AP-VP300N Button information
Creating New Subscriber Numbers (testing call connection between extension numbers-
Setting up AP-VP300N by using OSD)
Description for Overall Key Features of AP-VP300N
No. Keys Features
(1) SpeedDial Brining a menu for speed dial
(2) F1~F4 When you use Phone Book or Speed Dial, these functions are assigned to
the touch screen, which is located in the lower part of the screen.
(3) INFO While on the line, you can select whether to display information
(4) Number Dialing by using remote control. Used for entering each value of setup of
Key OSD menu
(5) Hook Flash Hold key for headset or speaker phone during phone conversation
(6) Camera Used for turning on/off the camera screen
(7) Privacy While on the line, the other person is not able to see you
(8) Menu Brining OSD main menu
Used for moving to a higher category in OSD menu.
(9) Cancel
(10) Call Used for brining call history from the latest and calling by pressing number
keys
방향키, OK
(11) Checking and moving with in OSD menus or adjusting camera movement
(12) END To end on line call
(13) View Changing conversation view/ remote view/ local view while on the line
Used during the user's absence (to be released)
(14) Absence
(15) Voice Mail To listen to voice mail (to be released)
(16) HDP Call For using headset
(17) SPK Call To use imbedded speaker phone
