. -134 Suffix too long The suffix of the numeric element is too long. A suffix was encountered after a numeric element which does not -138 Suffix not allowed allow suffixes.

  • Page 75: Execution Errors

    (bit 4) in the event status register to be set. Error code Error message description -200 Execution error (generic) A generic error for the TOS3200. -203 Command protected Password protected program or query command cannot be executed. -210 Trigger error –...

  • Page 76: Query Errors

    Received a new command before the response to the previous query -410 Query INTERRUPTED was read. The controller attempted to read the response after the TOS3200 received an unsupported query or has not received a query. -420 Query UNTERMINATED The -100 “Command error” and this error is stored in the error queue.

  • Page 77: C Processing Time Of Main

    (ms) time (ms) time (ms) 19200 38400 Appx *CLS Clears the register. TC:NETW “B” Sets the measurement network. MEAS:CURR:LEAK? Queries the measured current. STAT:OPER:COND? Queries the register status. RES? Queries the test judgment result. Using USB-GPIB by National Instruments. TOS3200...

  • Page 78: D A List Of Default Settings

    A List of Default Settings Initializing the TOS3200 While holding down the SHIFT key, turn on the POWER switch. The TOS3200 dis- plays the firmware version followed by INITIALIZING! “INITIALIZING!” and starts to initialize. If you initialize the TOS3200, various set-...
  • Page 79 Voltage display in expanded ← DISP:UXV No change display mode The factory default settings are shown below. TIME ADJUST: Standard Japanese time at factory shipment. CAL. DATE: Calibration date at factory shipment. ALARM: One year after CAL. DATE. Aborts the program operation. TOS3200...

  • Page 80: Default Values Of The Panel Memory

    TC measurement conforming to various safety standards. These memory numbers can be overwritten as with 51 to 99. The contents of the panel memory will be reset to default values if the TOS3200 is initialized. Default values of memory numbers 00 to 50 The default values for items other than those indicated in this table are set to the value of item B in below table.
  • Page 81 Default values of memory numbers 51 to 99 Item A Item B Setting Setting Operation mode UPPER ON/OFF NTWK LOWER 30 µA PROBE ENCPE LOWER ON/OFF NORM TIMER 10 s COND NORM TIMER ON/OFF MODE WAIT UPPER 30 mA WAIT ON/OFF RANGE AUTO TOS3200...

  • Page 82: Index

    VISA library ..............7 IEEE Std 488.2 ............6 initialization ...............78 interface ..............6 KI-VISA ...............7 List of Default Settings ..........78 List of Errors .............74 Messages ..............14 List ..............68 NRf ................17 Numeric ..............17 OPERation status register ........60 Panel memory ............80 parameter ..............17 TOS3200...
  • Page 84 KIKUSUI ELECTRONICS CORP. 1-1-3 Higashiyamata, Tsuzuki-ku, Yokohama, 224-0023, Japan Tel: +81-45-593-7570 Fax: +81-45-593-7571 http://www.kikusui.co.jp/en Website...
