Fan cut in during defrost
Here you can set whether fan is to operate during defrost.
0: Stopped (Runs during pump down)
1: Running (stopped during "fan delay")
2: Running during pump down and defrost. After that stopped
Defrost sensor
Here you define the defrost sensor.
0: None, defrost is based on time
1: S5
2: S4
Pumpdown delay
Set the time where the evaporator is emptied of refrigerant prior to the defrost.
Defrost on demand – aggregate refrigeration time
Set here is the refrigeration time allowed without defrosts. If the time is passed, a
defrost will be started.
With setting = 0 the function is cut out.
Defrost on demand – S5 temperature
The controller will follow the effectivity of the evaporator, and via internal calcula-
tions and measurements of the S5 temperature it will be able to start a defrost when
the variation of the S5 temperature becomes larger than required.
Here you set how large a slide of the S5 temperature can be allowed. When the value
is passed, a defrost will start.
The function can only be used in 1:1 systems when the evaporating temperature
will become lower to ensure that the air temperature will be maintained. In central
systems the function must be cut out.
With setting = 20 the function is cut out
If you wish to see the temperature at the defrost sensor, push the controller's lower-
most button.
If you wish to start an extra defrost, push the controller's lowermost button for four
seconds.
You can stop an ongoing defrost in the same way
The LED on the controller's front will indicate whether a defrost is going on.
Fan
Fan stopped at cut-out compressor
Here you can select whether the fan is to be stopped when the compressor is cut out
Delay of fan stop when compressor is cut out
If you have chosen to stop the fan when the compressor is cut out, you can delay the
fan stop when the compressor has stopped.
Here you can set the time delay.
Fan stop temperature
The function stops the fans in an error situation, so that they will not provide power
to the appliance. If the defrost sensor registers a higher temperature than the one set
here, the fans will be stopped. There will be re-start at 2 K below the setting.
The function is not active during a defrost or start-up after a defrost.
With setting +50°C the function is interrupted.
The LED on the controller's front will indicate whether a defrost is going on.
10
Manual RS8EE202 © Danfoss 08-2010
d09
FanDuringDef
d10
DefStopSens.
d16
Pump dwn del.
d18
MaxTherRunT
d19
CutoutS5Dif.
Defrost temp.
Def Start
Here you can start a manual defrost
Defrost Relay
Here you can read the defrost relay
status or you can force-control the
relay in "Manual control" mode.
Hold After Def
Shows ON when the controller is
operating with coordinated defrost.
Defrost State
Status on defrost
1= pump down / defrost
Fan control
F01
Fan stop CO
(Yes = Fan stopped)
F02
Fan del. CO
F04
FanStopTemp.
Fan Relay
Here you can read the fan relay status,
or force-control the relay in "Manual
control" mode.
EKC 202D
