Description

Description
This User Guide details the DLRO10HD and the DLRO10HDX.
Both the DLRO10HD and the DLRO10HDX measure the same tests and parameters, in addition the DLRO10HDX
can save, recall and download test results to PowerDB.
The DLRO10 range of digital low resistance ohm meters measure resistance in a range of 0.1 µΩ to 2 k. These
instruments provide a maximum test current of 10 Amps. The DLRO10 range consist of four versions:
„ DLRO10
„ DLRO10X
„ DLRO10HD
„ DLRO10HDX

Key Features

„ Simple operation
„ High power ranges
„ Simultaneous testing and battery charging
„ Rugged case construction designed for use in demanding environments or the lab
„ IP65 with the lid closed and IP54 with the lid open for protection against ingress during operation (IP65 lid
closed)
„ Multiple lead set options (Megger connect leads - see the lead set data-sheet)
„ 10 A while measuring up to 250 mΩ and 1 A while measuring up to 2.5 Ω
„ Monitors test lead contact - reduces the chance of erroneous readings
„ Rechargeable battery: Capacity <1000 10A test
„ Auto power off
„ Large, clear LCD for all light conditions
„ Time and Date stamped memory for recording of results (DLRO10HDX only)
„ Memory storage and USB download capability (DLRO10HDX only)
„ CAT III 300 V: Protected against accidental connection to external voltages up to 600 V DC applied between
any pair of the f our terminals for up to 10 seconds
