Operating Basics
8
+ Input Fuse

Figure 3: Input Connectors and Fuses

TEKPROBE Interface Pins
Signal Output
BNC

Figure 4: Output Connector

+ Input BNC
- - Input BNC
Connector
Connector
ADA400A Differential Preamplifier
- - Input Fuse
