CV14
(LF Compensation)
*CV13
(HF CMRR)
*CV17
RV106
(10X Gain)
(Offset Zero)
ADA400A Differential Preamplifier
R18
RV32
Figure 16: Location of Adjustments Underneath Inner Shield
Adjustment Procedures
CV6
(LF Compensation)
*CV12
*CV18
RV17
(LF CMRR)
CV4 (HF)
RV62
(100X Gain)
RV33
(Offset Balance)
*Factory adjust only
