Overview
Overview
This section details an over view of the instrument:
Display
DLRO10HDX
DLRO10HD
Item Description
1
Current Terminals
2
Potential Terminals
3
Test Lead LED Cable
4
Display
5
Save Button
6
USB socket (download records)
7
Hazard warning LED during test
8
Range Rotary Switch
6
DLRO10HD / DLRO10HDX
1
16
15
14
13
12
11
10
1
15
13
12
14
11
3
2
9
8
2
3
8
9
Item Description
9
Test button (Start and stop tests)
10
Navigation keypad (setup and stored results)
11
Test modes and Off rotary switch
12
Mains Power On LED
13
Fuse
14
Contrast button
15
Mains Power Socket
16
Back-light
4
5
6
7
4
7
16
