3 sysTEM OVErViEW

3
System overview

3.1 The instrument

On front is the control panel where from you can
operate and monitor the circuit breaker position, you
set the operation sequence and run the measurement.
On top is the panel that includes all connectors for in
and outputs.

TM1710

The TM1710 is a "black box" version equipped with
one Control section, one Timing M/r section and one
Digital section.
16 TM1700-sEriEs

TM1720

The TM1720 is a "black box" version with two Con-
trol sections, one Timing Aux, one Timing M/r section
and one Digital section.

TM1750

The TM1750 has two Control sections, one Timing
Aux, one Timing M/r section and one Digital section.
