Performance Verification
Table 9: Test Equipment (Cont.)
Item Number and
Description
4. Calibration Generator
5. BNC Adapters
6. Dual Input Connector
50 Ω Terminators (2)
7.
8. 10X Attenuators (2)
9. Coaxial Cables (2)
10. Adjustment Tool, Probe

Procedures

30
Minimum Requirements
Calibrated Amplitude:
Period: 1 ms
Amplitude: 50 mVp-p to
20 V p-p into 1 MΩ
Aberrations: ≤ 2% p-p
Accuracy: ≤ 0.5%
Fastrise: ≤ 500 ns
1 Vp-p into 50 Ω
BNC Female to Dual Banana
Dual Input Cable BNC
50 Ω, 2W, BNC
10:1 Attenuator, 50 Ω, BNC
50 Ω, 36 in. L, BNC male both
ends
Plastic Insulated
Before beginning the procedures in this section, connect the output of the
ADA400A Differential Preamplifier to the oscilloscope, turn the oscilloscope on,
and let the ADA400A warm up for 20 minutes.
NOTE. Before performing these procedures, make sure your oscilloscope can
display the proper scale factor. If you are using an oscilloscope that is not
compatible with the scale factor coding of the ADA400A Differential Preamplifi-
er to perform these procedures, see page 2 to properly configure the scale factor
coding.
To convert the volts/division settings for oscilloscopes that cannot read the scale
factor from the ADA400A, multiply the volts/div setting in the procedure by the
gain setting of the ADA400A.
Example
CG5011
Tektronix part number
103- - 0090- - 00
Tektronix part number
067- - 0525- - 02
Tektronix part number
011- - 0049- - 01
Tektronix part number
011- - 0059- - 02
Tektronix part number
012- - 1341- - 00
Tektronix part number
003- - 0675- - 01
ADA400A Differential Preamplifier
Purpose
Gain check and adjustment.
LF Compensation adjustments
Signal connection
Signal connection
Signal connection
Signal attenuation
Signal connection
Adjustments (Adjustment
Procedure only)
