Copy from the programming key
This function downloads a set of settings earlier saved in the controller. Select the
relevant number.
All settings except for Application (o61) and Address (o03) will be copied. When copy-
ing has started the display returns to o66. After two seconds you can move back into
the menu again and check whether the copying was satisfactory. Showing of a nega-
tive figure spells problems. See the significance in the Fault Message section.
Save as factory setting
With this setting you save the controller's actual settings as a new basic setting (the
earlier factory settings are overwritten).
Service
Temperature measured with S5 sensor
Status on DI1 input. on/1=closed
Temperature measured with S3 sensor
Status on night operation (on or off ) 1=closed
Temperature measured with S4 sensor
Thermostat temperature
Read the present regulation reference
Status on DI2 output. on/1=closed
Temperature shown on display
Measured temperature for alarm thermostat
* Status on relay for cooling
* Status on relay for fan
* Status on relay for defrost
* Status on relay for railheat
* Status on relay for alarm
* Status on relay for light
*) Not all items will be shown. Only the function belonging to the selected applica-
tion is shown.
EKC 202D Manual RS8EE202 © Danfoss 08-2010
o66 -
o67 -
- - - Night Setback
0=Day
1=Night
Service
u09 S5 temp.
u10 DI1 status
u12 S3 air temp
u13 Night Cond.
u16 S4 air temp
u17 Ther. air
u28 Temp. ref.
u37 DI2 status
u56 Display air
u57 Alarm air
u58 Comp1/LLSV
u59 Fan relay
u60 Def. relay
u61 Railh. relay
u62 Alarm relay
u63 Light relay
